High Precision 2D Optical Coordinate Vision Video Measuring Machine

High Precision 2D Optical Coordinate Vision Video Measuring Machine

$9000.00-$80000.00/ Set|1 Set/Sets(Min. Order)

Customization:

Customized logo（Min.Order: 1 pieces）
Customized packaging（Min.Order: 1 pieces）
Graphic customization（Min.Order: 2 pieces）
View product details

High Precision 2D Optical Coordinate Vision Video Measuring Machine

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Precision 2D Measurement: Equipped with a laser/light projection system and high-resolution camera, the machine enables sub-micron accuracy for precise dimensional analysis of parts across X, Y, and Z axes.
  • Integrated Software Analysis: Features advanced software for real-time data processing, automated measurement reporting, and compliance with quality control standards in manufacturing.

Key features

  • 1. Industrial-Grade Material Technology for Durability

    • With a robust metal-and-plastic construction, this machine ensures long-term precision and stability in demanding manufacturing environments. The sturdy base and adjustable optical head withstand frequent use without compromising accuracy.

  • 2. User-Friendly Interactive Design for Efficiency

    • With an intuitive control panel featuring emergency stop and software integration, streamline operations while ensuring operator safety. The advanced software interface simplifies data analysis and measurement adjustments, reducing setup time by up to 30%* compared to basic models.

  • 3. Sub-Micron Precision for Critical Applications

    • With sub-micron measurement accuracy, achieve precise results for aerospace, automotive, and electronics components. This level of precision outperforms standard optical instruments by up to 50%* in detail-critical tasks.

  • 4. Versatile Scenario Adaptability

    • Whether in manual quality control or automated production lines, this machine adapts to diverse manufacturing needs. Its large worktable and adjustable optical head accommodate parts from small components to large assemblies, enhancing workflow flexibility.

  • 5. Global Compliance Certifications

    • With RoHS and CE certifications, ensure compliance with global environmental and safety standards, meeting the demands of regulated industries while minimizing environmental impact.

Product details

High Precision 2D Optical Coordinate Vision Video Measuring Machine

The High Precision 2D Optical Coordinate Vision Video Measuring Machine combines robust construction, advanced optics, and intuitive software to deliver sub-micron accuracy for quality control in manufacturing. Certified to RoHS and CE standards, it supports versatile applications from small components to large assemblies, backed by a 1-year warranty.

Technical specifications

FeatureSpecificationBenefit
Measurement AccuracySub-micron resolution (≤0.5μm)Ensures precision in aerospace, automotive, and electronics manufacturing
Optical SystemAdjustable laser/light source + high-resolution camera (4K)Captures detailed images for automated data analysis
Axes MovementX/Y/Z-axis adjustability with ±0.001mm repeatabilityEnables multi-directional measurements of complex geometries
CertificationsRoHS, CEMeets global safety and environmental compliance standards
Worktable CapacitySpacious flat surface (max load: 50kg)Accommodates large assemblies or small precision parts

Customization guide

Adjustable optical head positioning and software parameters can be tailored to meet specific measurement tolerances (e.g., ±0.1μm for semiconductor components) or integrate with existing quality management systems.

Get inspired

With sub-micron accuracy and 4K optical resolution, this machine empowers manufacturers to achieve flawless quality control. Whether inspecting automotive gears or PCBs, its versatility ensures reliability across industries.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Measurement Speed100mm/s+20% faster (120mm/s)+35% faster (135mm/s)*
Accuracy±0.5μm±0.3μm±0.1μm
Software FeaturesBasic 2D analysisAuto edge detection3D modeling + AI defect scan
AutomationManual controlSemi-automatedFully automated

Supplier's note

  1. Technical Breakthroughs:

    • Sub-micron accuracy (≤0.1μm in Pro Model) exceeds industry benchmarks by 3x, enabling safe handling of delicate semiconductor components.
    • AI-driven defect scanning in the Advanced Model reduces inspection time by 20% compared to traditional methods.
    • 4K optical resolution ensures clarity even for microscopic features, outperforming 1080p competitors.

  2. Version Selection Guide:

    • Base Model: Ideal for SMEs prioritizing cost-efficiency for basic QC tasks (e.g., measuring standard automotive parts).
    • Advanced Model: Best for mid-sized manufacturers needing semi-automation and faster defect detection (e.g., PCB inspection).
    • Pro Model: Suited for high-precision industries like aerospace, where ±0.1μm accuracy paired with AI modeling ensures flawless turbine blade measurements.

*Performance gains vs. industry-standard CMM models.

Frequently asked questions

  • Which model of high-precision 2D optical measuring machine suits small workshops?

  • How to clean the optical lens of a coordinate vision video measuring machine?

  • Why does the machine use metal and plastic materials for its structure?

  • Can this video measuring machine integrate with custom software for specific applications?

  • Is the coordinate vision measuring machine certified for international standards like RoHS and CE?

  • What's the maximum measurement accuracy of the 2D optical coordinate machine?

  • Which industries benefit most from using a high-precision video measuring machine?

  • Does the machine come with a warranty, and what support is available?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Industry Standard Coordinate Measuring MachineGeneral manufacturing quality control1 micron resolution (ISO 10360), basic software (manual operation), CE certifiedCost-effective, reliable for standard partsLimited precision for high-precision industries (e.g., aerospace)
Our Base Model (High Precision 2D Optical CMM)Automotive/electronics manufacturing0.5 micron resolution (▲ vs Industry Standard), RoHS/CE certified, 1-year warrantyEnhanced precision for mass production, dual certificationNo automated analysis features, requires skilled operators
Our Advanced ModelAerospace/medical device production0.25 micron resolution (▲▲), advanced software with automated analysis, 3-year warrantyHighest precision, automated defect detection, extended warrantyHigher cost, requires specialized training
Portable Coordinate Measuring MachineField inspections/on-site quality checks1 micron resolution, lightweight design (ISO 9001), 1-year warrantyMobility for remote use, cost-effective for small teamsLower durability, less precision for critical applications
Automated Coordinate Measuring MachineHigh-volume production lines0.5 micron resolution, fully automated (ISO 14644), 2-year warrantyFast throughput, reduces human error in mass productionHigh initial cost, complex integration with existing systems
Manual Coordinate Measuring MachineSmall workshops/prototyping1 micron resolution, manual operation, CE certifiedLower cost, flexible for custom setupsSlow measurement, dependent on operator skill and fatigue
