Normally Closed Angle Tactile Tact Switch

Name: Normally Closed Angle Tactile Tact Switch
Brand: Shenzhen Intech Electronic Technology Limited
SKU: 60812857854_1
Price: 0.02 USD
Availability: InStock
Rating: 4.8 (100 reviews)

Product overview

Core functionalities

Applicable scenarios

Unique advantages

Tactile Feedback Mechanism: Provides distinct physical feedback upon actuation, ideal for user interfaces in electronic devices like keyboards, game controllers, and smart appliances.
Normally Closed Design: Maintains circuit continuity until pressed, ensuring fail-safe operation in critical systems such as safety switches or emergency stop mechanisms.

Key features

1. Material Technology

With a corrosion-resistant brass body and silicone tactile cap, ensure durability and reliable operation in diverse environments.

2. Interactive Design

With an angled tactile design and SMD mounting, enable easy integration into compact devices and intuitive user interaction.

3. Performance Parameters

With 100mΩ insulation resistance and 12V rating, ensure efficient power transmission and compatibility with standard voltage systems.

4. Scenario Solutions

With waterproof construction and SMD compatibility, ideal for both consumer electronics and moisture-prone commercial applications.

5. Certification Standards

With materials designed to meet electrical safety standards, ensure reliable performance in certified applications.

Product details

The Normally Closed Angle Tactile Tact Switch is a durable, compact switch designed for seamless integration into electronic devices. With a metallic body and elastomer cap, it offers reliable tactile feedback and robust performance in applications requiring frequent activation.

Technical specifications

Feature	Specification	Benefit
Material	Metallic body (brass), plastic cap	Enhanced durability and conductivity
Insulation Resistance	100mΩ	Ensures electrical safety under load
Voltage Rating	12V (max)	Safe operation in standard electronic systems
Tactile Feedback	Adjustable force	Clear user interaction confirmation
Mounting Type	SMD (surface-mount)	Simplified assembly and compact design
Waterproofing	IP67 (optional)	Resists moisture for harsh environments

Customization guide

Adjustable parameters include:

Size/Shape: Customize dimensions to fit specific device constraints.
Contact Resistance: Optimize for low-resistance applications (e.g., 50–100mΩ).
Color/Finish: Choose from multiple cap colors to match device aesthetics.

Get inspired

Ideal for compact devices like wearable tech, gaming controllers, or industrial interfaces. The tactile feedback and waterproof options make it versatile for both consumer and professional use.

Choose your model

Parameter	Base Model	Advanced Model	Pro Model
Waterproof Rating	IP54	IP67	IP68
Contact Resistance	100mΩ	80mΩ (+20% improvement)	50mΩ (+50% improvement)*
Voltage Handling	12V (base)	15V (+25% capacity)	24V (+100% capacity)*
Tactile Feedback	Standard	Enhanced	Premium
Lifespan	50,000 cycles	100,000 cycles	200,000 cycles

Supplier's note

Technical Breakthroughs:
- IP68 Waterproofing (Pro Model): Enables use in marine or outdoor devices.
- Low Contact Resistance: Reduces energy loss in high-current applications.
- SMD Mounting: Cuts assembly time by 30% compared to through-hole alternatives.
Version Selection Guide:
- Base Model: Best for basic electronics (e.g., remote controls) with standard environmental needs.
- Advanced Model: Ideal for industrial tools or medical devices requiring IP67 protection and extended lifespan.
- Pro Model: Perfect for high-end gaming peripherals or underwater equipment needing IP68 and 24V compatibility.

With the Pro’s IP68 rating, you can deploy switches in water-exposed systems like smart showers or marine sensors. Pair its low contact resistance with high-voltage specs to ensure stable performance in demanding setups.

Frequently asked questions

Which Normally Closed Tact Switch suits low-voltage electronics like Arduino projects?
How do I clean the contacts of a tactile switch without damaging them?
What materials make the Normally Closed Tact Switch durable for industrial use?
Can I customize the color and shape of tactile switches for a product design?
Is the Normally Closed Tact Switch FDA-approved for medical devices?
What applications are best for SMD-mounted tactile switches?
How does the Normally Closed Tact Switch ensure reliability in humid environments?
Are there angle-adjustable options for mounting tactile switches in tight spaces?

Product comparison

Category	Usage Scenarios	Characteristics	Advantages	Disadvantages
Insulation Resistance	Industrial Equipment	Industry: 50mΩ (IEC 60068) ▲ Base: 100mΩ ▲ Advanced: 150mΩ	Enhanced fault protection in harsh environments	Advanced versions may cost more or require thicker materials
Voltage Rating	High-Power Devices (e.g., industrial controls)	Industry: 9V (IEC 60947-5-1) ▲ Base: 12V ▲ Advanced: 18V	Supports high-power applications like robotics or machinery	Higher voltage may demand thicker wiring and safety certifications
Mounting Type	Compact Electronics (e.g., smartphones)	Industry: Through-Hole ▲ Base: SMD (JEDEC MO-200) ▲ Advanced: Hybrid SMD	Smaller footprint for SMD, easier automated assembly	Through-hole easier for manual soldering; advanced may need specialized tools
Tactile Feedback	User Interfaces (e.g., keyboards, game controllers)	Industry: Basic tactile ▲ Base: 0.5N force (ISO 9283) ▲ Advanced: Adjustable	Clearer feedback for precision input devices	Advanced versions may add complexity to design and calibration
Waterproofing	Outdoor Devices (e.g., weatherproof panels)	Industry: Non-waterproof ▲ Base: IP54 (IEC 60529) ▲ Advanced: IP67	Operates in wet/dusty environments like outdoor panels	Advanced versions may have slower actuation speed due to sealing materials
Customization	Consumer Goods (e.g., branded electronics)	Industry: Limited colors ▲ Base: 10+ colors (ASTM D5097) ▲ Advanced: Custom shapes	Better branding and aesthetics for consumer products	Custom options may increase lead time and per-unit cost
