CNC Manual Rotary Table HV4 HV6 HV8 HV10 Milling Indexing Table
Ready to Ship
In stock Fast dispatch

CNC Manual Rotary Table HV4 HV6 HV8 HV10 Milling Indexing Table

$160.00-$269.00/ Piece|2 Piece/Pieces(Min. Order)

Customization:

Customized logo（Min.Order: 2000 pieces）
View product details

CNC Manual Rotary Table HV4 HV6 HV8 HV10 Milling Indexing Table

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Precision Indexing: Enables high-accuracy rotation and positioning of workpieces for milling, drilling, and grinding operations, supporting precise angular adjustments via a graduated scale.
  • Workpiece Clamping: Features evenly spaced slots and secure clamping mechanisms to hold materials firmly during multi-axis machining processes.

Key features

  • 1. Durable Steel Construction for Heavy-Duty Use

    • With a robust steel material, ensure long-lasting precision and resistance to wear in demanding machining environments. This construction offers superior strength compared to cast iron alternatives*, enabling reliable performance in high-stress applications.

  • 2. Ergonomic Manual Control for Precision Indexing

    • With ergonomic handles and precise indexing scales, achieve accurate angle adjustments (down to 0.01mm) without relying on electronic systems*. This manual design provides unmatched tactile control compared to motorized rotary tables*, ideal for intricate machining tasks.

  • 3. High-Precision Indexing for Multi-Axis Machining

    • With a concentric circular surface and precise indexing capability, maintain tight tolerances (±0.01mm) during multi-step milling or drilling operations*. This ensures consistent results in complex processes, outperforming standard rotary tables with lower accuracy*.

  • 4. Versatile Industrial Applications

    • Designed for aerospace, automotive, and precision manufacturing, it adapts to diverse machining needs such as drilling, milling, and grinding*. Its round design and clamping slots enable secure workpiece rotation for both small workshops and large-scale industrial setups*.

  • 5. Compliance with Precision Standards

    • Built to meet ISO precision standards for machining tools, ensuring reliability in critical applications*. This certification guarantees compatibility with high-precision workflows, surpassing non-certified alternatives*.

Product details

CNC Manual Rotary Table HV4 HV6 HV8 HV10 Milling Indexing Table

The CNC Manual Rotary Table HV4/HV6/HV8/HV10 is a precision tool designed for high-accuracy milling and indexing applications. Built from steel for durability, it features manual operation, a round table design, and a 1-year warranty. Its ergonomic handles, graduated scale, and clamping slots enable precise rotation and secure workpiece positioning, making it ideal for aerospace, automotive, and industrial manufacturing.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialSteelWithstands heavy-duty machining demands
Rotation Precision±0.02° (HV4), ±0.01° (HV10)Aerospace components requiring tight tolerances
Clamping System12–20 evenly spaced slotsSecure holding during multi-axis machining
Rotation Control3 ergonomic handlesSmooth indexing adjustments in milling operations
Measurement ScaleGraduated in degrees/minutesPrecise angle positioning for complex parts
Warranty1 year (2 years for Pro models)Peace of mind for long-term use

Customization guide

Adjustable indexing plates and clamping systems can be tailored to accommodate specific workpiece sizes, materials, or rotational requirements.

Get inspired

The HV series rotary tables deliver unmatched precision for tasks like drilling, grinding, and contour milling. With their robust steel construction and manual operation, they empower manufacturers to achieve flawless results in high-stakes applications.

Choose your model

ParameterBase Model (HV4)Advanced Model (HV6)Pro Model (HV8/HV10)
Table Diameter4"6"8"–10"
Max Load Capacity400 kg+20% (480 kg)+40% (560–700 kg)*
Rotation Precision±0.02°±0.015°±0.01°
Clamping Slots121620

Supplier's note

  1. Technical Breakthroughs:

    • The Pro model’s ±0.01° precision triples industry standards, enabling flawless aerospace component alignment.
    • Enhanced clamping force (+30% in Pro models) ensures stability for heavy materials like titanium.
    • Larger diameters (up to 10") accommodate oversized workpieces, expanding application versatility.

  2. Version Selection Guide:

    • Base Model (HV4): Ideal for small workshops or light-duty tasks requiring basic precision.
    • Advanced Model (HV6): Perfect for mid-sized manufacturers needing faster indexing (20% quicker than HV4) and higher load capacity.
    • Pro Model (HV8/HV10): Designed for high-volume production or precision engineering (e.g., turbine blades), with double the clamping slots and extreme durability.

With the Pro’s ±0.01° precision, you can machine aerospace parts with unmatched accuracy. Pair its 10" diameter with heavy-duty clamping to handle large, complex components. The Advanced model’s 20% faster indexing reduces downtime in automotive assembly lines. Choose wisely based on your workload and tolerance requirements.

Frequently asked questions

  • Which HV series rotary table model is best for small workshop milling operations?

  • How to clean and maintain the indexing mechanism of a manual rotary table?

  • Steel vs Cast Iron: Which material is better for precision rotary tables in machining?

  • Can the HV series rotary table be customized with specific clamping options?

  • Is the HV rotary table material compliant with aerospace industry standards?

  • What types of milling operations is the HV rotary table suitable for?

  • What does the 1-year warranty for the HV rotary table cover?

  • How does the HV rotary table ensure high precision indexing for machining tasks?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Material CompositionHeavy-duty machining, corrosive environmentsIndustry: Cast Iron (ISO 8340 compliant)
Base: Steel (ASTM A36, 0.5mm corrosion resistance▲)
Advanced: High-grade Steel (ASTM A536, 1.2mm corrosion resistance▲▲)		Base: Lighter weight and corrosion resistance▲
Advanced: Enhanced strength▲▲		Cast Iron’s rigidity may require heavier builds
Precision LevelAerospace, medical partsIndustry: ±0.05mm (ISO 230-2)
Base: ±0.02mm▲
Advanced: ±0.01mm▲▲		Base: Better for precision parts▲
Advanced: Meets aerospace tolerances▲▲		Higher precision increases cost
Workholding CapacityAutomotive manufacturingIndustry: Up to 5kg
Base: 10kg▲
Advanced: 20kg▲▲		Base: Handles larger parts▲
Advanced: Industrial-grade capacity▲▲		Larger size may require more space
Power TypeHigh-repetition tasksIndustry: Manual (basic handles)
Base: Ergonomic handles▲
Advanced: Torque control▲▲		Base: Reduces fatigue▲
Advanced: Precise angle control▲▲		No motorized option available
Customization OptionsPrototyping, varied partsIndustry: Standard clamping
Base: Adjustable clamping▲
Advanced: Modular system▲▲		Base: Flexibility for different parts▲
Advanced: Quick setup▲▲		Setup time increases with customization
WarrantyLong-term industrial useIndustry: 6 months
Base: 1 year▲
Advanced: 2 years▲▲		Base: Standard coverage▲
Advanced: Extended reliability▲▲		No disadvantages
