CNC 4th 5th Axis Rotary Axis Dividing Head Harmonic Gearbox
Ready to Ship
In stock Fast dispatch

CNC 4th 5th Axis Rotary Axis Dividing Head Harmonic Gearbox

  • 1 - 4 Pieces
    $1,163
  • >= 5 Pieces
    $1,052

Customization:

Customized packaging（Min.Order: 100 pieces）
Graphic customization（Min.Order: 100 pieces）
Customized logo（Min.Order: 100 pieces）
View product details

CNC 4th 5th Axis Rotary Axis Dividing Head Harmonic Gearbox

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Precision Angular Positioning: Equipped with a harmonic gearbox and stepper motor, the rotary axis dividing head enables precise angular positioning (±0.001°–±0.005°) for CNC machining, metrology, and assembly processes.
  • Multi-Axis Compatibility: Designed for 4th/5th axis integration in CNC systems, it supports complex machining operations such as milling, drilling, and contouring on irregular workpieces.

Key features

  • 1. Corrosion-Resistant Aluminum & Robust Steel Construction

    • With a corrosion-resistant aluminum motor housing and a robust steel base, ensure durability and stability in heavy-duty machining environments. ~30% lighter than all-steel alternatives*, enabling easier handling while maintaining structural integrity.

  • 2. Precision Stepper Motor for Ultra-Accurate Positioning

    • With a precision stepper motor, achieve angular accuracy as fine as ±0.001°, enabling repeatable positioning in complex CNC operations. Outperforms traditional DC motors in precision control*, critical for applications like aerospace component machining.

  • 3. High-Torque Harmonic Gearbox for Enhanced Efficiency

    • The harmonic gearbox design delivers smooth motion and high torque, enhancing output speed by up to 25% compared to traditional worm gear systems*. Ideal for rapid, high-precision 4th/5th axis operations in multi-axis machining.

  • 4. Customizable Solutions for Diverse Industrial Needs

    • With customizable material (e.g., stainless steel for corrosive environments) and modular mounting options, adapt to specialized applications such as medical device prototyping or automotive part manufacturing. Outperforms rigid, non-modular competitors in versatility*.

  • 5. ISO-Compliant Precision for Global Manufacturing Standards

    • Compliance with ISO precision standards ensures compatibility with global quality requirements, meeting strict industry regulations for accuracy and safety in precision engineering and research applications.

Product details

CNC 4th 5th Axis Rotary Axis Dividing Head Harmonic Gearbox

The CNC 4th/5th Axis Rotary Axis Dividing Head with Harmonic Gearbox is a precision-engineered accessory for advanced machining applications. Featuring a high-grade metal construction (aluminum/steel), a stepper motor for repeatable positioning, and angular accuracy as tight as ±0.001°, this dividing head enables complex 3D contouring and multi-axis machining. Ideal for industries like aerospace, automotive, and prototyping, it supports customization for material, size, and mounting requirements.

Technical specifications

FeatureSpecificationBenefit
MaterialHigh-grade aluminum/steelDurable, corrosion-resistant base
Angular Accuracy±0.001° to ±0.005° (model-dependent)Precision for tight tolerance applications
Motor TypeStepper motorHigh-resolution control for repeatability
Load CapacityUp to 1,000 kg (Pro model)Supports heavy-duty machining tasks
Warranty3 months or optional noneFlexible coverage based on use case

Customization guide

  • Material Customization: Switch to stainless steel for corrosive environments or lightweight aluminum for portable setups.
  • Size Adjustment: Tailor the table diameter and base dimensions to fit workbench constraints.
  • Mounting Options: Choose clamping plates, flanges, or integrated brackets for seamless integration.

Get inspired

With its harmonic gearbox and stepper motor, this dividing head unlocks precision in applications like turbine blade manufacturing or intricate gear cutting. Whether you’re machining aerospace components or prototyping medical devices, the modular design ensures adaptability to evolving project needs.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Angular Accuracy±0.005°±0.002°±0.001° (3× industry standard)
Load Capacity500 kg800 kg1,000 kg
Motor Torque1 Nm1.5 Nm2 Nm (+20% vs. competitors)
CertificationsBasic ISOIP65ISO 230-1 + IP67

Supplier's note

  1. Technical Breakthroughs:

    • Harmonic Gearbox: Achieves smoother motion with minimal backlash, enabling sub-micron positioning.
    • Stepper Motor Control: Ensures ±0.001° repeatability for high-volume production runs.
    • Material Flexibility: Stainless steel variants resist corrosion in chemical processing.

  2. Version Selection Guidance:

    • Base Model: Ideal for small workshops or basic 4th-axis tasks (e.g., engraving).
    • Advanced Model: Suitable for mid-tier manufacturers needing ±0.002° accuracy (e.g., mold making).
    • Pro Model: Best for aerospace or medical industries requiring ISO-certified precision (e.g., turbine blade machining).

With the Pro model’s triple-industry-standard accuracy, you can machine aerospace alloys with tolerances as tight as 0.002 mm. Pair its IP67 rating with stainless steel construction to ensure reliability in harsh environments.

Frequently asked questions

  • Which precision rotary table model suits high-precision CNC machining applications?

  • How to maintain the stepper motor in a precision rotary table for longevity?

  • What materials are used in the base and housing of this dividing head?

  • Can this rotary table be customized for corrosive environments?

  • Is the harmonic gearbox in this dividing head ISO-certified for precision?

  • Which industries benefit most from this precision rotary table?

  • Does the aluminum housing affect durability compared to steel?

  • Are mounting options customizable for non-standard workbenches?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Standard Rotary TablesGeneral machining, basic setups±0.1° precision (ISO 230-2), manual indexing, carbon steel constructionCost-effective, easy maintenanceLow precision, limited automation capabilities
High-Precision Rotary TablesCNC machining, metrology±0.005° accuracy (ISO 230-2), stepper motor, aluminum alloy (ASTM A963)High accuracy, reliable performanceHigher cost, requires skilled operation
CNC Rotary AxesAutomated manufacturing lines±0.001° (ISO 230-2), digital control interface, modular design (ISO 9001)Full automation, high repeatabilityComplex setup, expensive
Dividing Heads (Base Model)Workshops, medium-precision±0.01°, manual indexing, steel base (ASTM A36), 3-month warrantyDurable, affordableLimited precision, short warranty
Dividing Heads (Advanced Model)High-precision CNC setups±0.002°▲ (ISO 230-2), stepper motor, harmonic gearbox (Harmonic Drive®), 2-year warrantySuperior precision▲, smooth operation▲, extended warranty▲Higher price, requires technical expertise
Modular Rotary SystemsCustom applications, researchCustomizable size/material (up to 500mm diameter), ±0.003° accuracy (ISO 230-2)Highly adaptable, versatileLonger lead times, complex integration
