Custom Round 2.54pitch 360w Magnetic 8pin Pogo Pin Contacts 1mm 1.5mm 2.5mm 3mm 4mm Diameter 3a 12v Connector

Custom Round 2.54pitch 360w Magnetic 8pin Pogo Pin Contacts 1mm 1.5mm 2.5mm 3mm 4mm Diameter 3a 12v Connector

  • 20 - 99 Pieces
    $2
  • 100 - 999 Pieces
    $1.80
  • >= 1000 Pieces
    $1
View product details

Custom Round 2.54pitch 360w Magnetic 8pin Pogo Pin Contacts 1mm 1.5mm 2.5mm 3mm 4mm Diameter 3a 12v Connector

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Magnetic Power/Data Transfer: Enables secure, vibration-resistant connections for power (up to 3A/12V) and data via 8-pin pogo pin contacts, designed for PCB-mounted applications.
  • Versatile Connectivity: Supports multiple pin configurations (4p/5p) and diameters (1mm to 4mm), ensuring compatibility with diverse electronic devices and PCB layouts.

Key features

  • 1. Material Technology

    • With a brass-and-nylon construction and gold-plated pins, ensure durable, corrosion-resistant connections while maintaining high conductivity.

  • 2. Interactive Design

    • With a magnetic coupling mechanism, connect and disconnect effortlessly without manual alignment, ideal for frequent use in portable devices.

  • 3. Performance Parameters

    • With a 3A rated current and 12V compatibility, handle high-power applications like charging stations or industrial devices.

  • 4. Scenario Solutions

    • With customizable pin configurations (4p/5p) and diameters (1–4mm), adapt to PCB-mounted systems or portable electronics like smartphones and tablets.

  • 5. Certification Standards

    • With CE, RoHS, UL, and EPR certifications, meet global safety and environmental regulations for commercial and consumer use.

Product details

Custom Round 2.54pitch 360w Magnetic 8pin Pogo Pin Contacts 1mm 1.5mm 2.5mm 3mm 4mm Diameter 3a 12v Connector

The Custom Round 2.54pitch 360W Magnetic 8pin Pogo Pin Contacts are high-performance connectors designed for PCB mounting and cable integration. Built with a durable metal-plastic composite, they support up to 3A at 12V and feature a magnetic coupling mechanism for secure, vibration-resistant connections. Certified to global standards (CE, RoHS, UL), these connectors offer customizable pin configurations (5p/4p) and diameters (1mm–4mm) for versatile applications.

Technical specifications

FeatureSpecificationBenefit
MaterialBrass (gold-plated pins) + nylon housingEnhanced conductivity and corrosion resistance
Magnetic Coupling360° alignment-free connectionEasy integration and secure attachment
Rated Current3ASafe for high-power applications
Pitch2.54mmStandard compatibility with PCB layouts
Diameter Options1mm, 1.5mm, 2.5mm, 3mm, 4mmCustomizable to fit device requirements
CertificationsCE, RoHS, EPR_Germany_Packing, ULCompliance with global safety standards

Customization guide

Adjustable parameters include pin count (up to 8 pins), diameter, and magnetic strength to meet specific device requirements. Ideal for applications needing vibration-resistant connections (e.g., industrial tools) or compact designs (e.g., wearable electronics).

Get inspired

With a magnetic coupling mechanism, you can achieve quick, tool-free connections in portable devices. The gold-plated pins ensure long-term reliability in harsh environments. Whether designing a charging dock or a medical device, these connectors provide a secure, certified solution.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Rated Current3A4.5A (+50%)6A (+100%)
Magnetic StrengthStandardEnhanced (+30%)Premium (+60%)
Pin Configuration4p/5p fixedCustomizable pinsCustomizable pins + IP67 sealing
CertificationsCE, RoHSCE, RoHS, ULAll certifications + ISO 13485 (medical-grade)

Supplier's note

  1. Technical Breakthroughs:

    • Magnetic 360° Alignment: Eliminates manual alignment, reducing connection errors by 40% compared to traditional pogo pins.
    • Gold-Plated Pins: Achieves 99.9% conductivity, outperforming uncoated alternatives in corrosive environments.
    • Global Compliance: UL certification expands market access for North American industrial applications.

  2. Version Selection Guide:

    • Base Model: Ideal for standard electronics (e.g., consumer gadgets) requiring basic durability and cost-efficiency.
    • Advanced Model: Targets industrial IoT devices needing higher current handling and customizable pin layouts.
    • Pro Model: Best for medical or aerospace applications demanding IP67 sealing and medical-grade certifications. For example, the Pro’s 6A rating enables safe power delivery to high-drain sensors, while its magnetic strength ensures stability in turbulent environments.

Frequently asked questions

  • Which magnetic connector suits high-current applications like 3A at 12V for PCB mounting?

  • How do I clean the contacts of a magnetic pogo pin connector to maintain conductivity?

  • What materials make the 1mm-4mm diameter magnetic connectors durable for frequent use?

  • Can these magnetic pogo pin connectors be customized for 5-pin or 4-pin configurations?

  • Are these 360-degree magnetic connectors certified for EU and global standards?

  • What advantages do magnetic pogo pin connectors offer over traditional PCB headers?

  • Which connector diameter (1mm, 1.5mm, etc.) suits low-profile PCB designs?

  • Can these magnetic connectors handle both power and data transfer simultaneously?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Magnetic CouplingFrequent connections in portable devicesIndustry: Manual alignment; Base: Magnetic (ISO 14288); Advanced: 15% stronger ▲ (IEC 61076-2)Seamless plug-and-play; secure in vibrations; Advanced reduces misalignment riskBase may require closer alignment; Advanced adds cost ▲ (€5/unit)
Rated CurrentHigh-power devices (e.g., drones)Industry: 2A (IEC 60204); Base: 3A (IEC 60204); Advanced: 5A ▲ (66% ↑, UL 1950)Supports 3A continuous load; Advanced handles 5A for power toolsBase may limit high-current applications; Advanced requires thicker wiring ▲
Pin ConfigurationVariable pin-count needsIndustry: Fixed pins; Base: 4/5 pins; Advanced: Customizable ▲ (ISO 9311)Flexible for PCB/cable interfaces; Advanced allows 8 pins ▲ for data+power combosBase limits pin options; Advanced needs design collaboration ▲
Material CompositionHarsh environments (e.g., industrial)Base: Brass pins + nylon housing; Advanced: Gold-plated pins ▲ (ASTM B488)Corrosion resistance (Base: 500hr salt spray; Advanced: 1,000hr ▲)Base may degrade faster in chemical exposure; Advanced adds 20% cost ▲
CertificationsGlobal complianceBase: CE, RoHS; Advanced: Adds UL, EPR ▲ (IEC 60601 for medical)Base meets EU/Asia; Advanced unlocks US/medical markets ▲Base excludes UL/EPR; Advanced delays time-to-market by 2 weeks ▲
Customization OptionsOEM device integrationBase: Limited; Advanced: Full customization ▲ (pin shape, magnet strength)Advanced enables tailored solutions (e.g., 1mm–4mm diameters ▲); reduces assembly stepsBase requires off-the-shelf designs; Advanced demands NRE fees ▲
