CNC PCB Printed Circuit Board Drilling Cutting Machine Machinery

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Precision PCB Drilling & Cutting: Equipped with CNC technology and a servo motor, the machine ensures high-precision drilling and cutting of printed circuit boards (PCBs) for electronic components.
  • Material Adaptability: Designed to handle various PCB materials (e.g., FR4, aluminum-backed boards) with customizable tooling for diverse manufacturing needs.

Key features

  • 1. Corrosion-Resistant Metal Construction

    • With a durable steel/aluminum body, this CNC PCB drilling machine ensures longevity in industrial environments. The robust material resists wear and tear, maintaining precision over prolonged use.

  • 2. Touchscreen Interface with Multi-Program Presets

    • With an intuitive touchscreen control panel, you can customize drilling programs effortlessly. Pre-set configurations streamline workflows for different PCB designs, reducing setup time.

  • 3. High-Precision Servo Motor

    • Powered by a servo motor, this machine delivers exceptional accuracy and speed, ensuring consistent drilling and cutting results even for intricate PCB layouts.

  • 4. Transparent Panels for Real-Time Monitoring

    • The transparent front panel allows operators to monitor operations and robotic arm movements in real-time, enabling quick adjustments for quality control and troubleshooting.

  • 5. Compact Bench Design for Versatile Workspace Integration

    • As a bench drilling machine, it optimizes workspace efficiency, making it ideal for small workshops or prototyping environments without sacrificing performance.

Product details

CNC PCB Printed Circuit Board Drilling Cutting Machine Machinery

The ChiKin CNC PCB Printed Circuit Board Drilling Cutting Machine is a precision-engineered benchtop solution designed for high-accuracy PCB fabrication. Equipped with a servo motor and CNC technology, it offers automated drilling and cutting capabilities, while its transparent front panel enables real-time monitoring of operations.

Technical specifications

FeatureSpecificationBenefit
CNC TechnologyComputer Numerical ControlEnables automated, repeatable PCB drilling
MotorHigh-precision servo motorEnsures consistent speed and torque
MaterialDurable steel/aluminum alloyWithstands heavy-duty industrial use
DesignBench-type compact configurationOptimized for space-constrained workshops
Control PanelDigital touchscreen interfaceUser-friendly programming and adjustments
VisibilityReinforced polycarbonate front panelReal-time monitoring of robotic arms
Warranty1-year manufacturer warrantyPeace of mind with reliable service

Customization guide

Adjustable parameters such as drilling speed, tool path precision, and material thickness tolerance can be customized to meet specialized PCB production needs, such as high-volume manufacturing or delicate prototyping.

Get inspired

The ChiKin CNC PCB Drilling Machine combines precision engineering with user-friendly design, offering unmatched versatility for PCB fabrication. Whether you’re prototyping or mass-producing circuit boards, this machine delivers accuracy and efficiency tailored to your workflow.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Drilling Accuracy±0.02mm±0.01mm±0.005mm
Max. Speed1200 RPM1500 RPM1800 RPM (+50% vs Base)
Load Capacity500kg800kg1200kg
Tool CompatibilityStandard bitsExtended rangeCustomizable
Noise Level65 dB60 dB55 dB

Supplier's note

  1. Three Technical Breakthroughs:

    • CNC Precision: With micron-level accuracy (±0.005mm in the Pro model), you can achieve flawless drilling in high-density PCBs.
    • Servo Motor Efficiency: The servo motor ensures 20% faster drilling speeds than traditional models, reducing cycle times.
    • Transparent Monitoring: The polycarbonate front panel allows real-time oversight, minimizing downtime for quality control.

  2. Optimal Version Selection:

    • Base Model: Ideal for small workshops requiring basic CNC drilling (e.g., prototyping).
    • Advanced Model: Perfect for medium-scale production needing ±0.01mm precision (e.g., consumer electronics assembly).
    • Pro Model: Designed for heavy-duty industrial use, with triple the load capacity of competitors, enabling high-volume PCB manufacturing.

With the Pro model’s ±0.005mm accuracy, you can produce intricate circuit boards for aerospace applications. Its 1800 RPM speed outperforms industry standards, slashing production timelines by 20%. Pair this with the transparent panel for seamless quality checks, ensuring zero defects in high-stakes projects.

Frequently asked questions

  • Which CNC PCB drilling machine is best suited for small electronics workshops?

  • How do I clean and maintain the drill bits on a CNC PCB drilling machine?

  • What’s the advantage of a CNC PCB drilling machine over manual ones?

  • Can this machine handle custom PCB designs with intricate patterns?

  • Is the ChiKin CNC PCB machine certified for industrial use?

  • How often should the servo motor be serviced for optimal performance?

  • Does the bench drilling machine save space compared to floor models?

  • Can I monitor the drilling process in real-time?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
CNC PCB Drilling MachinesPCB assembly lines, high-precision manufacturingCNC-controlled paths (ISO 230-2 compliant) ▲ Advanced model’s 10,000 RPM servo motor (industry standard: 8,000 RPM)±0.01mm precision (ideal for fine PCBs), automated error reductionHigher cost (2x baseline models), requires skilled operators
Manual Drilling MachinesSmall workshops, prototypingManual operation, 2,000 RPM motor, basic steel frame (ISO 9001 certified)Affordable (50% cheaper than CNC), minimal maintenance±0.5mm tolerance (unsuitable for precision tasks), labor-intensive
Servo Motor-Driven DrillsHigh-speed assembly linesServo motor (10,000 RPM ▲ Advanced model: 12,000 RPM), programmable settings40% faster cycle time (IEC 61131-3 compliant), consistent performanceHigher maintenance costs (30% more than manual models), space-intensive
High-Precision Drilling SystemsAerospace/medical manufacturingLaser-guided alignment (ISO 10360), tolerance ±0.001mm ▲ Advanced: ±0.0005mmMinimal rework (critical for aerospace parts), extreme accuracy50% cost premium, complex calibration requirements
Industrial Bench DrillsMedium-volume productionHeavy-duty steel frame (ISO 13849), adjustable RPM (0–5,000 ▲ Advanced: 6,000 RPM)Robust for heavy use, versatile material handlingBulky design (requires 2m² space), no automation features
Entry-Level Drilling MachinesEducational/hobbyist useBasic CNC interface, 5,000 RPM motor ▲ Advanced model: 7,000 RPM (ISO 230-2)Affordable entry point (half the cost of advanced models), easy learningLimited precision (±0.2mm), slower processing (ideal for non-critical tasks)
