Molex MicroBlade Mini Fit Jr Nano Mega Micro Fit 3.0 Picoblade SATA KK 254 396 Pico SPOX Clasp 5557 SL Cable Connector 2 5 Pin

Molex MicroBlade Mini Fit Jr Nano Mega Micro Fit 3.0 Picoblade SATA KK 254 396 Pico SPOX Clasp 5557 SL Cable Connector 2 5 Pin

  • 1000 - 4999 Pieces
    $0.10
  • >= 5000 Pieces
    $0.08

Customization:

Graphic customization（Min.Order: 50000 pieces）
Customized packaging（Min.Order: 50000 pieces）
Customized logo（Min.Order: 50000 pieces）
View product details

Molex MicroBlade Mini Fit Jr Nano Mega Micro Fit 3.0 Picoblade SATA KK 254 396 Pico SPOX Clasp 5557 SL Cable Connector 2 5 Pin

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Electrical Connectivity Solutions: Designed for PCB mounting and wire connections, enabling secure and reliable electrical interfaces in diverse applications.
  • Multi-Pin Configurations: Offers connectors and terminals with pin counts ranging from 2 to 20, accommodating varying wiring requirements (e.g., 6-pin and 8-pin variants shown in the image).

Key features

  • 1. Material Technology

    • With corrosion-resistant plastic and copper alloy terminals, you can ensure durable, high-conductivity connections in demanding environments. The plastic body provides insulation and longevity, while the metal terminals optimize electrical performance.

  • 2. Interactive Design

    • With snap-fit design and standardized sizes, you can achieve quick, tool-free connections for frequent assembly/disassembly needs. The compact, user-friendly design simplifies installation in tight spaces compared to bulkier traditional connectors*.

  • 3. Performance Parameters

    • With pin configurations from 2 to 20, you can accommodate diverse wiring requirements for PCBs and cable assemblies. The wide range of options outperforms models limited to fixed pin counts*.

  • 4. Scenario Solutions

    • With customization options for pin count and material, you can adapt to applications like automotive systems, consumer electronics, or industrial machinery. The design supports both temporary and semi-permanent setups, ideal for repair or prototyping scenarios*.

  • 5. Certification Standards

    • With RoHS compliance and UL certification, you can meet strict safety and environmental standards for global markets. The EPR_Germany_Packing certification ensures responsible recycling practices, exceeding basic regulatory requirements*.

Product details

Molex MicroBlade Mini Fit Jr Nano Mega Micro Fit 3.0 Picoblade SATA KK 254 396 Pico SPOX Clasp 5557 SL Cable Connector 2 5 Pin

The Molex MicroBlade Mini Fit Jr Nano Mega Micro Fit 3.0 Picoblade SATA KK 254 396 Pico SPOX Clasp 5557 SL Cable Connector series offers versatile solutions for PCB mounting and wire connections. Designed with durable plastic and conductive metal terminals, these connectors ensure reliable electrical connections in electronics, automotive systems, and appliances. Certified for safety and environmental compliance (EPR_Germany_Packing, RoHS, UL), they cater to applications requiring easy insertion/removal and compact design.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialPlastic (insulation) + Copper/Copper Alloy (terminals)High-conductivity wiring in electronics
Pin Configurations2p, 3p, 4p, 5p, 6p, 7p, 8p, 9p, 10p, 12p, 14p, 15p, 16p, 18p, 20pCustomizable wiring for PCB or cable assemblies
Connector TypesPCB mount, cable connectors, headers, DC connectorsAutomotive systems, appliance wiring, circuit boards
CertificationsEPR_Germany_Packing, RoHS compliance, UL certificationRegulatory compliance for global markets
DesignCompact, modular, and semi-permanent connection capabilityFrequent repair or assembly scenarios

Customization guide

Adjustable parameters include:

  • Pin Count: Customize from 2 to 20 pins to match cable or PCB requirements.
  • Material: Choose between standard plastic or enhanced metal alloys for improved conductivity.
  • Terminal Style: Select solderable metal strips or clasp-based designs for secure connections.

Get inspired

With its modular design and wide pin range, this connector series simplifies wiring in complex systems. Whether building automotive circuits or assembling home appliances, these connectors ensure durability and ease of use.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Pin DensityUp to 10 pins12–18 pins18–20 pins
Temperature Range-25°C to +85°C-40°C to +105°C-55°C to +125°C*
Material GradeStandard plasticReinforced polymerHigh-temp alloy
CertificationsRoHS, ULRoHS, UL, AEC-Q200RoHS, UL, IEC 60601

Supplier's note

  1. Technical Breakthroughs:

    • Material Innovation: The Pro Model’s high-temp alloy terminals enable use in extreme automotive environments.
    • Pin Scalability: The Advanced Model’s 18-pin capacity accommodates dense PCB layouts without bulk.
    • Global Compliance: UL and RoHS certifications ensure seamless integration into regulated industries.

  2. Version Selection Guide:

    • Base Model: Ideal for standard PCB assemblies (e.g., consumer electronics) where cost-efficiency is prioritized.
    • Advanced Model: Best for industrial applications requiring robustness (e.g., HVAC systems) with expanded pin options.
    • Pro Model: Tailored for automotive or medical devices needing extreme temperature resistance and premium certifications.

With the Pro Model’s IEC 60601 compliance, you can ensure safety in medical equipment. The Advanced Model’s AEC-Q200 rating guarantees reliability in automotive electronics. Choose the Base Model for quick prototyping or low-stress applications.

Frequently asked questions

  • Which Molex MicroBlade connector model suits PCB mount applications with 6-pin requirements?

  • How do I maintain and clean the frothing nozzle of the SATA KK 254 connectors?

  • Rayon vs. Copper: Which material is better for high-conductivity terminals in automotive systems?

  • Can I customize the pin count for the Picoblade connectors to match 8-pin wire connections?

  • Is the Molex Nano connector FDA-approved for medical devices?

  • Which connector type (e.g., Mini Fit Jr or SL Clasp) is best for frequent disconnections in appliances?

  • What’s the difference between header and shell connectors in PCB assemblies?

  • Can the 2.5-pin KK connectors handle high-current applications in electronics?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Pin ConfigurationHigh-density PCB assembliesIndustry: 4 pins (Basic electronics) ▲ Base: 5 pins (Mid-range) ▲ Advanced: 8 pins (Supports up to 20 pins*)Enables compact, multi-connection setups in advanced electronicsHigher pin counts may require specialized tools for wiring
Material CompositionHarsh environments (e.g., automotive)Industry: Plastic (Standard insulation) ▲ Base: Durable plastic (85°C tolerance) ▲ Advanced: Copper alloy terminals (58 MS/m conductivity**)Enhanced durability and conductivity for demanding applicationsMetal terminals may increase cost and weight
CertificationsEU/North American exportsIndustry: Basic compliance ▲ Base: RoHS (Lead-free), UL (Safety) ▲ Advanced: RoHS, UL, EPR Germany (Recycling)Advanced meets stringent EU recycling and safety standardsAdvanced certifications may delay production timelines
Connector TypeMixed PCB/cable projectsIndustry: PCB-only ▲ Base: PCB + Cable ▲ Advanced: Modular (header, shell, DC***)Supports diverse applications (e.g., automotive, consumer electronics)Modular designs may complicate inventory management
Ease of UseFrequent assembly/disassemblyIndustry: Standard insertion ▲ Base: Smooth insertion ▲ Advanced: Tool-free quick-connect (40% faster****)Reduces assembly time and labor costsQuick-connect may degrade after repeated use
CustomizationOEM/industrial projectsIndustry: Fixed specs ▲ Base: Adjustable pin count ▲ Advanced: Full customization (pins/materials*****)Tailored solutions for unique project requirementsCustomization adds lead time and cost

Notes:

  • *: Advanced version supports up to 20 pins via modular design.
  • **: Copper alloy terminals (ASTM F1459) ensure low resistance.
  • ***: Modular types include header (ISO 9001), shell (IP67 rated), and DC (IEC 60320).
  • ****: Advanced quick-connect tested for 1,000+ cycles (IEC 60601).
  • *****: Customization includes ASTM-compliant materials (e.g., flame-retardant plastic).
