Electronic Circuit Board Inverter Pcb With Enclosure Assembly and Components Procurement Electronic Circuit

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Power DC/AC Conversion: Designed to handle output power ranging from 1kW to 200kW, enabling efficient conversion between DC and AC power for applications like compressors, industrial machinery, and renewable energy systems.
  • Multi-Output Flexibility: Supports multiple output types (AC, DC, VFD) to accommodate diverse operational requirements, such as motor speed control, voltage regulation, and energy distribution.

Key features

  • 1. Advanced Material Technology

    • With a corrosion-resistant FR-4 PCB material, ensure long-term durability in industrial environments prone to moisture or chemical exposure.

  • 2. Customizable Interactive Design

    • With a multi-program VFD (Variable Frequency Drive) interface, adjust output parameters (voltage, frequency, and speed) to match compressor-specific requirements.

  • 3. High-Power Performance

    • With an output range of 1-200kW, handle heavy-duty industrial loads, such as large compressors, exceeding the capacity of traditional inverters (typically ≤50kW).

  • 4. Scenario-Specific Optimization

    • With compressor-optimized design, reduce energy waste and improve efficiency in industrial cooling or HVAC systems.

  • 5. Robust Protection Standards

    • With an IP65-rated enclosure and built-in overcurrent/overvoltage protection, ensure safe operation in dusty or wet environments.

Product details

Electronic Circuit Board Inverter Pcb With Enclosure Assembly and Components Procurement Electronic Circuit

The Electronic Circuit Board Inverter PCB with Enclosure Assembly is a high-performance inverter solution designed for compressor applications, offering output power from 1kW to 200kW. Built with robust components like FR-4 PCB material, advanced motor control ICs, and integrated protection circuits, this inverter ensures reliable operation in industrial, automotive, and robotics environments.

Technical specifications

FeatureSpecificationBenefit
Power Range1–200 kWSupports diverse applications from small compressors to heavy industrial machinery
Component DesignFR-4 PCB, high-current inductors,Ensures thermal stability and long-term durability
multi-layer capacitors, motor control
ICs
Protection FeaturesOvercurrent, overvoltage, short-circuitPrevents system damage in harsh operating conditions
Output TypeAC/DC/VFD compatibleFlexible compatibility with multiple motor types
Enclosure AssemblyIP54-rated, heat-dissipating designSafeguards against dust, moisture, and overheating

Customization guide

Adjustable parameters include:

  • Input/Output Voltage: Tailor to 12V–600V DC or AC systems for specialized power requirements.
  • Protection Thresholds: Customize overcurrent/overvoltage limits to match specific motor tolerances.
  • Connector Configurations: Modify I/O ports for seamless integration into robotics or EV systems.

Get inspired

This inverter is ideal for industrial compressors needing precise speed control or electric vehicles requiring efficient power conversion. Its modular design allows easy scaling from 1kW lab prototypes to 200kW industrial setups.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Max Power Handling100 kW150 kW200 kW
Efficiency92%94%96%
Protection FeaturesBasic (OC/OV)Enhanced (OC/OV/SG)Full (OC/OV/SG/TP)
Weight5.2 kg6.8 kg8.5 kg
CertificationsIEC 60727IEC 60727 + ULIEC 60727 + UL + CE

Supplier's note

  1. Technical Breakthroughs:

    • High-Power Scalability: The Pro Model’s 200kW capacity (30% higher than industry benchmarks) enables reliable operation in heavy industrial compressors.
    • Advanced ICs: Motor control ICs with real-time PWM optimization reduce energy loss by 25% compared to traditional designs.
    • Triple Protection Layers: The Pro Model’s thermal + electrical + signal safeguards ensure zero downtime in harsh environments.

  2. Version Selection Guide:

    • Base Model: Ideal for small workshops or HVAC systems requiring up to 100kW.
    • Advanced Model: Best for medium-scale industrial compressors needing 150kW and enhanced signal integrity.
    • Pro Model: Tailored for heavy machinery, EV drivetrains, or robotics demanding peak performance and full protection.

With its 96% efficiency, the Pro Model cuts energy costs by 20% versus legacy systems. Pair it with high-temperature capacitors for uninterrupted operation in foundries or mining equipment.

Frequently asked questions

  • Which inverter PCB model is best suited for high-power compressor systems?

  • How do I maintain the inverter PCB’s inductors and capacitors for longevity?

  • FR-4 vs. aluminum PCBs: Which is better for industrial inverters?

  • Can this inverter PCB be customized for specific compressor voltage requirements?

  • Is the PCB’s material compliant with industrial safety standards?

  • How does the 1-200kW output range benefit compressor applications?

  • What components ensure reliability in high-voltage inverter PCBs?

  • Why choose this inverter PCB for robotics and electric vehicle compressors?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Power Handling CapacityIndustrial compressors, heavy machineryIndustry Standard: 100kW max (IEC 61800-3)Our Base: 150kW (▲1.5x)Our Advanced: 200kW (▲2x)
Energy EfficiencyHVAC systems, energy-sensitive industriesIndustry Standard: 85% efficiency (EN 50598)Our Base: 90% (▲5%)Our Advanced: 95% (▲10%)
Output FlexibilityRobotics, multi-motor automationIndustry Standard: 3 outputs (IEC 61800-3)Our Base: 5 outputs (▲66%)Our Advanced: 10 outputs (▲200%)
Protection FeaturesHarsh industrial environmentsIndustry Standard: Overcurrent (IEC 60335-1)Our Base: +Overvoltage (▲1 feature)Our Advanced: +Thermal (▲2 features)
Component QualityVibration-prone settings (e.g., mining)Industry Standard: Standard components (ISO 9001)Our Base: High-grade inductors/caps (▲20% lifespan)Our Advanced: FR-4 reinforced PCB (▲30% durability)
Customization OptionsElectric vehicles, bespoke systemsIndustry Standard: Fixed voltage (UL 1741)Our Base: 200-480V adjustable (▲2x range)Our Advanced: Fully programmable (▲Full adaptability)
