HPGL DXF PLT File Formats Support CAD Inkjet Paper Pattern Graph Contour Plotter
Ready to Ship
In stock Fast dispatch

HPGL DXF PLT File Formats Support CAD Inkjet Paper Pattern Graph Contour Plotter

  • 1 - 4 Sets
    $1,429
  • 5 - 19 Sets
    $1,379
  • 20 - 99 Sets
    $1,329
  • >= 100 Sets
    $1,229
View product details

HPGL DXF PLT File Formats Support CAD Inkjet Paper Pattern Graph Contour Plotter

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Multi-Format Compatibility: Supports HPGL, DXF, and PLT file formats for seamless integration with CAD software, enabling precise contour plotting and pattern graph generation.
  • High-Volume Wide-Format Printing: Designed to handle large rolls of materials like aluminum-backed inkjet paper, vinyl, and other substrates, producing detailed prints for industrial and commercial applications.

Key features

  • 1. Industrial-Grade Aluminum Alloy Body

    • With an industrial-grade aluminum alloy body, ensure durability in harsh environments compared to plastic-based models*. The corrosion-resistant material guarantees long-term stability and resistance to wear, ideal for commercial and industrial settings.

  • 2. User-Friendly Touchscreen Interface

    • With a touchscreen interface, access multi-program presets for seamless operation, reducing setup time by up to 30%* compared to traditional button-based controls. Simplify complex tasks like file format adjustments (HPGL, DXF, PLT) and printing parameters.

  • 3. High-Speed Printing Capabilities

    • With a high-resolution print head and optimized ink delivery system, achieve rapid output speeds for large-format prints, up to 20% faster than standard wide-format printers*. Handle high-volume projects efficiently without compromising on detail quality.

  • 4. Versatile Scenario Adaptability

    • Designed for continuous 24/7 operation, maintain output stability in commercial settings, ideal for high-demand environments like apparel manufacturing or architectural drafting. Compatible with diverse materials (paper, vinyl, etc.), ensuring adaptability across industries.

  • 5. Eco-Friendly Ink Solutions

    • Equipped with eco-friendly water-based inks, meet environmental safety certifications, surpassing solvent-based alternatives in sustainability*. Reduce environmental impact while maintaining vibrant, fade-resistant print quality.

Product details

HPGL DXF PLT File Formats Support CAD Inkjet Paper Pattern Graph Contour Plotter

The HPGL DXF PLT File Formats Support CAD Inkjet Paper Pattern Graph Contour Plotter is a robust industrial-grade large format printer designed for high-volume, precision printing on wide rolls of paper, vinyl, and other substrates. Built with an aluminum frame for durability, it supports advanced file formats (HPGL, DXF, PLT) and offers versatile customization options for commercial and industrial applications.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialAluminum frame with plastic componentsEnsures structural integrity in heavy-use environments
Print Resolution1200 x 1200 dpiIdeal for detailed CAD designs and contour plots
Media CompatibilitySupports paper, vinyl, and synthetic materialsVersatile for banners, apparel patterns, and signage
File FormatsHPGL, DXF, PLTSeamless integration with CAD software for engineering and apparel industries
Maximum Media Width60 inches (1524mm)Handles large-format prints for posters and industrial patterns

Customization guide

Adjustable parameters:

  • Media width: Customizable up to 60 inches to accommodate specialized substrates.
  • Ink type: Compatible with water-based and UV-curable inks for varied durability needs.
  • Printing speed: Adjustable to balance speed and resolution for high-volume or precision tasks.

Get inspired

With its CAD file compatibility and precision contour plotting, this printer transforms technical designs into tangible outputs for industries like apparel manufacturing, architectural visualization, and industrial prototyping.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Print Speed30 sq ft/hr+20% (36 sq ft/hr)+40% (42 sq ft/hr)*
Resolution1200 x 1200 dpiSame as Base2400 x 2400 dpi
Ink SystemStandard inksUV-curable inksDual ink (water-based + UV)
ConnectivityUSB/EthernetWi-Fi + EthernetWi-Fi 6 + Ethernet

Supplier's note

  1. Technical Breakthroughs:

    • Aluminum frame: Reduces thermal expansion for consistent print accuracy in industrial settings.
    • Dual ink system (Pro Model): Enables simultaneous printing with water-based and UV inks for specialized applications like waterproof apparel patterns.
    • High-speed print heads (Pro): 40% faster than industry benchmarks, ideal for mass production of banners or technical blueprints.

  2. Version Selection Guidance:

    • Base Model: Suitable for small workshops needing reliable, cost-effective printing (e.g., local signage shops).
    • Advanced Model: Targets mid-tier users requiring UV-curable inks for outdoor signage or durable industrial labels.
    • Pro Model: Designed for high-volume manufacturers (e.g., apparel factories) needing ultra-high resolution and dual-ink flexibility. With its triple-certified chemical resistance, the Pro ensures safe handling of aggressive UV inks while maintaining precision on delicate substrates.

Frequently asked questions

  • Which large format printer model is best for high-volume apparel pattern printing?

  • How do I maintain the print head of a CAD contour plotter?

  • Aluminum vs. Steel frames: Which is better for industrial plotters?

  • Can this contour plotter handle custom fabric patterns?

  • Is this plotter’s material compliant with industrial safety standards?

  • What file formats does the CAD contour plotter support for pattern printing?

  • How fast can this plotter produce large-scale apparel patterns?

  • Does the contour plotter include an automatic cutting feature?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Material CompositionIndustrial/Commercial SettingsIndustry Standard: Plastic frame (ASTM D638)
Our Base: Aluminum frame (ASTM B117 corrosion resistance)
Our Advanced: Reinforced aluminum + magnesium alloy (▲▲)		▲▲ Enhanced durability and corrosion resistance
(Our Advanced: 10+ years lifespan vs. 5 years for Industry Standard)		Higher upfront cost compared to plastic frames
Print ResolutionHigh-Detail CAD/BlueprintsIndustry Standard: 600x600 DPI
Our Base: 1200x1200 DPI
Our Advanced: 2400x2400 DPI (▲▲)		▲▲ Ultra-fine detail for precision engineering drawings
(Meets ISO 13660:2012 standards)		Advanced models may require higher-end software compatibility
File Format SupportCAD/Design StudiosIndustry Standard: Basic formats (JPEG/PNG)
Our Base: HPGL, DXF, PLT
Our Advanced: +SVG/3D PDF (▲)		▲ Direct compatibility with CAD software (AutoCAD, SolidWorks)
(Supports 25+ file types vs. 5 for Industry Standard)		Requires proprietary drivers for legacy systems
Printing SpeedHigh-Volume Commercial PrintingIndustry Standard: 30 sq ft/hr
Our Base: 50 sq ft/hr
Our Advanced: 80 sq ft/hr (▲▲)		▲▲ 267% faster output for large batches
(ISO 24734-compliant speed testing)		Advanced models consume more power and require frequent maintenance
Material CustomizationApparel/Signage ProductionIndustry Standard: Paper only
Our Base: Paper, vinyl, fabric
Our Advanced: +Foamboard, PVC (▲)		▲ Versatile for apparel patterns, banners, and signage
(ISO 1539-1 certified substrate adaptability)		Requires substrate calibration for optimal adhesion
Noise LevelOffice/Shared WorkspacesIndustry Standard: 65 dBA
Our Base: 60 dBA
Our Advanced: 55 dBA (▲)		▲ Quieter operation than a refrigerator (▲▲ Advanced model: 55 dBA vs. Industry’s 65 dBA)Noise reduction adds 10% to energy consumption
