Custom Right Angle Double Row Double Plastic Pin Header 2x20P Gold Plated Brass 1.0mm Pitch Connector for Smart Home Appliance

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Performance Connectivity: A right-angle double-row pin header with 2x20 pins (40 contacts) designed for secure electrical connections in smart home appliances and electronic devices. The 1.0mm pitch ensures compatibility with standard PCB layouts.
  • Durability & Conductivity: Gold-plated brass contacts provide superior corrosion resistance, low contact resistance, and long-term reliability in high-frequency or high-power applications.

Key features

  • 1. Gold-Plated Brass Contacts for Superior Conductivity

    • With gold-plated brass contacts, you can achieve enhanced electrical conductivity and corrosion resistance compared to uncoated metal connectors*. The gold plating ensures stable performance in humid or high-temperature environments common in smart home appliances.

  • 2. Right-Angle Double-Row Design for Space Efficiency

    • The right-angle orientation and double-row configuration allow compact integration into tight spaces within smart home devices, optimizing board layout compared to straight connectors*. This design reduces physical interference in confined electronic systems.

  • 3. 1.0mm Pitch and Dual-Core Compatibility for High-Density Connections

    • With a 1.0mm pitch and support for dual-core connections, you can achieve high-density signal routing and faster data transfer rates than wider-pitch alternatives*. Ideal for smart home systems requiring efficient power and data transmission.

  • 4. Reliable Operation in Smart Home Environments

    • Designed specifically for smart home appliances, these connectors provide stable power and signal transmission in residential settings, minimizing downtime compared to general-purpose connectors*. The robust construction ensures durability against frequent use.

  • 5. Compliance with Industry Safety Standards

    • Constructed with brass and flame-retardant plastic materials, this connector meets safety and quality standards for electronic components, ensuring compliance with regulations for home appliances*.

Product details

Custom Right Angle Double Row Double Plastic Pin Header 2x20P Gold Plated Brass 1.0mm Pitch Connector for Smart Home Appliance

The Custom Right Angle Double Row Double Plastic Pin Header 2x20P Gold Plated Brass 1.0mm Pitch Connector is engineered for reliable connectivity in smart home appliances. With gold-plated brass contacts, you can ensure long-term conductivity and corrosion resistance in humid environments. Its 1.0mm pitch and right-angle design optimize space in compact devices, while dual-core support enables efficient power and data transmission.

Technical specifications

FeatureSpecificationApplication Scenario
Material CompositionBrass contacts (gold-plated), polyester insulation, plastic housingSmart home appliances requiring corrosion resistance and high conductivity
Pitch1.0mmCompatibility with standard PCB layouts
OrientationRight angleSpace-constrained designs in smart devices
CoresSingle-core/dual-core supportManaging power and data signals in appliances
Temperature Range-20°C to +85°CReliable operation in indoor environments

Customization guide

Adjustable pin count (from 2x20P) and spacing to meet specific PCB layout requirements. Custom latching mechanisms can be added for enhanced mechanical stability in vibration-prone applications.

Get inspired

Ideal for smart home devices like IoT controllers, smart plugs, and sensors. The right-angle orientation and compact design make it perfect for embedded systems where space is limited.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Contact Resistance10mΩ8.5mΩ (+15%)7mΩ (+30%)
Current Capacity2A2.3A2.6A
Operating Temp Range-20°C to +85°C-30°C to +90°C-40°C to +105°C
CertificationsULUL + RoHSUL + RoHS + IP67

Supplier's note

  1. Technical Breakthroughs:

    • Gold-plated brass contacts: 30% lower contact resistance than industry standards, ensuring signal integrity in high-frequency applications.
    • Right-angle design: 20% smaller footprint compared to standard headers, optimizing space in compact smart devices.
    • Dual-core capability: Simultaneously handles power and data signals, reducing the need for multiple connectors.

  2. Version Selection Guidance:

    • Base Model: Suitable for basic smart home appliances (e.g., LED controllers) with standard environmental conditions.
    • Advanced Model: Ideal for high-current devices (e.g., smart HVAC systems) requiring extended temperature ranges.
    • Pro Model: Best for industrial-grade smart home setups (e.g., outdoor sensors) needing IP67-rated dust/water resistance and extreme temperature tolerance.

With the Pro version’s IP67 rating, you can deploy connectors in outdoor smart home devices without compromising reliability. Pair its low contact resistance with dual-core support to handle both power and data seamlessly in IoT ecosystems.

Frequently asked questions

  • Which right angle pin header suits smart home appliances with limited space?

  • How to clean gold-plated brass pin headers to maintain conductivity?

  • Brass vs. Copper: Which material is better for smart appliance connectors?

  • Can I customize pin counts for a 2x20P header in smart home projects?

  • Is this gold-plated connector RoHS-compliant for smart home use?

  • Why choose a double row plastic pin header for smart home devices?

  • What’s the advantage of dual-core vs. single-core contacts in smart appliances?

  • Can this connector handle both power and data in smart home systems?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Material CompositionHigh-current industrial equipmentIndustry Standard: Steel (conductivity: 8.0 MS/m)
Our Base: Brass (17.0 MS/m▲)
Our Advanced: Gold-plated Brass (20.0 MS/m▲▲)		▲ Base: 112% higher conductivity than steel.
▲▲ Advanced: 15% better corrosion resistance.		▲ Base: 20% cost increase vs steel.
▲▲ Advanced: 40% premium for gold plating.
Contact MaterialData-sensitive devices (e.g., routers)Industry Standard: Tin-plated copper (resistance: 0.02Ω)
Our Base: Brass (0.015Ω▲)
Our Advanced: Gold-plated brass (0.01Ω▲▲)		▲ Base: 25% lower resistance.
▲▲ Advanced: 30% better signal integrity.		▲ Base: Requires stricter soldering.
▲▲ Advanced: Fragile plating during assembly.
OrientationCompact IoT devicesIndustry Standard: Straight (space efficiency: 1.0)
Our Base: Right Angle (1.5▲)
Our Advanced: Right Angle + 90° bend (2.0▲▲)		▲ Base: Saves 30% PCB space.
▲▲ Advanced: Enables vertical mounting.		▲ Base: 15% higher cost.
▲▲ Advanced: Limited compatibility with legacy systems.
Connector TypeModular smart home systemsIndustry Standard: Generic headers (locking: none)
Our Base: Pin headers (locking: optional)
Our Advanced: Latched pin headers (locking: mandatory▲)		▲ Advanced: 50% lower disconnection risk.
Base: Cost-effective for non-vibrational use.		Advanced: 25% bulkier than base.
Industry: Risk of accidental unplugging.
Core ConfigurationHigh-power appliances (e.g., HVAC)Industry Standard: Single-core (current: 2A)
Our Base: Dual-core (3.5A▲)
Our Advanced: Quad-core (5A▲▲)		▲ Base: Handles 75% more power.
▲▲ Advanced: Supports industrial-grade loads.		▲ Base: 20% heavier.
▲▲ Advanced: Requires thicker wiring.
PitchHigh-density PCB layoutsIndustry Standard: 1.25mm (density: 80 contacts/cm²)
Our Base: 1.0mm (100 contacts/cm²▲)
Our Advanced: 0.5mm (200 contacts/cm²▲▲)		▲ Base: 25% denser packing.
▲▲ Advanced: 150% higher component density.		▲ Base: Delicate solder joints.
▲▲ Advanced: Requires specialized tools.
