Electrical Symbol and Function of Surge Arrester

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Overvoltage Protection: Designed to safeguard electrical systems against damaging surges caused by lightning strikes or switching operations by diverting excess voltage to ground.
  • Zinc Oxide Technology: Utilizes zinc oxide-based components for efficient energy absorption and rapid response to transient overvoltages, ensuring prolonged equipment longevity.

Key features

  • 1. Zinc Oxide Material Technology for Enhanced Protection

    • With zinc oxide as the core material, this surge arrester provides superior protection against overvoltages compared to traditional silicon carbide models*. The nonlinear voltage-current characteristics of zinc oxide ensure rapid response and effective clamping of transient surges, safeguarding electrical systems in harsh environments.

  • 2. Cylindrical Design with Concentric Rings for Optimal Electrical Stress Distribution

    • The concentric ring design minimizes flashover risks by evenly distributing electrical stress, outperforming flat or non-patterned arrester designs*. This ensures reliable operation under high-voltage conditions and extends the product’s lifespan in outdoor or industrial settings.

  • 3. High-Voltage Compatibility for Diverse Applications

    • With a clamping voltage rating up to 150% of nominal system voltage, this arrester can handle extreme overvoltages caused by lightning or switching—20% more effectively than basic surge protectors*. It is compatible with high-voltage systems up to 35kV, making it ideal for both commercial grids and industrial installations.

  • 4. Adaptable for Residential and Commercial Use

    • Designed for seamless integration into power distribution networks, this surge arrester balances compact size with robust performance. Its red ceramic body and metallic base ensure visibility and durability, enabling reliable protection in both residential substations and large-scale commercial facilities.

  • 5. Compliance with International Safety and Environmental Standards

    • Manufactured to meet IEC 60099-4 and ISO 14001 certifications*, this surge arrester ensures safety and eco-friendly material usage. The zinc oxide core reduces environmental impact compared to lead-based alternatives, aligning with global sustainability initiatives.

Product details

Electrical Symbol and Function of Surge Arrester

The Surge Arrester is a critical component for safeguarding electrical systems against overvoltages caused by lightning strikes or switching operations. Constructed with zinc oxide (ZnO) as the core material and a durable ceramic/composite body, it ensures reliable protection while maintaining structural integrity under extreme conditions.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialZinc Oxide (ZnO) core, ceramic bodyHigh-voltage power distribution systems
DesignCylindrical with concentric ringsReduces flashover risk in outdoor environments
Base ConstructionMetallic (steel/aluminum) groundingEnsures robust grounding in industrial setups
Voltage RatingCustomizable (e.g., 72kV, 145kV)Protects substations and transmission lines

Customization guide

Adjustable parameters include voltage rating (to match system requirements) and physical dimensions (for space-constrained installations). For specialized needs, the ceramic body can be reinforced with UV-resistant coatings to enhance durability in harsh climates.

Get inspired

With its zinc oxide core, this surge arrester provides ultra-fast response to overvoltages, protecting sensitive equipment like transformers and circuit breakers. Its concentric ring design ensures even voltage distribution, making it ideal for high-stakes industrial and utility applications.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Voltage Rating72kV145kV220kV
Response Time2μs1.5μs (+25%)1μs (+50%)*
Durability10-year lifespan15-year lifespan20-year lifespan
Weight15kg20kg25kg

*Comparative improvement over industry benchmarks.

Supplier's note

  1. Key Technical Breakthroughs:

    • Zinc Oxide Core: Achieves 30% lower clamping voltage than traditional silicon carbide models, minimizing residual voltage damage.
    • Concentric Ring Design: Reduces surface flashover risk by 40% in humid environments.
    • Metallic Base: Ensures 99.9% grounding efficiency, critical for high-current dissipation.

  2. Optimal Version Selection:

    • Base Model: Ideal for residential or low-voltage commercial systems (e.g., small substations).
    • Advanced Model: Suitable for medium-voltage industrial grids, offering 25% faster response than competitors.
    • Pro Model: Designed for extreme conditions (e.g., offshore wind farms), with a 220kV rating and 50% longer lifespan than industry standards.

With the Pro version’s 220kV rating, you can safeguard critical infrastructure against the most severe lightning surges. Pair its zinc oxide core with the reinforced ceramic body to ensure uninterrupted operation in corrosive coastal environments.
