High Performance and Accuracy Dimension Video Measuring System 2D Measuring Machine Precision CMM Vision Measurement

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Precision 2D Measurement: Utilizes advanced video-based technology for high-accuracy dimension analysis, enabling precise measurement of object geometries and tolerances.
  • CMM Vision Integration: Combines Coordinate Measuring Machine (CMM) principles with vision measurement systems to ensure reliable data capture for quality control and inspection tasks.

Key features

  • 1. Material Technology

    • With precision-engineered optical components, achieve sub-micron measurement accuracy for high-stakes manufacturing applications. Up to 0.01mm resolution, 20% more precise than conventional 2D systems*

  • 2. Interactive Design

    • With an intuitive touchscreen interface, streamline workflow by accessing pre-set measurement programs quickly. Reduces setup time by 30% compared to manual systems*

  • 3. Performance Parameters

    • With high-speed 2D scanning technology, complete complex measurements 20% faster than traditional systems while maintaining accuracy. Processes up to 50 parts per hour*

  • 4. Scenario Solutions

    • With versatile application adaptability, seamlessly integrate into both small-batch prototyping and high-volume production environments. Suitable for precision engineering and mass production scenarios*

  • 5. Certification Standards

    • With EPR Germany environmental certification, ensure compliance with EU packaging waste regulations for sustainable operations. Meets strict environmental disposal standards*

Product details

High Performance and Accuracy Dimension Video Measuring System 2D Measuring Machine Precision CMM Vision Measurement

The High Performance and Accuracy Dimension Video Measuring System is a cutting-edge 2D measuring machine designed for precision quality control and dimensional analysis. Equipped with advanced computer vision technology and EPR-Germany-certified compliance, this system delivers rapid, repeatable measurements for diverse industrial applications.

Technical specifications

FeatureSpecificationBenefit
Measurement Accuracy±0.005mm (Pro Model)Ensures precision in high-stakes manufacturing
Measurement Speed120 points/min (Advanced Model)20% faster than traditional CMM systems
Resolution0.001mmCaptures intricate details in micro-components
Repeatability±0.002mmReliable results for mass production quality checks
CertificationEPR Germany Packing StandardMeets stringent European safety and compliance requirements

Customization guide

Adjustable measurement range (up to 1,200x800mm) and software interfaces (e.g., CAD integration) to meet specialized needs in automotive, electronics, or aerospace sectors.

Get inspired

With this system’s 2D vision measurement capabilities, you can streamline quality assurance processes for precision parts, PCB assemblies, and complex geometries. Its automated data logging and real-time analysis enable seamless integration into smart manufacturing workflows.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Measurement Accuracy±0.01mm±0.008mm (+15%)±0.005mm (+30%)*
Max. Measurement Range600x400mm1,000x600mm1,200x800mm
Processing Speed80 points/min120 points/min150 points/min
Resolution0.002mm0.0015mm0.001mm

Supplier's note

  1. Three Technical Breakthroughs:

    • EPR Certification Compliance: Ensures seamless entry into European markets with rigorous safety standards.
    • Enhanced Optical Resolution: The Pro Model’s 0.001mm resolution captures microscopic details in semiconductor or medical device components.
    • Automated Data Synchronization: Reduces manual errors by 40% via real-time integration with CAD/CAM systems.

  2. Optimal Version Selection:

    • Base Model: Ideal for SMEs requiring cost-effective QC for standard parts (e.g., automotive bolts, plastic molds).
    • Advanced Model: Suitable for mid-tier manufacturers needing faster throughput (e.g., PCB assembly lines, consumer electronics).
    • Pro Model: Best for high-precision industries like aerospace or medical devices, where ±0.005mm accuracy ensures compliance with critical tolerances.

*Pro Model’s accuracy exceeds ISO 10360-2:2019 standards by 25%.

Frequently asked questions

  • Which High Performance 2D Measuring Machine model suits small workshops with limited space?

  • How to maintain the sensors of the Precision CMM Vision Measurement System for optimal performance?

  • Is the Dimension Video Measuring System EPR Germany certified for European compliance?

  • Can the Vision Measurement System be customized with software for specific part inspections?

  • What’s the maximum accuracy of the 2D Measuring Machine for micro-component inspection?

  • Does the CMM Vision Measurement System support real-time data export to ERP systems?

  • How often should the Precision CMM Vision Measurement System be calibrated?

  • Which industries is the High Performance Dimension Video Measuring System best suited for?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
2D Measuring MachineQC of flat parts (e.g., PCBs, sheets)Resolution: 0.5 µm (ISO 10360-2) ▲
Certification: EPR Germany Packing (complies with EU packaging standards)		Cost-effective, fast 2D analysis ▲
EU regulatory compliance		Limited to 2D data ▲
Less versatile for complex geometries
Coordinate Measuring MachinePrecision 3D part inspectionAccuracy: 0.8 µm ▲
Axes: 6-axis motion (ISO 10360-12)		High precision for complex geometries ▲
Multi-axis flexibility		High cost, slower cycle times ▲
Requires skilled operators
Vision Measurement SystemSurface defect detection (e.g., semicon)Camera: 29 MP resolution ▲
Auto-focus: 0.01 mm repeatability		Non-contact inspection ▲
Rapid defect detection ▲		Struggles with reflective/transparent surfaces ▲
Calibration sensitive
Portable CMMOn-site manufacturing auditsWeight: 5 kg ▲
Battery Life: 8h continuous use (IEC 60204)		Field mobility ▲
Immediate feedback ▲		Lower accuracy vs benchtop models ▲
Environmental sensitivity
Laser Scanning SystemReverse engineering & 3D modelingPoint Density: 500k points/sec ▲
Field of View: 1.2m (ASTM E2808)		High-speed 3D data capture ▲
Complex surface mapping ▲		Requires post-processing ▲
Expensive software dependencies
Handheld Measuring ToolRapid in-line inspectionsWireless: 2.4 GHz transmission ▲
Battery: 12h (IEC 62209-1)		Instant portability ▲
Minimal setup time ▲		Lower precision vs fixed systems ▲
Limited measurement range
