Epileds Chip High Power Red Led Diode 1w 2w 3w 620nm 640nm 650nm 660nm Led
Ready to Ship
In stock Fast dispatch

Epileds Chip High Power Red Led Diode 1w 2w 3w 620nm 640nm 650nm 660nm Led

$0.50-$20.00/ Piece|20 Piece/Pieces(Min. Order)

Customization:

Customized logo（Min.Order: 50000 pieces）
View product details

Epileds Chip High Power Red Led Diode 1w 2w 3w 620nm 640nm 650nm 660nm Led

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Power Lighting: Designed to deliver intense red light (620nm–660nm wavelengths) for high-brightness applications, supporting power outputs of 1W, 2W, and 3W.
  • Advanced Thermal Management: Features a gold-plated metal substrate and heat-dissipating leads to ensure stable performance in high-temperature environments.

Key features

  • 1. Advanced Material Technology

    • With InGaN semiconductor material and gold-plated thermal substrate, achieve high luminous efficiency and superior heat dissipation. The

Product details

Epileds Chip High Power Red Led Diode 1w 2w 3w 620nm 640nm 650nm 660nm Led

Epileds Chip High Power Red LED Diodes are engineered for high-brightness applications, featuring InGaN chip technology and robust thermal management. Available in 1W, 2W, and 3W configurations (620nm–660nm wavelengths), these LEDs deliver reliable performance in harsh environments. Their gold substrate and epoxy housing ensure durability, while customizable power and wavelength options cater to diverse industrial and commercial needs.

Technical specifications

FeatureSpecificationBenefit
Chip MaterialInGaNEnhanced efficiency and longevity
Power Range1W, 2W, 3WScalable solutions for varying light demands
Emitting ColorRed (620nm–660nm), Tri-color (R/B/G)Versatile for signage, lighting, and displays
Thermal ManagementGold substrate with 30% lower resistanceMaintains stability in high-temperature environments
Dimensions5mm x 5mmEasy integration into compact systems
Warranty3 yearsGuaranteed reliability

Customization guide

Adjustable parameters:

  • Power Output: Choose between 1W, 2W, or 3W to match energy requirements.
  • Wavelength: Select from 620nm–660nm for precise color tuning in lighting or signaling systems.
  • Color Configuration: Opt for monochromatic red or tri-color (red/blue/green) for multi-functional setups.

Get inspired

Epileds High Power LEDs combine cutting-edge materials and thermal engineering to deliver unmatched brightness and durability. Ideal for automotive lighting, industrial machinery, or smart building systems, these diodes ensure consistent performance even under prolonged use.

Choose your model

ParameterBase Model (1W)Advanced Model (2W)Pro Model (3W)
Power Output1W2W3W
Thermal Resistance0.5°C/W0.4°C/W (+20%)0.3°C/W (+40%)
Luminous Flux100 lm180 lm (+80%)250 lm (+150%)
Color RangeRed (620–660nm)Red + Tri-colorFull spectrum

Supplier's note

  1. Technical Breakthroughs:

    • InGaN Chip Technology: Enables 20% higher luminous efficiency compared to standard aluminum-based LEDs.
    • Gold Substrate Design: Reduces thermal resistance by 30%, outperforming industry benchmarks.
    • Custom Wavelength Tuning: Precise 620–660nm red spectrum for optimal visibility in safety signage.

  2. Version Selection Guidance:

    • Base Model (1W): Ideal for general lighting or low-power signaling systems (e.g., exit signs).
    • Advanced Model (2W): Suitable for industrial equipment interfaces or mid-range automotive applications.
    • Pro Model (3W): Designed for high-stress environments like mining machinery or outdoor advertising, where triple the industry-standard thermal resistance ensures longevity.

With the Pro Model’s 3W output and gold substrate, you can achieve 250 lm of consistent light in harsh conditions. Pair its 660nm wavelength with smart sensors to create energy-efficient agricultural lighting systems.

Frequently asked questions

  • Which Epileds Chip High Power Red LED Diode model (1W, 3W) suits small-scale industrial lighting?

  • How to maintain thermal performance of Epileds High Power LEDs in high-temperature settings?

  • What are the advantages of InGaN chip material in Epileds Red LEDs vs. sapphire-based LEDs?

  • Can Epileds Red LEDs be customized for specific wavelengths (e.g., 660nm) in horticulture setups?

  • Is the Epileds 3W Red LED IP-rated for outdoor use?

  • How does the Epileds Red LED’s gold substrate improve longevity vs. aluminum-based LEDs?

  • Which Epileds LED wavelength (640nm vs. 660nm) is best for automotive brake lights?

  • Does Epileds offer tri-color (RGB) LED arrays using the same InGaN chip technology?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
High-Power LEDIndustrial lighting, outdoor signage1-3W (IEC 60598-1 compliant) ▲ Advanced: 3W (3x higher than Base)Supports brighter applications (e.g., streetlights)Higher energy consumption at 3W; requires robust power supplies
Thermal ManagementHigh-temperature environmentsGold substrate with <50°C thermal resistance (ASTM E1461)Maintains performance in extreme heat (e.g., automotive lighting)Requires external heat sinks for sustained high-power use
Color OptionsCustom lighting solutionsTri-color (Red/Blue/Green) or single Red (620–660nm)Versatile for RGB applications (e.g., advertising displays)Tri-color versions may complicate circuit design
Material QualityHarsh industrial settingsInGaN chip (Enhances efficiency under stress) ▲ Advanced: 50% higher durability (ASTM D543)Longer lifespan in corrosive or high-vibration environmentsAdvanced versions may incur higher upfront costs
WarrantyLong-term installations3-year warranty (Industry standard: 1–2 years)Extended coverage for reliability in critical infrastructureLimited to standard usage conditions (e.g., no extreme humidity/temperature)
DurabilityOutdoor/industrial settingsGold leads resist oxidation (ASTM B117 salt spray test)Withstands environmental exposure (e.g., marine or construction sites)Higher susceptibility to physical shock compared to epoxy-encased LEDs
