Horizontal Hydraulic Internal Broaching Machine

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Precision Internal Broaching: Designed to create precise internal shapes and holes in metal components using hydraulic power, ensuring high-force, smooth cutting for complex geometries.
  • Hydraulic Power Efficiency: Leverages hydraulic systems for consistent force application, enabling reliable performance in heavy-duty material processing tasks.

Key features

  • 1. Material Technology

    • With a corrosion-resistant steel body, ensure durability in harsh industrial environments*.

  • 2. Interactive Design

    • With a PLC-controlled touchscreen interface, preset multi-program operations for seamless automation*.

  • 3. Performance Parameters

    • With hydraulic power, achieve high-force output for precise material forming, surpassing mechanical systems in speed and consistency*.

  • 4. Scenario Solutions

    • With modular adaptability, switch between production tasks for diverse industrial applications*.

  • 5. Certification Standards

    • With compliance to industrial safety standards, ensure reliable performance in regulated environments*.

Product details

Horizontal Hydraulic Internal Broaching Machine

The Horizontal Hydraulic Internal Broaching Machine is a robust industrial tool designed for precision material forming and shaping. Built with durable steel construction and hydraulic power, it offers efficient automation through PLC controls and modular design for customizable production needs. Backed by a 1-year warranty, it ensures reliability in high-volume manufacturing environments.

Technical specifications

FeatureSpecificationApplication Scenario
Power SourceHydraulicPrecision cutting and shaping metals
Material ConstructionHeavy-duty steel frameWithstands high-pressure industrial use
Control SystemPLC programmable interfaceAutomated production lines in automotive manufacturing
Modular DesignAdjustable broaching stroke/pressureCustomized hole or slot forming in aerospace parts
Warranty Period1 yearLong-term operational reliability assurance

Customization guide

Adjustable parameters such as broaching stroke length (+/- 5mm range) and hydraulic pressure (up to 40MPa) allow customization to meet specific production tolerances or material hardness requirements.

Get inspired

With its hydraulic precision and modular flexibility, this machine empowers manufacturers to achieve complex internal profiles in metals—ideal for creating gears, engine blocks, or turbine components with minimal downtime.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Hydraulic Pressure30MPa+15% (34.5MPa)+30% (39MPa)*
Precision±0.1mm±0.08mm±0.05mm
Automation LevelBasic PLC controlFull PLC + sensorsIoT-enabled monitoring
Max Stroke Length500mm600mm800mm

Supplier's note

  1. Key Technical Breakthroughs:

    • Hydraulic Efficiency: The Pro Model’s 39MPa pressure (30% above industry benchmarks) enables high-speed broaching of hardened steel.
    • Precision Engineering: The Advanced Model’s ±0.08mm tolerance reduces scrap rates by 20% in aerospace component production.
    • Modular Scalability: Adjustable stroke lengths allow seamless adaptation to both small-batch prototyping and mass production.

  2. Optimal Version Selection:

    • Base Model: Ideal for SMEs needing cost-effective solutions for standard metalworking tasks (e.g., automotive brackets).
    • Advanced Model: Targets mid-tier manufacturers requiring enhanced precision (e.g., medical device parts).
    • Pro Model: Best for high-volume industries like aerospace or energy, where extreme durability and IoT integration are critical. With its triple-certified chemical resistance, the Pro Model ensures safe handling of corrosive coolants during turbine blade production. Pair its 800mm stroke with PLC sensors to automate quality checks in real time.

Frequently asked questions

  • Which horizontal hydraulic internal broaching machine model is best for heavy-duty metalworking tasks?

  • How do I maintain the hydraulic system of a horizontal hydraulic internal broaching machine?

  • Why is steel the preferred material for constructing horizontal hydraulic internal broaching machines?

  • Can this machine be customized for specific broaching profiles?

  • Is the hydraulic system compliant with industrial safety standards?

  • Does the 1-year warranty cover regular hydraulic system maintenance?

  • How does the hydraulic power source improve internal broaching efficiency?

  • What materials can be processed with this horizontal hydraulic internal broaching machine?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Hydraulic Broaching SystemsComplex internal geometries (engine blocks, gears)Cutting Force: 120 kN (Industry Standard) ▲150 kN (Our Base) ▲220 kN (Our Advanced, ISO 2372)
Precision: ±0.1mm (Industry) ▲±0.05mm (Base) ▲±0.02mm (Advanced, ISO 2768)
Noise Level: 85 dBA (Industry) ▲80 dBA (Base) ▲75 dBA (Advanced, ISO 11203)		High production efficiency, capable of intricate shapes, quieter operation (quieter than industrial drills)Higher upfront cost, requires skilled setup, limited to specific geometries
CNC Milling MachinesPrecision 3D components (aerospace, molds)Spindle Speed: 8000 RPM (Industry Standard)
Tool Change Time: 5s (Industry)		Extreme flexibility, high accuracy (±0.01mm), automated workflowsHigh maintenance costs, requires skilled operators, slower for large batches
Laser Cutting MachinesSheet metal/plastic cutting (automotive, signage)Cutting Speed: 2 m/min (Industry Standard)
Accuracy: ±0.1mm (ISO 2768)		Minimal material waste, rapid setup (no tool changes), non-contact processLimited to thin materials (<20mm), energy-intensive, reflective materials problematic
Electric Discharge Machining (EDM)Conductive materials (electrodes, dies)Discharge Energy: 10 J/pulse (Industry)
Surface Finish: Ra 1.6 μm (ISO 1302)		Works on hard materials (e.g., titanium), no mechanical stressSlow process (hours/day), requires conductive materials, post-processing often needed
Conventional Broaching MachinesSimple internal shapes (keyways, splines)Cutting Force: 100 kN (Industry)
Production Rate: 50 parts/hour (ISO 9283)		Lower cost, simpler operation, high volume productionLimited to basic geometries, less efficient for complex parts, tooling costs add up
Modular Machine Tool SystemsFlexible manufacturing (automotive, electronics)Modular Units: 5+ (Industry)
Setup Time: 2 hours (Industry)		Rapid reconfiguration, reduced downtime, space-efficient layoutsComplex maintenance, higher initial investment, requires advanced planning
