JSY1003F Vertical Installation Integrated Measurement Digital Communication Electronic Watt Power Consumption Energy Meter
Ready to Ship
In stock Fast dispatch

JSY1003F Vertical Installation Integrated Measurement Digital Communication Electronic Watt Power Consumption Energy Meter

  • >= 10 Pieces
    $6.39
    $7.10

Customization:

Customized logo（Min.Order: 500 pieces）
Customized packaging（Min.Order: 1000 pieces）
Graphic customization（Min.Order: 500 pieces）
View product details

JSY1003F Vertical Installation Integrated Measurement Digital Communication Electronic Watt Power Consumption Energy Meter

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Accurate Energy Measurement: Class 1 accuracy for precise real-time monitoring of power consumption, voltage, current, and energy usage.
  • Digital Communication Integration: Supports IoT and industrial systems via digital interfaces, enabling seamless data transmission for smart grid management and remote monitoring.

Key features

  • 1. Material Technology

    • With a durable FR4 PCB and corrosion-resistant components, ensure long-lasting performance in harsh industrial or outdoor environments. ~30% more resistant to wear than standard PCB materials*.

  • 2. Interactive Design

    • With modular connectors and lightweight design, achieve quick vertical installation in tight spaces. 40% faster setup than bulkier meters*.

  • 3. Performance Parameters

    • With class 1 accuracy (±1% precision), measure energy consumption reliably. 50% more precise than class 2 meters*.

  • 4. Scenario Solutions

    • Designed for vertical installation, seamlessly integrate into IoT systems for smart homes, industrial equipment, or telecommunication devices. Compatible with more use cases than basic meters*.

  • 5. Certification Standards

    • Certified to RoHS, IEC 62368, and EPR standards, ensuring safety and eco-friendly compliance. Exceeds minimum regulatory requirements for global markets*.

Product details

JSY1003F Vertical Installation Integrated Measurement Digital Communication Electronic Watt Power Consumption Energy Meter

The JSY1003F Vertical Installation Integrated Measurement Energy Meter is a compact, versatile module designed for precise energy monitoring in IoT, industrial, and household applications. With a 30mm x 30mm FR4 PCB and 3.3V operation, it combines durability, safety, and ease of integration. Certified to global standards like RoHS and IEC 62368, it ensures compliance across markets while supporting analog, digital, or hybrid display configurations.

Technical specifications

FeatureSpecificationApplication Scenario
Accuracy ClassClass 1 (±1% measurement error)Industrial process control, billing-grade metering
CertificationsRoHS, EPR Germany/France, IEC 62368, CEGlobal deployment in regulated industries
Display OptionsAnalog, Digital, or Hybrid (analog + digital)Retail energy kiosks, smart home dashboards
Power Supply3.3V DC (low-power design)IoT edge devices, battery-operated systems
MaterialFR4 PCB with standard componentsHarsh environments requiring thermal stability
ConnectivityDual connectors (white/black) for modular integrationSmart grid interfaces, industrial automation

Customization guide

Adjustable parameters include:

  • Display Type: Swap between analog, digital, or hybrid interfaces to match user preference.
  • Communication Protocols: Customize connector pinouts for RS-485, Modbus, or Wi-Fi integration.
  • Voltage Tolerance: Modify input range (e.g., 2.5V–5V) for low-power IoT applications.

Get inspired

Use the JSY1003F to build:

  • Smart Home Hubs: Pair its digital display with voice-controlled energy monitoring.
  • Industrial IoT Sensors: Leverage Class 1 accuracy for real-time factory energy audits.
  • Telecom Backup Systems: Rely on its 3.3V efficiency to extend battery life in remote towers.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
AccuracyClass 1 (±1%)Class 0.5 (±0.5%)Class 0.2 (±0.2%)
DisplayDigital onlyHybrid (analog + digital)Full-color TFT
CommunicationRS-485RS-485 + Wi-FiRS-485 + 5G/LTE
Operating Temp.-10°C to 50°C-20°C to 70°C-30°C to 85°C

Supplier's note

  1. Technical Breakthroughs:

    • Class 1 Accuracy: Enables billing-grade precision for utilities, reducing disputes.
    • 3.3V Low-Power Design: 20% more energy-efficient than 5V competitors in IoT setups.
    • Multi-Certification Compliance: Streamlines deployment across EU and global markets.

  2. Version Selection Guide:

    • Base Model: Ideal for households and small businesses needing basic energy tracking.
    • Advanced Model: Targets industrial IoT where hybrid displays and Wi-Fi connectivity are critical.
    • Pro Model: For extreme environments (e.g., oil rigs) requiring sub-0.2% accuracy and 5G connectivity.

With Class 1 accuracy, you can ensure precise energy billing in industrial grids. With its 3.3V design, you can extend battery life in remote sensors. The Pro Model’s triple-certified durability meets EPR and IEC standards, enabling safe handling of high-voltage systems. Pair its 5G module with the FR4 PCB’s thermal stability to achieve real-time data transmission in harsh climates.

Frequently asked questions

  • Which energy meter model is best for industrial IoT applications?

  • How to maintain the JSY1003F energy meter for long-term use?

  • FR4 vs other materials: Why is the JSY1003F PCB made of FR4?

  • Can the JSY1003F support custom connectors for integration?

  • Is the JSY1003F compliant with EU environmental regulations?

  • What display type suits real-time energy monitoring best?

  • Does the JSY1003F work with low-power IoT systems?

  • What warranty and support does the JSY1003F offer?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Accuracy ClassIndustrial Metering, Billing SystemsIndustry: ±2% (Class 2, IEC 62053-21) ▲
Our Base: ±1% (Class 1, IEC 62053-11) ▲
Our Advanced: ±0.5% (Class 0.5, IEC 61036)		Ensures precise billing and compliance with regulatory standards.Higher cost compared to standard meters due to advanced calibration.
Display TypeIoT, Smart Home SystemsIndustry: Analog Only ▲
Our Base: Analog ▲
Our Advanced: Digital + Analog (ISO 7512)		Digital displays enable real-time data logging and remote monitoring.Analog-only systems lack connectivity features for IoT integration.
CertificationsEU/Global ComplianceIndustry: CE, RoHS ▲
Our Base: +IEC 62368 ▲
Our Advanced: +EPR Germany/France, CE, RoHS		Wider market access in regulated regions like Germany/France.Advanced certifications increase upfront costs for compliance testing.
WeightPortable Devices, Field InstallationsIndustry: 50g ▲
Our Base: 25g (30x30mm FR4 PCB) ▲
Our Advanced: 28g (with IoT module)		Lightweight design simplifies installation in tight spaces or handheld devices.Sacrifices minor durability compared to heavier, bulkier alternatives.
Voltage CompatibilityLow-Power Systems (Raspberry Pi)Industry: 5V ▲
Our Base: 3.3V (JSY1003F spec) ▲
Our Advanced: 3.3V ±10% tolerance		Direct compatibility with microcontrollers like Arduino/Raspberry Pi.Not suitable for high-voltage industrial systems (e.g., 220V/440V applications).
Installation TimeTelecom Deployments, Emergency SetupIndustry: 15 mins ▲
Our Base: 5 mins (snap-fit design) ▲
Our Advanced: 1 min (pre-configured IoT)		Reduces downtime by enabling rapid deployment in critical infrastructure.Advanced versions may lack customization for niche applications.
