GWY-0618 High-tech Shuttle Toroidal Transformer Automatic Winding Machine Floor Type Inductor Winding Machine

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Automated Winding Process: High-precision CNC-driven winding/rewinding of toroidal transformers and inductors, enabling consistent coil formation with adjustable speed and tension control via a digital interface.
  • Multi-Spool Material Handling: Three modular spools accommodate simultaneous loading, processing, and unloading of cylindrical materials (e.g., wire, cable, tape), streamlining workflows for diverse applications.

Key features

  • 1. Corrosion-Resistant Metallic Frame

    • Material Technology

  • 2. Intuitive Digital Control Panel

    • Interactive Design

  • 3. High-Speed Automated Winding

    • Performance Parameters

  • 4. Modular Design for Versatile Applications

    • Scenario Solutions

  • 5. Safety-Certified Guard Systems

    • Certification Standards

Product details

GWY-0618 High-tech Shuttle Toroidal Transformer Automatic Winding Machine Floor Type Inductor Winding Machine

The GWY-0618 High-tech Shuttle Toroidal Transformer Automatic Winding Machine is a CNC-driven, fully automated floor-type system designed for precision winding of toroidal transformers, inductors, and other cylindrical components. Built with a sturdy metallic frame and modular components, it ensures stability, efficiency, and adaptability across industries like electronics, automotive, and construction.

Technical specifications

FeatureSpecificationApplication Scenario
CNC ControlYes (5-axis precision)High-precision transformer core winding
Automation LevelFully automatic with digital interfaceMass production of standardized coils
Material HandlingCopper/Aluminum wires (0.1-3.0mm dia.)Custom inductor fabrication for aerospace
Spindle Capacity3 adjustable spoolsConcurrent winding of multiple materials
Accuracy±0.01mmSensitive electronics component assembly
Speed Range0-300 RPMBalancing speed and precision in winding
Safety FeaturesGuarded spindles + emergency stopSafe operation in industrial workshops
Modular DesignAdjustable spindle positionsCustom setups for non-standard projects

Customization guide

Adjustable parameters include winding speed (0-300 RPM), wire tension, and spindle alignment to accommodate materials like thin enameled wires or thick copper strands.

Get inspired

With CNC precision, you can achieve consistent coil dimensions for high-voltage transformers. With fully automatic operation, you can streamline production in automotive manufacturing. With modular spindles, you can adapt to custom inductor designs for IoT devices.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Winding Speed200 RPM250 RPM (+25%)300 RPM (+50%)
Accuracy±0.02mm±0.015mm±0.01mm
Spindle Capacity2 spools3 spools4 spools
Max Load500 kg800 kg1,000 kg
AutomationBasic autoFull autoFull auto + AI
Safety ComplianceISO 13849-1ISO 13849-1 + CEISO 13849-1 + UL

Supplier's note

  1. CNC Precision: The Pro model’s ±0.01mm accuracy exceeds industry standards by 50%, enabling flawless windings for medical equipment.
  2. Modular Spindles: The Advanced model’s 3-spindle setup reduces downtime by 30% in multi-material projects.
  3. AI Integration: The Pro’s AI-driven tension control adapts to material stiffness, cutting waste by 20% in high-volume production.

Version Selection Guide:

  • Base Model: Ideal for small workshops needing cost-effective, basic automation (e.g., low-volume transformer cores).
  • Advanced Model: Best for medium-scale production requiring multi-spindle flexibility (e.g., automotive sensor coils).
  • Pro Model: Suited for high-volume, precision-critical applications (e.g., aerospace-grade inductors). Pair its UL-certified safety features with its AI controls to ensure zero-defect output in hazardous environments.

Frequently asked questions

  • Which model is suitable for high-volume toroidal transformer production?

  • How often should the CNC components be lubricated for optimal performance?

  • What materials can this machine handle compared to standard winding machines?

  • Can this machine be customized for different coil thicknesses or materials?

  • Is the machine’s material compliant with ISO standards for industrial machinery?

  • How does the automatic winding feature improve efficiency compared to manual methods?

  • What safety features ensure operator safety during high-speed winding?

  • What makes this floor-type machine more efficient than benchtop models?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Control SystemPrecision transformer manufacturing▲ CNC precision control (±0.01mm accuracy) vs Industry Standard’s manual controls▲ Reduces human error by 40% (ISO 9283 compliance)Higher initial cost vs Industry Standard
Automation LevelMass production lines▲▲ Fully automatic winding (ISO 9283) vs Base’s semi-automatic▲▲ 50% faster cycle time vs Industry Standard (ASTM D543)Requires skilled technicians for setup
Material HandlingHeavy-duty industrial applications▲ 200kg load capacity (EN 1343) vs Industry Standard’s 100kg▲ Handles toroidal cores up to 1m diameter (IEC 60289)Larger footprint compared to Base model
Precision ToleranceAerospace component production▲▲ ±0.005mm tolerance (ASTM E8/E9) vs Base’s ±0.01mm▲▲ Meets NASA-grade specs for high-precision coilsIncreased maintenance frequency due to tighter tolerances
Safety FeaturesHigh-risk manufacturing environments▲ Automated emergency stop (ISO 13849) vs Base’s manual override▲ Reduces accident risk by 60% (OSHA compliance)Adds complexity to operation protocols
CustomizationCustom transformer prototyping▲▲ Modular design (ISO 9001) vs Industry Standard’s fixed configurations▲▲ Adapts to 10+ coil geometries (IEC 60148)Requires 20% longer setup time vs non-modular systems
