High Frequency 24V Power Transformer PQ2016 PQ3230 Toroidal Core Transformer 220V to 12V Single Output Voltage Transformer

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Frequency Voltage Conversion: Efficiently converts input voltages (220V/240V) to single-output voltages (12V/24V/36V/220V) using a toroidal coil structure, enabling precise power regulation in electronic systems.
  • Compact Energy Storage & Filtering: Designed for high-frequency applications (e.g., switching power supplies), the ferrite core ensures minimal energy loss while providing electromagnetic interference (EMI) suppression and signal filtering capabilities.

Key features

  • 1. Advanced Material Technology

    • With a toroidal ferrite core and copper winding, you can achieve high efficiency and compact design, reducing energy loss compared to traditional E-core transformers.*

  • 2. Modular and Accessible Design

    • With a modular design and accessible terminals, you can easily integrate this transformer into circuits without complex assembly, unlike bulkier models.*

  • 3. High-Frequency Performance

    • With high-frequency capabilities and precise voltage conversion (220V/240V to 12V/24V), you can support modern switching power supplies more effectively than conventional transformers.*

  • 4. Versatile Scenario Solutions

    • Designed for high-frequency applications like switching power supplies, this transformer ensures stable performance in environments where traditional models may overheat or underperform.*

  • 5. Customization Flexibility

    • With customizable core materials and terminal configurations, you can tailor the transformer to specific application needs, offering greater adaptability than standardized models.*

Product details

High Frequency 24V Power Transformer PQ2016 PQ3230 Toroidal Core Transformer 220V to 12V Single Output Voltage Transformer

The High Frequency 24V Power Transformer PQ2016/PQ3230 is a compact toroidal core transformer designed for high-frequency applications in switching power supplies. Built with copper windings and a ferrite core, it offers efficient energy transfer and low electromagnetic interference. Available in single-output configurations (12V/24V/36V/220V), it supports input voltages of 220V/240V, making it ideal for electronic devices requiring stable power conversion.

Technical specifications

FeatureSpecificationApplication Scenario
Coil StructureToroidal copper windingsMinimizes leakage flux in high-frequency circuits
Core MaterialFerriteHigh-frequency filtering and energy storage
Input Voltage Range220V–240VGlobal compatibility for industrial equipment
Output Voltage Options12V, 24V, 36V, 220V (single output)Customizable power supply for electronics
Frequency ResponseOptimized for high-frequency operationSwitching power supplies and inverters
Enclosure MaterialDurable plastic/metalProtection against environmental stress

Customization guide

Adjustable parameters include:

  • Core Material: Swap ferrite for powdered iron to enhance magnetic saturation for heavy-load applications.
  • Terminal Configuration: Modify pin spacing or add screw terminals for easier soldering.
  • Output Voltage: Tailor output levels (e.g., 5V/9V) for specialized devices.

Get inspired

With its toroidal design and copper windings, this transformer ensures minimal energy loss in high-frequency setups. Ideal for compact electronics like LED drivers, IoT devices, or industrial control systems requiring reliable power conversion.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Efficiency88%+12% (91%)+20% (94%)
Max Power Handling100W150W250W
Frequency Range50–200kHz50–300kHz50–500kHz*
Thermal Resistance65°C/W55°C/W40°C/W
CertificationIEC 60947IEC 60947 + RoHSIEC 60947 + RoHS + UL

Supplier's note

  1. Toroidal Core Design: Reduces stray magnetic fields by 40% compared to E-core transformers, enabling safer integration in sensitive electronic systems.
  2. High-Frequency Optimization: The Pro Model’s 500kHz capability outperforms industry benchmarks by 30%, ideal for fast-charging applications.
  3. Material Choice: Copper windings provide 15% lower resistance than aluminum, ensuring cooler operation under load.

Version Selection Guide:

  • Base Model: Suitable for standard 100W devices (e.g., small LED panels) where cost efficiency is prioritized.
  • Advanced Model: Recommended for mid-range industrial equipment (e.g., HVAC systems) needing enhanced thermal performance.
  • Pro Model: Best for high-power, high-frequency applications (e.g., server power supplies) requiring UL certification and extreme durability.

Pro Model’s 500kHz frequency exceeds industry standards by 30%, enabling seamless operation in 5G base stations. Pair its low thermal resistance with copper windings to reduce heat buildup by 25%, extending lifespan in continuous-use scenarios.

Frequently asked questions

  • Which high-frequency transformer model suits compact switching power supplies?

  • How to maintain the ferrite core of a 24V power transformer for longevity?

  • Copper vs aluminum windings: Why is copper preferred in high-frequency transformers?

  • Can this 220V to 12V transformer be customized for 36V output?

  • Is the PQ3230 transformer UL-certified for high-frequency applications?

  • Which model handles 240V input for industrial power supplies?

  • Can toroidal transformers reduce noise in electronic circuits?

  • Are these transformers suitable for solar power inverters?
