Copper Wire Hv Transformer Automatic Cabling Coil Winding Machine Electric Motor Winding Machine

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Automatic Winding Precision: Designed for high-voltage (HV) transformer and electric motor winding, enabling precise control over coil configuration, primary/secondary winding ratios, and turn counts via digital settings.
  • CNC Technology Integration: Equipped with CNC automation for consistent, repeatable production of copper wire coils, reducing manual intervention and errors.

Key features

  • 1. Material Technology

    • With CNC-machined metal construction, you can ensure precision and durability in heavy-duty industrial applications*

  • 2. Interactive Design

    • With programmable digital controls and foot pedal operation, you can customize winding parameters while maintaining hands-free adjustments*

  • 3. Performance Parameters

    • With automatic winding technology, you can achieve consistent output speeds of up to 120 coils per hour*

  • 4. Scenario Solutions

    • Designed for continuous commercial operation, this machine can handle 24/7 winding tasks without downtime*

  • 5. Certification Standards

    • Built to comply with industrial safety standards, ensuring reliable performance in regulated environments*

Product details

Copper Wire Hv Transformer Automatic Cabling Coil Winding Machine Electric Motor Winding Machine

The Copper Wire HV Transformer Automatic Cabling Coil Winding Machine is a precision-engineered CNC device designed for high-voltage transformer and electric motor manufacturing. Its robust metallic frame, programmable digital controls, and adjustable winding spools ensure consistent performance in industrial environments.

Technical specifications

FeatureSpecificationApplication Scenario
CNC ControlFully automated via digital interfacePrecise winding for transformer cores
Winding MechanismAdjustable spools (⌀10mm–⌀50mm)Custom material thickness compatibility
Digital DisplayParameters: Coil Type, Turns, SpeedReal-time monitoring of winding processes
Motor Power2.2kW, 380V ACHeavy-duty industrial use
CertificationsCE, RoHS, ISO 9001Compliance with global manufacturing standards

Customization guide

Adjustable spool sizes (⌀10mm–⌀50mm) and programmable parameters (turns, speed) allow customization for:

  • Material Type: Copper wire, aluminum cable, or insulated conductors.
  • Coil Design: Primary/secondary winding ratios via "Pri/Sec" settings.
  • Speed Control: Foot pedal for manual override during delicate adjustments.

Get inspired

With its CNC precision and dual-axis winding capability, this machine ensures uniform coil density for transformers, while the foot pedal provides hands-free control during complex setups. Ideal for manufacturers needing repeatability in high-voltage applications.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Winding Speed150 turns/min+20% (180 turns/min)+35% (200 turns/min)*
Precision Tolerance±0.5mm±0.3mm±0.1mm
Max Coil Diameter200mm250mm300mm
CertificationsCE, RoHS+ISO 14001+UL, IP54 Protection

Supplier's note

  1. Technical Breakthroughs:

    • CNC Automation: Reduces human error by 40% compared to manual winding.
    • Dual-Axis Control: Enables helical winding for high-current transformers.
    • Foot Pedal Integration: 20% faster setup adjustments in complex jobs.

  2. Version Selection Guide:

    • Base Model: Ideal for small workshops prioritizing cost-efficiency.
    • Advanced Model: Best for medium-scale production needing faster speeds and eco-compliance (ISO 14001).
    • Pro Model: Required for high-volume manufacturing or harsh environments (e.g., oil-resistant coils). Its ±0.1mm precision ensures flawless transformer cores for aerospace applications.

*Pro Model’s speed improvement validated against industry benchmarks (ISO 230-2).
