KTM 5K 100mm resistive linear position transducer linear position sensor

KTM 5K 100mm resistive linear position transducer linear position sensor

$30.00-$150.00/ Piece|1 Piece/Pieces(Min. Order)
View product details

KTM 5K 100mm resistive linear position transducer linear position sensor

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Precise Linear Position Measurement: The KTM 5K 100mm resistive linear position sensor accurately measures linear displacement up to 100mm, leveraging resistive technology for real-time data output.
  • Versatile Analog Output: Supports 12V, 24V, and analog signals, ensuring seamless integration with a wide range of industrial and automation systems.

Key features

  • 1. Corrosion-Resistant Aluminum Construction

    • With a corrosion-resistant aluminum body, ensure durability in harsh industrial environments. ~30% lighter than steel alternatives*, this design reduces mechanical load while maintaining structural integrity.

  • 2. Versatile Analog Output Compatibility

    • With analog outputs (12V/24V) and an analog interface, seamlessly integrate into existing control systems. Compatible with both low and high-voltage setups for broader application flexibility.

  • 3. Precision 100mm Measurement Range

    • With a 100mm measurement range, achieve accurate linear displacement tracking over extended distances. The 5KΩ resistance ensures stable output signals for reliable performance in dynamic systems.

  • 4. Industrial-Grade Robustness

    • Designed for industrial automation, robotics, and machinery, this sensor withstands mechanical stress and environmental challenges. The compact, rugged design enables seamless deployment in demanding scenarios like manufacturing and automation.

  • 5. CE-Certified Safety Compliance

    • With CE certification, meet EU safety, health, and environmental standards. Ensures regulatory compliance for use in regulated industries, enhancing trust and reliability in global applications.

  • Notes:

    • The product’s resistive technology and analog outputs prioritize cost-effective integration over high-end LVDT alternatives, balancing precision and affordability.

Product details

KTM 5K 100mm resistive linear position transducer linear position sensor

The KTM 5K 100mm resistive linear position transducer is a precision sensor engineered for accurate linear displacement measurement in industrial and automation applications. Built with an aluminum body and a durable green plastic end cap, it offers robust performance in harsh environments. With a resistive sensing mechanism, analog output (12V/24V), and a 5KΩ resistance, this sensor ensures reliable integration into control systems while maintaining compliance with CE safety standards.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialAluminum body, plastic end capWithstands mechanical stress in industrial machinery
Measurement Range100mmAccurate tracking of long-stroke movements
Output±0.05V (analog), 12V/24VCompatible with PLCs and industrial control systems
Resistance5KΩEnsures stable signal transmission
CertificationCEMeets EU safety and environmental standards
TechnologyResistiveIdeal for cost-effective position monitoring

Customization guide

Adjustable parameters include measurement range (up to ±20% beyond 100mm) and output voltage (customizable to 5V/10V) to meet specific application needs.

Get inspired

Whether you’re automating robotic arms or monitoring industrial equipment, the KTM 5K’s precision and durability ensure seamless integration into systems requiring reliable linear position feedback.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Measurement Range100mm150mm (+50mm)200mm (+100mm)*
Output Stability±0.05V±0.03V (20% better)±0.02V (60% better)
Operating Temp.-20°C to 80°C-30°C to 100°C-40°C to 120°C
IP RatingIP65IP67IP69K (dust/waterproof)

Supplier's note

  1. Three Technical Breakthroughs:

    • The Pro Model’s IP69K rating enables use in high-pressure washdown environments (e.g., food processing), unlike standard IP65 sensors.
    • The Advanced Model’s ±0.03V output stability reduces errors by 40% in dynamic systems like CNC machines.
    • All versions feature a 5KΩ resistance, ensuring compatibility with legacy analog systems while outperforming traditional LVDTs in cost and ease of integration.

  2. Optimal Version Selection:

    • Base Model: Ideal for general industrial automation (e.g., conveyor belts) where cost efficiency is critical.
    • Advanced Model: Suited for high-temperature environments (e.g., foundries) requiring extended durability.
    • Pro Model: Best for harsh outdoor or chemical-exposed applications (e.g., mining equipment) where extreme reliability is paramount.

With its 100mm measurement range, you can precisely track movements in robotics. The Pro Model’s IP69K rating ensures safe operation in washdown processes, while its 200mm range expands applicability for large-scale machinery.

Frequently asked questions

  • Which applications is the KTM 5K 100mm resistive linear position sensor best suited for?

  • How should the KTM 5K 100mm sensor’s aluminum body be maintained to prevent corrosion?

  • Why is aluminum chosen for the KTM 5K 100mm sensor’s body over other materials?

  • Can the KTM 5K 100mm sensor be customized for specific voltage requirements?

  • Is the KTM 5K 100mm sensor CE certified and compliant with safety standards?

  • How does the KTM 5K 100mm sensor achieve its ±0.05V output precision?

  • Is the KTM 5K 100mm sensor compatible with analog control systems?

  • What makes the KTM 5K 100mm sensor suitable for harsh industrial environments?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Measurement RangeIndustrial machinery, roboticsIndustry Standard: 50mm (common for compact systems)
Our Base: 50mm
Our Advanced: 100mm▲▲		Advanced doubles range for larger-scale applications (e.g., heavy machinery).Base may limit use in high-displacement scenarios.
Output TypeControl systems, automationIndustry Standard: ±0.1V analog
Our Base: ±0.05V analog
Our Advanced: ±0.02V analog▲▲		Higher precision output (e.g., ±0.02V for advanced robotics).Analog outputs require external signal conditioning for digital systems.
Power SupplyFactory automation, automotiveIndustry Standard: 12V only
Our Base: 12V/24V
Our Advanced: 12V/24V + voltage tolerance (±10%)▲		Flexible voltage compatibility reduces system redesign costs.No USB or wireless options for modern IoT setups.
TechnologyCost-sensitive applicationsIndustry Standard: LVDT (magnetic)
Our Base/Advanced: Resistive (potentiometric)▲		Lower cost and simpler design compared to LVDTs.Susceptible to wear over time vs. non-contact LVDTs.
Environmental ResistanceHarsh industrial environmentsIndustry Standard: IP54 (dust/water resistance)
Our Base: IP65▲
Our Advanced: IP67▲▲		Advanced withstands submersion (e.g., in hydraulic systems).IP67 adds cost; Base may suffice for indoor use.
Certification & ComplianceEU/Global marketsIndustry Standard: No universal certification
Our Base/Advanced: CE certified▲▲		CE ensures compliance with EU safety/EMC standards.No ATEX/UL certifications for explosive environments.
