China Henan Large Span Steel Structure Space Frame Design Book Free Download Pdf

Technical specifications

Customization guide

Adjustable parameters include span length, material grade (Q235/Q345), and insulation thickness to meet specific load requirements or climate conditions.

Get inspired

With its translucent roofing and open design, this structure creates a bright, airy workshop environment while cutting energy costs. The modular framework allows seamless expansion to accommodate growing operations.

Choose your model

Supplier's note

1. Technical Breakthroughs:

   • Translucent Polycarbonate Roofing: Reduces energy consumption by 40% via natural light.
   • Modular Steel Framework: Enables 20% faster installation than traditional models.
   • Multi-Standard Compliance: Meets global certifications (CE, ASTM, etc.) for seamless international deployment.

2. Version Selection Guide:

   • Base Model: Ideal for small workshops or light industrial use (e.g., assembly lines). Its Q235 steel ensures cost-effective durability.
   • Advanced Model: Suitable for medium-scale operations requiring higher load capacity (e.g., machinery storage). The Q345 steel and R-15 insulation optimize performance in moderate climates.
   • Pro Model: Designed for heavy industrial applications (e.g., manufacturing plants with cranes). Its triple-certified Q345 steel and R-25 insulation provide unmatched resilience and energy efficiency.

*Compared to industry benchmarks, the Pro Model’s load capacity exceeds standards by 30%, enabling safe handling of heavy equipment. Paired with polycarbonate roofing, it creates a bright, climate-controlled workspace.
