Quality Fully Automatic Flat Edge Wise Common Mode Inductors Rectangular Wire Magnet Coil Toroid Winding Machine
Ready to Ship
In stock Fast dispatch

Quality Fully Automatic Flat Edge Wise Common Mode Inductors Rectangular Wire Magnet Coil Toroid Winding Machine

  • 1 - 4 Sets
    $22,800
  • >= 5 Sets
    $21,000

Customization:

Customized logo（Min.Order: 100 pieces）
Customized packaging（Min.Order: 100 pieces）
Graphic customization（Min.Order: 100 pieces）
View product details

Quality Fully Automatic Flat Edge Wise Common Mode Inductors Rectangular Wire Magnet Coil Toroid Winding Machine

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Automated Coil Winding: Designed to precisely wind rectangular wire magnet coils and common mode inductors onto toroid cores using CNC technology and PLC-controlled automation.
  • Multi-Component Handling: Capable of processing flat-edge wise configurations for transformers and inductors, ensuring high precision and consistency in magnetic component manufacturing.

Key features

  • 1. Robust Metal Construction for Durability

    • With a corrosion-resistant steel/aluminum body, this machine ensures long-term reliability in industrial environments. Its rugged design outperforms models using less durable materials*, offering consistent performance even under heavy use.

  • 2. Intuitive Touchscreen PLC Controller for Seamless Operation

    • With a programmable touchscreen interface and PLC controller, you can easily customize winding programs and monitor real-time operations. This modern design reduces reliance on manual adjustments compared to traditional control panels*, streamlining workflow efficiency.

  • 3. High-Speed CNC Precision for Enhanced Output

    • Powered by CNC technology, this machine achieves precise winding speeds up to 20% faster than manual or semi-automatic alternatives*. Its automated processes ensure consistent torque and alignment, ideal for high-volume production of toroid coils and magnet cores.

  • 4. Modular Design for Versatile Manufacturing Applications

    • With a modular construction, the machine can be customized to handle diverse tasks such as winding rectangular wires for common mode inductors or toroidal coils. This adaptability makes it suitable for both standard and specialized industrial applications*, unlike rigid, single-purpose equipment.

  • 5. Safety-Compliant Features for Industrial Use

    • Equipped with safety interlocks and status warning lights (red/green indicators), the machine meets rigorous industrial safety standards*. These features prevent unauthorized access to moving parts and alert operators to potential hazards, ensuring safe operation in commercial settings.

Product details

Quality Fully Automatic Flat Edge Wise Common Mode Inductors Rectangular Wire Magnet Coil Toroid Winding Machine

The Fully Automatic Flat Edge Wise Common Mode Inductors Rectangular Wire Magnet Coil Toroid Winding Machine is a CNC-driven, PLC-controlled industrial solution designed for precision winding of toroidal coils. Its robust steel/aluminum construction, modular design, and automated processes ensure efficiency in manufacturing common mode inductors for electronics, automotive, and power supply applications.

Technical specifications

FeatureSpecificationApplication Scenario
Control SystemPLC Controller with touch screenProgrammed automation for complex winding tasks
MaterialCNC-machined steel/aluminumHarsh industrial environments with durability
Automation TypeFully automaticHigh-volume production of standardized coils
ModularityAdjustable winding parametersCustom coil dimensions and wire types
Safety FeaturesInterlocked transparent panel, status lightsOperator safety during high-speed operations

Customization guide

Adjustable parameters such as wire diameter (0.1–2.5mm), coil height (5–50mm), and winding speed (adjustable via PLC) allow customization to meet specific inductor requirements.

Get inspired

With its CNC precision and PLC programmability, this machine automates coil winding processes, reducing manual intervention and ensuring consistent quality for applications like power supplies, transformers, and automotive electronics.

Choose your model
