DIODE POWER MODULE PD100N16 PD100N08 PD100N12 PD60N08 PD60N16
Ready to Ship
In stock Fast dispatch

DIODE POWER MODULE PD100N16 PD100N08 PD100N12 PD60N08 PD60N16

  • >= 1 Pieces
    $16
View product details

DIODE POWER MODULE PD100N16 PD100N08 PD100N12 PD60N08 PD60N16

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Power Diode Control: The PD100N16 series diode modules manage unidirectional current flow in high-voltage (up to 1600V) and high-current (up to 100A) applications, enabling efficient power conversion and motor control.
  • Thermal Efficiency: Robust epoxy construction and metal terminals ensure heat dissipation compatibility with heatsinks, maintaining reliability under continuous operation.

Key features

  • 1. Advanced Material Technology for Durability

    • With a heat-resistant epoxy composite and corrosion-resistant metal terminals, you can ensure reliable operation in high-temperature and high-current environments. The robust construction provides superior thermal stability compared to standard modules*.

  • 2. Modular Design for Seamless Integration

    • With a compact rectangular design and top-mounted terminals, you can easily integrate the module into control circuits or power systems for quick installation and maintenance. The standardized layout simplifies compatibility with existing setups.

  • 3. High-Performance Voltage and Current Ratings

    • With a 1600V voltage rating and 100A current capacity, you can handle demanding applications like industrial motor control or energy conversion. This exceeds the specifications of many mid-range semiconductor modules*.

  • 4. Versatile Scenario Solutions for Critical Applications

    • Designed for unidirectional current flow, you can deploy this module in scenarios requiring precise power regulation, such as inverters, rectifiers, or energy management systems. Its rugged build supports continuous operation in commercial or industrial settings.

  • 5. Certified Safety and Reliability

    • With UL certification, you can ensure compliance with global safety and performance standards. This guarantees reliable operation while minimizing risks in high-stakes power electronics systems.

Product details

DIODE POWER MODULE PD100N16 PD100N08 PD100N12 PD60N08 PD60N16

The DIODE POWER MODULE series (PD100N16, PD100N08, PD60N16, etc.) is a robust thyristor-based semiconductor solution designed for high-power applications requiring unidirectional current flow. Built with heat-resistant epoxy and metal terminals, these modules ensure reliable performance in motor control, power conversion, and energy management systems.

Technical specifications

FeatureSpecificationBenefit
Voltage Rating800V–1600V (model-dependent)Supports high-voltage applications
Current Rating60A–100A (model-dependent)Handles heavy load demands
MaterialEpoxy composite + copper/aluminumDurable, heat-resistant construction
Terminals3 terminals (input/output/control)Easy integration into control circuits
CertificationUL-listedMeets global safety and performance standards
Thermal DesignHeatsink-compatibleEnsures efficient heat dissipation

Customization guide

Adjustable parameters include voltage/current ratings and terminal configurations to meet specific industrial needs (e.g., custom voltage thresholds for specialized power grids).

Get inspired

With the PD100N16’s 1600V rating, you can safely power industrial motors in harsh environments. The PD60N16’s compact design simplifies integration into space-constrained inverters.

Choose your model

ParameterBase Model (PD60N16)Advanced Model (PD100N12)Pro Model (PD100N16)
Voltage Rating1600V1200V1600V
Current Rating60A100A100A
Thermal Resistance0.15°C/W0.12°C/W*0.09°C/W*
Package Size60mm x 40mm80mm x 50mm100mm x 60mm

Supplier's note

  1. Technical Breakthroughs:

    • UL Certification: Ensures compliance with global safety standards, reducing compliance risks.
    • Enhanced Thermal Design: The Pro Model’s 0.09°C/W thermal resistance outperforms industry benchmarks by 30%, enabling stable operation in high-heat environments.
    • Modular Compatibility: Universal terminal layouts simplify retrofitting into existing systems.

  2. Optimal Version Selection:

    • Base Model (PD60N16): Ideal for residential inverters or low-power industrial systems needing 1600V resilience.
    • Advanced Model (PD100N12): Perfect for mid-range applications like HVAC systems requiring 1200V/100A performance.
    • Pro Model (PD100N16): Designed for heavy industrial machinery (e.g., electric vehicle chargers) where 1600V/100A and superior heat dissipation are critical.

With the Pro Model’s tripled thermal efficiency compared to legacy designs, you can achieve uninterrupted operation in extreme conditions. Pair its high voltage rating with robust epoxy material to ensure longevity in corrosive or high-vibration environments.

Frequently asked questions

  • Which diode module model suits high-voltage industrial applications (e.g., motor control systems)?

  • How do I ensure proper thermal management for PD series diode modules?

  • What materials make PD60N08/PD100N12 modules suitable for power conversion systems?

  • Can PD series diode modules be customized for specific control circuits?

  • Is the PD100N16 diode module UL-certified for safety compliance?

  • Which PD module (PD60N16 vs PD100N16) is better for 1200V solar inverters?

  • What makes thyristor modules like PD100N12 suitable for rectifier circuits?

  • How do I install PD series modules to avoid overheating?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
High Voltage Diode ModulesIndustrial power systems, energy gridsVoltage Rating: 1600V (PD100N16) ▲ vs Industry Standard (1200V)Handles extreme voltages (e.g., industrial power grids)Larger physical size and higher cost compared to lower-voltage variants
High Current Diode ModulesHeavy machinery, motor controlCurrent Capacity: 100A (PD100 Series) ▲ vs Industry Standard (80A)Supports high-power applications (e.g., industrial motors)Requires robust heatsinks for thermal management
Thermal Management ModulesHigh-heat environments (e.g., inverters)Heat Dissipation: Epoxy resin with UL94 V-0 certification (ISO 7637 compliant)Reliable operation in extreme temperatures (up to 150°C)Requires external heatsinks for peak performance
Compact Diode ModulesConsumer electronics, portable devicesCompact Design: PD60 Series (30% smaller than PD100) ▲ vs Industry StandardSpace-saving for tight spaces (e.g., handheld tools)Lower voltage/current capacity (60A/800V max)
Safety-Certified Diode ModulesSafety-critical systems (e.g., medical)UL Listed (Underwriters Laboratories) certification ▲ vs Non-certified variantsMeets global safety standards (e.g., fire resistance)Slightly higher upfront cost
Cost-Effective Diode ModulesBudget projects, prototypingPD60N08: 60A/800V at 30% lower cost ▲ vs Competitor’s Base ModelEconomical for low-power applications (e.g., small appliances)Limited scalability for high-power or high-voltage needs
