M12 Wire Connector Panel Mount with Solder Cup Female Male Wire to Board Connector 2P 3P 4P 5P 6P 8P 12P 17P
Ready to Ship
In stock Fast dispatch

M12 Wire Connector Panel Mount with Solder Cup Female Male Wire to Board Connector 2P 3P 4P 5P 6P 8P 12P 17P

  • 50 - 499 Pieces
    $3.15
    $3.50
  • 500 - 999 Pieces
    $2.52
    $2.80
  • >= 1000 Pieces
    $1.62
    $1.80

Customization:

Customized logo（Min.Order: 5000 pieces）
Customized packaging（Min.Order: 5000 pieces）
Graphic customization（Min.Order: 5000 pieces）
View product details

M12 Wire Connector Panel Mount with Solder Cup Female Male Wire to Board Connector 2P 3P 4P 5P 6P 8P 12P 17P

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Secure Electrical/Data Connectivity: Designed for robust wire-to-board connections in panel-mounted applications, supporting 2P to 17P configurations. Features locking mechanisms and corrosion-resistant brass contacts for reliable performance.
  • Waterproof Protection: IP67-rated design with sealing capabilities ensures resistance to dust, water, and harsh environmental conditions, ideal for outdoor or industrial use.

Key features

  • 1. Corrosion-Resistant Nickel-Plated Brass Contacts

    • With nickel-plated brass contacts, you can achieve superior corrosion resistance and durability in harsh environments*, outperforming standard uncoated metal connectors by up to 50% in longevity*.

  • 2. Secure Panel Mount Design with Locking Screws

    • With a robust panel mount design featuring locking screws and solder termination, you can ensure stable, vibration-resistant connections while maintaining superior conductivity compared to crimp-style connectors*.

  • 3. IP67 Waterproof & Dustproof Protection

    • With an IP67 rating, you can protect against dust and water ingress (immersion up to 1m), making it ideal for outdoor or industrial settings compared to non-waterproof alternatives*.

  • 4. Versatile Pin Configurations for Diverse Applications

    • With adaptable pin options (2P to 17P), you can seamlessly integrate into applications like industrial machinery, automotive systems, or data transfer setups, offering 3x more customization than fixed-pin connectors*.

  • 5. RoHS Compliance & Rigorous Certifications

    • With RoHS compliance and IP67 certification, you can meet strict environmental and safety standards required in commercial/industrial sectors, ensuring regulatory alignment and quality assurance*.

Product details

M12 Wire Connector Panel Mount with Solder Cup Female Male Wire to Board Connector 2P 3P 4P 5P 6P 8P 12P 17P

The M12 Wire Connector Panel Mount is a rugged, industrial-grade solution designed for secure wire-to-board connections in harsh environments. With waterproof and dustproof IP67 ratings, brass contacts, and customizable pin configurations (2P to 17P), it ensures reliable performance in applications like automotive, robotics, and industrial machinery.

Technical specifications

FeatureSpecificationBenefit
MaterialBrassHigh conductivity and corrosion resistance
IP RatingIP67Waterproof and dustproof for outdoor use
Connector TypePanel mount, solder cup terminalsSecure, vibration-resistant installation
Contact MaterialBrass + nickel platingEnhanced durability and oxidation resistance
Pin Configurations2P, 3P, 4P, 5P, 6P, 8P, 12P, 17PVersatile for diverse wiring needs
CertificationsRoHS, IP67Compliance with global safety standards
TerminationSolderPermanent, high-integrity connections

Customization guide

Adjustable pin count (2P to 17P) to meet specific wiring requirements. For high-current applications, select larger pin configurations.

Get inspired

With IP67-rated waterproofing, you can deploy these connectors in outdoor or wet environments. The brass contacts ensure low resistance for efficient power/data transfer, while the modular design lets you tailor pin counts to your system’s needs.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Pin Capacity2P–6P4P–12P (+100% range)8P–17P (+183% range)
Operating Temp-40°C to 85°C-40°C to 105°C (+3°C)-40°C to 125°C (+50%)
Vibration Resistance10–55Hz @ 1.5G10–55Hz @ 3G (+100%)10–55Hz @ 5G (+233%)

Supplier's note

  1. Technical Breakthroughs:

    • IP67 Protection: Enables deployment in harsh environments like construction sites or marine systems.
    • Brass + Nickel Contacts: Reduces oxidation and ensures stable conductivity over time.
    • Modular Pin Design: Allows seamless integration into systems with varying wiring densities.

  2. Version Selection Guidance:

    • Base Model: Ideal for basic industrial setups (e.g., sensors in factories) requiring up to 6P connections.
    • Advanced Model: Suitable for robotics or HVAC systems needing higher pin counts (up to 12P) and wider temperature tolerance.
    • Pro Model: Best for aerospace or heavy machinery applications demanding extreme vibration resistance and 17P capacity.

With the Pro’s 5G vibration tolerance, you can ensure reliability in high-stress scenarios like mining equipment. Pair its 17P configuration with industrial Ethernet protocols to support complex data networks.

Frequently asked questions

  • Which M12 connector model suits applications requiring 4P waterproof wire-to-board connections?

  • How do I maintain the solder cups on M12 panel mount connectors?

  • Brass vs. Nickel Contacts: Which is better for corrosive environments?

  • Can M12 panel mount connectors be customized for non-standard pin orientations?

  • Is the M12 connector RoHS-compliant for industrial use?

  • What tools are needed for installing M12 panel mount connectors?

  • Does the IP67 rating protect against submersion in water?

  • Are M12 connectors suitable for high-temperature automotive applications?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
IP RatingOutdoor equipment, underwater devicesIndustry: IP65 (dust tight, water jets)
Base: IP67 (1m/30min water submersion) ▲
Advanced: IP68 (3m/48hrs submersion) ▲▲		Enhanced environmental protection for harsh conditions.Higher cost and bulkier design for IP68.
Pin ConfigurationBasic sensors → complex industrial systemsIndustry: Up to 4P connectors
Base: 2P-6P ▲
Advanced: 8P-17P ▲▲▲		Supports high-density wiring for multi-functional systems.Installation complexity increases with higher pin counts.
MaterialCorrosive or high-temperature environmentsIndustry: Aluminum (general corrosion resistance)
Base: Brass (ASTM B124, 1000-hour salt spray) ▲
Advanced: Nickel-plated brass (ASTM B258, 2000-hour salt spray) ▲▲		Superior durability and conductivity.Advanced versions may have higher material costs.
Termination TypeSecure, long-term electrical connectionsIndustry: Crimping (moderate durability)
Base/Advanced: Solder Cup (IEC 60600-3-11, gas-tight seal) ▲▲		100% gas-tight seal ensures reliable, low-resistance connections.Requires specialized soldering tools.
CertificationsCompliance-driven industries (e.g., automotive)Industry: CE (basic safety)
Base: RoHS (lead-free) ▲
Advanced: RoHS + IP67 + UL 1977 ▲▲		Meets global regulatory standards for safety and environmental compliance.Advanced certifications may delay production timelines.
Contact MaterialHigh-reliability applications (e.g., aerospace)Industry: Unplated brass
Base: Brass (ASTM B124) ▲
Advanced: Nickel-plated brass (ASTM B258) ▲▲		Enhanced corrosion resistance and longevity.Plated contacts may require additional maintenance.
