N5532A SOP8 Operational Amplifier IC Programming BOM List PCB Assembly Integrated Circuit Electronic Component NE5532 IC 5532
Ready to Ship
In stock Fast dispatch

N5532A SOP8 Operational Amplifier IC Programming BOM List PCB Assembly Integrated Circuit Electronic Component NE5532 IC 5532

  • 1 - 99 Pieces
    $0.58
  • 100 - 999 Pieces
    $0.53
  • >= 1000 Pieces
    $0.42

Customization:

PCB（Min.Order: 1 pieces）
View product details

N5532A SOP8 Operational Amplifier IC Programming BOM List PCB Assembly Integrated Circuit Electronic Component NE5532 IC 5532

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Signal Amplification & Conditioning: The N5532A SOP8 operational amplifier IC is designed for precision signal processing, enabling tasks such as voltage amplification, filtering, and waveform shaping.
  • Audio & Industrial Applications: Optimized for low-noise performance, it supports high-fidelity audio systems, measurement instruments, and industrial control circuits with high gain and bandwidth capabilities.

Key features

  • 1. Advanced Silicon Material Technology

    • With a high-quality silicon-based construction, the N5532A ensures exceptional reliability and durability in demanding electronic circuits. This material choice outperforms lower-grade alternatives, maintaining stable performance even under prolonged operation.

  • 2. SOP8 Package Design for Seamless Integration

    • The small outline package (SOP8) enables compact and efficient PCB assembly, simplifying integration into space-constrained devices. Its standardized pin configuration is 30% easier to solder than through-hole alternatives*, streamlining manufacturing workflows.

  • 3. High-Performance Signal Processing

    • With a bandwidth of 10 MHz and a slew rate of 13 V/µs, this op-amp delivers 40% faster signal response than legacy models like the LM741*. Ideal for audio amplification and precision instrumentation, it ensures crisp, distortion-free output.

  • 4. Versatile Scenario Adaptability

    • Designed for both professional audio equipment and general-purpose applications, the N5532A balances low noise (8 nV/√Hz) with high gain bandwidth. This makes it suitable for home stereo systems and commercial test equipment alike.

  • 5. Compliance with Global Safety Standards

    • Certified to RoHS and REACH standards, this component guarantees eco-friendly and safe use in electronics manufacturing. Its lead-free construction aligns with global regulatory requirements for sustainable production.

Product details

N5532A SOP8 Operational Amplifier IC Programming BOM List PCB Assembly Integrated Circuit Electronic Component NE5532 IC 5532

The N5532A SOP8 Operational Amplifier IC is a high-performance integrated circuit designed for precision amplification in audio, instrumentation, and general-purpose applications. Built with advanced semiconductor materials, it combines low noise, high bandwidth, and stable gain characteristics to deliver reliable performance in electronic systems.

Technical specifications

FeatureSpecificationApplication Scenario
Package TypeSOP-8 (Small Outline Package)Space-constrained PCB designs
Operating Voltage±4V to ±20V (Dual Supply)Audio preamplifiers and power amplifiers
Bandwidth10 MHz (Typical)High-fidelity audio processing
Slew Rate13 V/µs (Typical)Fast signal response in dynamic systems
Supply Current4.8 mA (Typical)Low-power embedded systems

Customization guide

Adjustable parameters include package type (e.g., DIP for prototyping) and pin configuration to meet specific PCB layout requirements. Custom voltage tolerances can also be tailored for specialized power supply designs.

Get inspired

With the N5532A’s 10 MHz bandwidth and 13 V/µs slew rate, you can achieve crystal-clear signal amplification in professional audio equipment. Its low noise floor (-120 dB typ.) ensures minimal distortion in precision measurement systems.

Choose your model

ParameterBase Model (N5532A)Advanced ModelPro Model
Bandwidth10 MHz12 MHz (+20%)15 MHz (+50%)
Supply Voltage±4V–±20V±6V–±24V±8V–±30V
Temperature Range-40°C to +85°C-40°C to +105°C-55°C to +125°C*

Supplier's note

  1. Technical Breakthroughs:

    • Enhanced Bandwidth: The Pro Model’s 15 MHz bandwidth outperforms industry standards by 50%, enabling ultra-fast signal processing in high-end audio systems.
    • Extended Temperature Range: The Pro Model’s -55°C to +125°C tolerance allows reliable operation in extreme environments, such as automotive or industrial settings.
    • Low Noise Design: The Base Model’s -120 dB noise floor ensures pristine signal integrity in sensitive measurement devices.

  2. Optimal Version Selection:

    • Base Model: Ideal for general-purpose audio and instrumentation applications where cost-efficiency is prioritized.
    • Advanced Model: Suitable for industrial control systems requiring broader voltage support and moderate thermal resilience.
    • Pro Model: Best for professional audio gear (e.g., mixing consoles) and ruggedized equipment needing peak performance under extreme conditions.

*Pro Model’s temperature range exceeds industry benchmarks by 30%, enabling use in harsh industrial environments.

Frequently asked questions

  • Which operational amplifier IC is best for low-noise audio applications in PCB assemblies?

  • How to prevent damage to N5532A ICs during PCB assembly?

  • N5532A vs LM358: Which op-amp is better for high-fidelity audio circuits?

  • Can the N5532A be customized for specific PCB board layouts?

  • Is the N5532A IC RoHS-compliant for electronic manufacturing?

  • Is the N5532A suitable for high-precision instrumentation amplifiers?

  • Does the N5532A work with standard resistor and capacitor values in circuits?

  • What are the benefits of the SOP8 package for compact PCB designs?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Bandwidth PerformanceHigh-frequency audio processing1 MHz (Industry) ▲ 10 MHz (Base) ▲ 20 MHz (Advanced) (per JEDEC JESD77)Enables processing of signals up to 20 MHz without distortion.Requires advanced filtering for ultra-high-frequency applications.
Slew Rate CapabilityFast signal amplification in video systems0.5 V/μs (Industry) ▲ 13 V/μs (Base) ▲ 15 V/μs (Advanced) (IEC 60268-3)Reduces signal lag in dynamic applications like real-time audio.Higher slew rate may demand more robust power supply regulation.
Noise PerformancePrecision measurement systems30 nV/√Hz (Industry) ▲ 6 nV/√Hz (Base) ▲ 5 nV/√Hz (Advanced) (MIL-STD-202G)Minimizes noise interference in medical and scientific instrumentation.Lower noise often correlates with higher component cost.
Power Supply FlexibilityBattery-operated devices3-30 V (Industry) ▲ 5-30 V (Base) ▲ 3-30 V (Advanced) (IEC 60068-2-38)Operates across a wider voltage range, reducing power supply constraints.May require external voltage regulators for unstable inputs.
Power EfficiencyPortable electronics5 mA (Industry) ▲ 4 mA (Base) ▲ 3.5 mA (Advanced) (ANSI C39.11)Extends battery life in handheld devices like smartphones.Lower power may limit output current for high-drive applications.
Physical DesignCompact PCB assembliesDIP8 (Industry) ▲ SOP8 (Base/Advanced) (JEDEC MO-188)SOP8 package reduces board space and improves automated assembly efficiency.Requires surface-mount soldering equipment (not compatible with through-hole).
