China custom made PCB manufacturing and Assembly electronic circuit board medical PCBA

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Medical Device Integration: Designed to support advanced surgical and diagnostic equipment, featuring a high-performance Atmel microcontroller for precise control and real-time data processing.
  • Power over Ethernet (POE) Compatibility: Enables simultaneous power and data transmission via Ethernet, streamlining setup in medical environments with limited power outlets.

Key features

  • 1. Advanced Material Technology for Enhanced Durability

    • With HASL (Hot Air Solder Leveling) surface finishing, you can ensure superior solder joint reliability and corrosion resistance in demanding medical environments. This technology outperforms unleaded or lower-quality finishes by providing a durable protective layer, extending the PCB’s lifespan.

  • 2. User-Centric Interactive Design with POE Integration

    • With Power over Ethernet (POE) capability, you can streamline setup in medical facilities by eliminating the need for separate power cables. The compact control unit with an intuitive touchscreen interface allows for easy operation, surpassing traditional non-POE devices that require complex wiring.

  • 3. Precision-Engineered Performance for Critical Applications

    • With Atmel microcontroller-based circuit design, you can achieve high-precision control and real-time data processing, ensuring accuracy in surgical or diagnostic workflows. This outperforms generic microcontrollers in reliability and speed for medical-grade applications.

  • 4. Compliance with Global Medical Safety Standards

    • With certifications like RoHS, UL, and EPR (Germany/France), you can meet stringent regulatory requirements for medical devices. These standards ensure eco-friendliness, electrical safety, and waste management compliance, surpassing non-certified alternatives.

  • 5. Customized Scalability for Diverse Medical Scenarios

    • With modular PCB assembly design, you can adapt the device for both clinical and surgical environments, supporting continuous operation or quick setup. This flexibility exceeds single-purpose systems, enabling use in hospitals, labs, or field deployments.

Product details

China custom made PCB manufacturing and Assembly electronic circuit board medical PCBA

China custom-made medical PCB assemblies combine precision engineering with compliance to global standards. Designed for surgical and diagnostic equipment, these boards feature robust Atmel microcontrollers, POE connectivity, and FR-4 material for reliability in critical healthcare environments.

Technical specifications

FeatureSpecificationBenefit
MaterialFR-4 epoxy glass substrateHigh thermal stability and durability
Surface FinishingHASL (Lead-free)Enhanced solderability and corrosion resistance
CertificationsEPR Germany/France Packing, REACH, UL, RoHSCompliance with global medical safety standards
ConnectivityPOE (Power over Ethernet)Simplified installation and power/data integration
MicrocontrollerAtmel-based (Customizable)Precise control for medical device functions

Customization guide

Adjustable parameters include PCB thickness (0.8mm–3.2mm), component density, and layer count (2–16 layers) to meet specific medical device requirements such as miniaturization or high-frequency signal processing.

Get inspired

Optimize your medical equipment with PCBAs engineered for precision. Whether for portable diagnostic tools or stationary surgical systems, our boards ensure seamless integration and compliance with rigorous healthcare standards.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Processing Power8-bit Atmel MCU32-bit Atmel SAM D2132-bit Atmel SAM L21 + AI co-processor
POE SupportBasic (15.4W)Enhanced (30W)Premium (90W)
Environmental RatingIP20IP54 (dust/waterproof)IP67 (full ingress protection)
Layer Count4 layers8 layers16 layers

Supplier's note

  1. Key Technical Breakthroughs:

    • POE Integration: Enables power/data delivery over Ethernet, reducing cabling complexity by 40% compared to traditional setups.
    • RoHS/EPR Compliance: Meets stringent EU environmental regulations, ensuring eligibility for European medical markets.
    • Atmel Microcontrollers: Offer 2x faster signal processing than legacy MCUs, critical for real-time diagnostics.

  2. Optimal Version Selection:

    • Base Model: Ideal for basic monitoring devices (e.g., patient vitals) where cost-efficiency is prioritized.
    • Advanced Model: Targets portable diagnostic tools requiring IP54 protection and higher power delivery (e.g., handheld ultrasound).
    • Pro Model: Designed for high-reliability applications like surgical robots, with IP67 ratings and AI capabilities for complex data analysis.

With POE compatibility, you can streamline medical device setups in cluttered environments. The Pro version’s 16-layer design ensures 30% faster signal transmission than industry benchmarks, making it ideal for time-sensitive applications.

Frequently asked questions

  • Which medical PCB assembly suits small diagnostic devices?

  • How do I clean and maintain medical circuit boards?

  • What materials are used in medical-grade PCBs vs standard PCBs?

  • Can I customize the design of a medical circuit board?

  • Is the PCB material FDA-approved for surgical devices?

  • What surface finishing options are available for medical PCBs?

  • Does the PCB support Power over Ethernet (POE) for hospitals?

  • What certifications ensure the PCB’s safety in medical environments?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Compliance CertificationsEU/US medical market entryIndustry Standard: RoHS, CE
Our Base: RoHS, CE, EPR Germany
Our Advanced: RoHS, CE, EPR Germany/France, REACH, UL ▲▲		Ensures regulatory compliance in stringent regions (e.g., EU RoHS, US FDA)Advanced certifications may increase production costs by ~15–20%
PCB Material QualityHigh-temperature medical devicesIndustry Standard: FR-4 (1.6mm, Tg 130°C)
Our Base: FR-4 (1.6mm, Tg 140°C) ▲
Our Advanced: High-TG FR-4 (1.6mm, Tg 170°C) ▲▲		Enhanced thermal stability for prolonged operation in MRI/CT environmentsAdvanced materials require specialized suppliers, extending lead times by 2–3 days
Surface FinishingMass production of fine-pitch componentsIndustry Standard: Lead-based HASL (IPC-6012)
Our Base: Lead-free HASL (IPC-7711) ▲
Our Advanced: ENIG (Electroless Nickel Immersion Gold) ▲▲		Lead-free compliance and compatibility with BGA/QFN componentsENIG finishing increases unit cost by ~$0.50–$1.00 per board
Operational NoiseICU/Operating RoomsIndustry Standard: 40 dBA (equivalent to quiet conversation)
Our Base: 35 dBA ▲ (quieter than whisper)
Our Advanced: 30 dBA ▲▲ (below human hearing threshold at 20kHz)		Reduces patient/staff distraction in critical care environmentsAdvanced noise dampening may add 0.5mm to board thickness
Power SolutionRemote medical stations without outletsIndustry Standard: Dedicated power supply
Our Base: POE (802.3af, 15.4W) ▲
Our Advanced: POE++ (802.3bt, 90W) ▲▲		Eliminates need for separate power cables, ideal for telemedicine cartsRequires POE-compatible switches and cabling infrastructure
Board ThicknessPortable diagnostic devicesIndustry Standard: 1.6mm
Our Base: 1.2mm ▲ (meets IPC-6012 Class 3)
Our Advanced: 0.8mm ▲▲ (lightweight for handheld use)		Enables compact device design (e.g., portable ultrasound scanners)Thinner boards may require reinforced edge plating for durability
