BNC Connectors Injection Making Machines BNC Connectors Isolated Female Edge Mount
Ready to Ship
In stock Fast dispatch

BNC Connectors Injection Making Machines BNC Connectors Isolated Female Edge Mount

  • >= 500 Pieces
    $0.89

Customization:

Customized packaging（Min.Order: 1000 pieces）
View product details

BNC Connectors Injection Making Machines BNC Connectors Isolated Female Edge Mount

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • RF Signal Transmission: Designed for high-frequency signal transmission in electronic systems, supporting applications like satellite communications, radar, and wireless networking.
  • Surface Mount Compatibility: Features a mounting flange for secure PCB integration, enabling easy assembly in circuit board designs.
  • Waterproof Protection: Durable waterproof design ensures reliability in harsh environments, such as automotive and medical equipment applications.

Key features

  • 1. Corrosion-Resistant Brass Construction & Waterproof Protection

    • With corrosion-resistant brass material and IP67-rated waterproofing*, you can ensure durability in harsh automotive and medical environments. Outperforms non-waterproof connectors in moisture-prone settings*.

  • 2. Surface Mount Design for Rapid PCB Integration

    • With a surface mount flange, you can achieve quick and secure PCB assembly, reducing installation time by up to 30% compared to through-hole alternatives*. Ideal for high-volume manufacturing workflows.

  • 3. High-Frequency RF Performance for Critical Applications

    • With optimized RF performance up to 4 GHz, you can transmit signals reliably in radar, satellite, and test equipment. Outperforms standard BNC connectors in high-frequency stability*.

  • 4. Versatile Scenario Solutions for Automotive & Medical Use

    • Designed for automotive electronics and medical devices, this connector provides a robust, waterproof solution for vibration-heavy or sterile environments. Meets industry-specific reliability demands*.

  • 5. Compliance with Global Industry Standards

    • With RoHS compliance and medical-grade durability*, you can meet regulatory requirements for global markets. Reduces certification risks compared to non-compliant alternatives.

Product details

BNC Connectors Injection Making Machines BNC Connectors Isolated Female Edge Mount

The BNC Connectors Injection Making Machine produces high-quality isolated female edge mount BNC connectors designed for precision applications in automotive, medical equipment, and RF systems. Built with durable metal (brass alloy) and a polished finish, these connectors ensure reliable signal transmission and robust environmental resistance.

Technical specifications

FeatureSpecificationBenefit
MaterialBrass alloySuperior electrical conductivity and durability
Mounting TypeSurface mount (flange) + PCB-compatibleEasy integration into circuit boards
Waterproof RatingIP67 (immersion-resistant)Safe for harsh environments
OrientationStraight or right angleFlexible installation in tight spaces
Pin Configuration1P (single pin)Simplified wiring for low-complexity systems
Locking MechanismBayonet-style nut with retention clipSecure connection under vibration

Customization guide

Adjustable parameters include:

  • Orientation: Swap between straight/right angle to fit PCB layouts.
  • Material Finish: Customize plating (e.g., gold, nickel) for corrosion resistance.
  • Pin Count: Upgrade to 2P/3P configurations for multi-signal applications.

Get inspired

With a waterproof rating of IP67, these BNC connectors are ideal for automotive sensors or medical devices exposed to moisture. Their surface-mount design streamlines assembly in compact electronics, while the locking nut ensures stability in high-vibration environments.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Waterproof RatingIP65IP67IP68
Frequency Range0–3 GHz0–6 GHz0–12 GHz
Operating Temp-20°C to +85°C-40°C to +105°C-55°C to +125°C

Supplier's note

  1. Technical Breakthroughs:

    • IP68 Waterproofing (Pro Model): Enables underwater deployment in marine electronics.
    • 12 GHz Frequency Support (Pro): Outperforms industry standards for 5G and radar systems.
    • -55°C to +125°C Temp Range (Pro): Operates in extreme environments like aerospace.

  2. Model Selection Guide:

    • Base Model: Suitable for standard automotive or indoor medical devices.
    • Advanced Model: Ideal for outdoor RF equipment or industrial sensors requiring IP67.
    • Pro Model: Best for aerospace, underwater systems, or high-frequency test setups.

With the Pro’s tripled temperature tolerance and 12 GHz bandwidth, you can deploy connectors in satellite communication systems where reliability is critical. Pair its gold-plated pins with ruggedized cables to ensure zero signal loss in extreme conditions.

Frequently asked questions

  • Which BNC connector model is best suited for automotive applications?

  • How do I maintain a right-angle BNC connector for medical equipment?

  • Metal vs. plastic BNC connectors: Which is better for high-frequency RF signals?

  • Can this BNC connector be customized for right-angle PCB mounting?

  • Is this BNC connector FDA-approved for medical equipment use?

  • What makes this surface mount BNC connector suitable for high-frequency applications?

  • Can I use this female BNC connector in waterproof outdoor setups?

  • How does the PCB mount design simplify assembly compared to traditional connectors?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Waterproof RatingAutomotive, Outdoor EquipmentIP54 (Industry) → IP65▲ (Base) → IP67▲▲ (immersion up to 1m for 30min)Protects against water submersion in harsh environments (e.g., automotive)Higher IP ratings increase cost and require careful installation
RF PerformanceTelecommunications, Radar SystemsVSWR ≤1.5 @4GHz (Industry) → ≤1.3 @6GHz▲ (Base) → ≤1.2 @18GHz▲▲ (Advanced)Supports high-frequency applications like 5G infrastructure and satellite linksAdvanced versions may have bulkier designs affecting space-constrained systems
Mounting FlexibilityPCB Assembly, Industrial EquipmentPCB/Panel Mount (Industry) → +Cable Options▲ (Base) → +Right-Angle▲▲ (Advanced)Flexibility for diverse mounting needs (e.g., tight spaces in medical devices)More options add complexity to inventory management
Durability (Cycle Life)Military, Aerospace500 mating cycles (Industry) → 1,000▲ (Base) → 2,000▲▲ (Advanced)Ensures reliability in high-vibration environments (e.g., automotive systems)Advanced versions may require more rigorous testing and validation
PIM Performance5G Base Stations, Cellular NetworksNot specified (Industry) → PIM < -150dBc▲ (Base) → < -160dBc▲▲ (Advanced)Minimizes signal interference in dense telecom networksRequires specialized manufacturing processes, increasing production costs
Operating TemperatureIndustrial, Automotive-20°C to +70°C (Industry) → -40°C to +85°C▲ (Base) → -55°C to +125°C▲▲ (Advanced)Operates reliably in extreme environments (e.g., under-the-hood automotive use)Wider ranges may necessitate heavier materials, affecting weight and cost
