Mini MSD 315A With Fuse and Front Mount Receptacle for Servicing PHEV System Manual Service Disconnect Plug
Ready to Ship
In stock Fast dispatch

Mini MSD 315A With Fuse and Front Mount Receptacle for Servicing PHEV System Manual Service Disconnect Plug

  • 1 - 49 Pieces
    $65.05
  • 50 - 99 Pieces
    $50.09
  • >= 100 Pieces
    $47.77

Customization:

Customized logo（Min.Order: 500 pieces）
Customized packaging（Min.Order: 500 pieces）
Graphic customization（Min.Order: 500 pieces）
View product details

Mini MSD 315A With Fuse and Front Mount Receptacle for Servicing PHEV System Manual Service Disconnect Plug

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Manual Service Disconnect for PHEV Systems: Designed to safely disconnect power during maintenance of plug-in hybrid electric vehicle (PHEV) systems, ensuring operator safety by preventing accidental energization.
  • High-Capacity Electrical Protection: Features a front-mounted fuse receptacle rated for 400A/200A and 700V/20KA, safeguarding against overcurrent and voltage surges while supporting heavy-duty applications.
  • Secure Latching Mechanism: The green latch ensures a tamper-proof connection, minimizing risks of accidental disengagement during use.

Key features

  • 1. Material Technology

    • With corrosion-resistant durable plastic and IP67 protection, ensure longevity and resistance to dust/water in harsh industrial environments. 30% more durable than non-IP rated connectors

  • 2. Interactive Design

    • With an ergonomic black handle and secure green latch mechanism, enable safe, one-handed operation and prevent accidental disconnections during maintenance.

  • 3. Performance Parameters

    • With a 400A rated current and 700V capacity, handle up to 20% higher loads than standard 300A models, ensuring reliability for heavy-duty applications.

  • 4. Scenario Solutions

    • With a front-mount receptacle design, provide quick and easy access for servicing PHEV systems, streamlining maintenance in commercial or industrial settings.

  • 5. Certification Standards

    • With IP67 certification and built-in safety disconnect features, meet rigorous industrial safety standards for dust/water resistance and secure power isolation during repairs.

Product details

Mini MSD 315A With Fuse and Front Mount Receptacle for Servicing PHEV System Manual Service Disconnect Plug

The Mini MSD 315A Manual Service Disconnect Plug is a rugged, front-mount receptacle designed for servicing Plug-in Hybrid Electric Vehicle (PHEV) systems. With a durable plastic housing, IP67 protection, and a secure green latch mechanism, it ensures safety and reliability in harsh industrial or commercial environments. Its bright orange color and clear labeling enhance visibility and compliance with safety standards.

Technical specifications

FeatureSpecificationBenefit
Connector TypeReceptacle (1P)Simplifies plug-and-play servicing
IP RatingIP67Dust/waterproof for outdoor or wet areas
Rated Current200A / 400A (configurable)Supports heavy-duty PHEV systems
Voltage Rating700V, 20KAHandles high-power electrical loads
Protection LevelIP67Prevents ingress of dust and water
Fuse Rating400ASafeguards against overcurrent surges

Customization guide

Adjustable rated current (200A to 400A) to meet specific PHEV system requirements. Custom labeling or color options available for fleet-wide standardization.

Get inspired

With its IP67 rating and high current capacity, the Mini MSD 315A is ideal for maintaining PHEV systems in workshops, factories, or outdoor environments. Its front-mount design and secure latch ensure quick, safe disconnection during maintenance.

Choose your model

ParameterBase Model (200A)Advanced Model (300A)Pro Model (400A)
Rated Current200A300A (+50%)400A (+100%)*
Voltage Rating600V700V700V
Protection LevelIP54IP65IP67

Supplier's note

  1. Technical Breakthroughs:

    • 400A Fuse Rating: Enables handling of high-power PHEV systems 20% beyond industry benchmarks.
    • IP67 Compliance: Ensures operation in extreme environments, outperforming traditional IP54 models.
    • Secure Latch Mechanism: Reduces accidental disconnections by 40% compared to standard designs.

  2. Optimal Version Selection:

    • Base Model (200A): Ideal for light commercial fleets or workshops with moderate power demands.
    • Advanced Model (300A): Suitable for mid-sized industrial facilities requiring enhanced durability.
    • Pro Model (400A): Designed for heavy-duty PHEV systems in factories or high-voltage applications. With its triple-industry-standard chemical resistance and IP67 rating, it ensures safe handling of corrosive fluids and wet conditions. Pair it with reinforced insulation materials for added safety during maintenance.

Frequently asked questions

  • Which Mini MSD model is best suited for servicing PHEV systems with high current demands?

  • How do I clean and maintain the Mini MSD 315A’s contacts and latch mechanism?

  • Why is the Mini MSD 315A’s IP67 rating important for outdoor or industrial use?

  • Can the Mini MSD 315A handle 400A currents in heavy-duty applications?

  • What safety features does the green latch on the Mini MSD 315A provide?

  • Is the Mini MSD 315A compatible with custom voltage or current requirements?

  • How does the Mini MSD 315A’s orange color enhance safety during use?

  • What distinguishes the Mini MSD 315A from lower-rated service disconnect plugs?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Rated CurrentHeavy machinery, industrial systemsIndustry: 160A ▲ Our Base: 200A ▲ Our Advanced: 400A (Handles up to 400A for high-demand applications)Supports heavy-duty equipment; meets IEC 60947 standardsAdvanced models may require more installation space; higher cost for 400A variants
IP Rating (Protection)Outdoor/wet environments, automotiveIndustry: IP54 ▲ Our Base/Advanced: IP67 (Immersion up to 1m for 30min per IEC 60529)Waterproof/dustproof; ideal for harsh conditionsHigher cost for IP67-rated models compared to basic variants
Fuse ProtectionSafety-critical systemsIndustry: 250A ▲ Our Base: 200A ▲ Our Advanced: 400A (Complies with IEC 60269-6)Prevents overloads; integrated safety mechanismRequires fuse replacement training for advanced models
Connector TypePHEV systems, battery connectionsIndustry: Standard 1P ▲ Our: Front-mount 1P (Meets SAE J1772 for EV applications)Dedicated front mount for easy access; compatible with PHEV systemsCustom mounting may be required for non-standard setups
Voltage RatingHigh-voltage systems (e.g., EVs)Industry: 600V ▲ Our: 700V (Handles up to 700V DC for PHEV systems)Supports modern high-voltage batteries; future-proof for emerging techRequires specialized installation expertise
Latching MechanismSafety-critical applicationsIndustry: Basic latch ▲ Our: Green secure latch (UL-certified locking mechanism)Prevents accidental disconnection during servicingMay require operator training for secure engagement
Color & VisibilityWorkshop/industrial environmentsIndustry: Neutral colors ▲ Our: Bright orange (OSHA-compliant high visibility)Easily identifiable in cluttered spaces; reduces error-prone operationsLess aesthetically suited for indoor commercial spaces
