OBD 16Pin Connector Female Male PCB Solder OBD2 OBDII J1962 Connector

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Vehicle Diagnostics & Data Transmission: Designed for OBD2/J1962 systems to interface with automotive ECUs for diagnostics, emissions testing, and data logging.
  • Robust PCB Solder Connection: 16-pin configuration with tin/copper contacts ensures secure soldering to printed circuit boards for reliable electrical connectivity.

Key features

  • 1. Material Technology

    • With tin-plated copper contacts and an ABS plastic body, ensure superior conductivity, corrosion resistance, and durability in harsh automotive environments.

  • 2. Interactive Design

    • With a modular design and customizable pin configurations, adapt to diverse automotive and PCB mounting requirements, offering greater flexibility than fixed-pin connectors.

  • 3. Performance Parameters

    • With a 16-pin configuration and solder termination, handle complex automotive systems with high signal integrity and robust mechanical stability, outperforming lower-pin connectors in multi-function applications.

  • 4. Scenario Solutions

    • Designed for automotive environments, ensure reliable operation in extreme temperatures and vibrations, making them ideal for OBD2/J1962 diagnostics in both commercial and consumer vehicles.

  • 5. Certification Standards

    • Complies with OBD2/J1962 standards, ensuring seamless compatibility with automotive diagnostic tools and systems, unlike non-certified alternatives.

Product details

OBD 16Pin Connector Female Male PCB Solder OBD2 OBDII J1962 Connector

The OBD 16Pin Connector is a rugged, modular PCB solder connector designed for automotive and industrial applications. With 16 pins arranged in a grid pattern and a durable ABS housing, it ensures secure, high-reliability connections in harsh environments. The copper contacts and tin plating provide optimal conductivity, while the solder termination ensures stable electrical performance.

Technical specifications

FeatureSpecificationBenefit
MaterialCopper contacts, ABS plastic housingEnhanced durability and corrosion resistance
Pins16-pin grid configurationSupports complex circuit integration
TerminationSolderSecure, permanent connection for PCBs
ApplicationAutomotive, industrial, PCB mountingVersatile for OBD2 diagnostics and IoT systems
Temperature Range-40°C to +105°CWithstands extreme environmental conditions

Customization guide

Adjustable pin spacing and plug compatibility allow customization for specific device interfaces. The modular design supports tailoring pin arrangements to match OEM requirements or integrate with non-standard connectors.

Get inspired

Designed for reliability, these connectors are ideal for automotive diagnostics, industrial control systems, and IoT devices. Their robust construction ensures long-term performance in vibration-prone or high-temperature environments.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Pin Density16 fixed pins16 pins (adjustable spacing)16 pins + customizable grid layout
Temperature Range-40°C to +105°C-40°C to +125°C-55°C to +150°C*
Chemical ResistanceStandard ABSFlame-retardant ABSUV-resistant, chemical-grade ABS
CertificationISO 16750-3ISO 16750-3 + IP67ISO 16750-3 + IP68

Supplier's note

  1. Technical Breakthroughs:

    • Copper Contacts: Triple-layer tin plating reduces contact resistance by 20% compared to standard connectors, ensuring stable high-current transmission.
    • Modular Design: Adjustable pin spacing accommodates 15% more device compatibility than fixed-pin alternatives.
    • UV-Resistant ABS: The Pro model’s housing withstands 30% more UV exposure than industry benchmarks, ideal for outdoor IoT deployments.

  2. Version Selection Guide:

    • Base Model: Best for standard automotive diagnostics (e.g., OBD2 scanners) where temperature and chemical exposure are moderate.
    • Advanced Model: Suitable for industrial machinery or marine electronics requiring IP67 water resistance and wider temperature tolerance.
    • Pro Model: Designed for extreme environments (e.g., aerospace, oil rigs) with its IP68 rating and -55°C to +150°C range. With its customizable pin layout, it also supports specialized robotics interfaces.

*Pro Model’s temperature range exceeds SAE J2045 automotive standards by 30%.

Frequently asked questions

  • Which OBD connector suits automotive diagnostics systems with PCB mounting requirements?

  • How to clean OBD2 connectors to prevent corrosion without damaging contacts?

  • Tin vs. Gold contacts: Which is better for automotive OBD connectors?

  • Can I customize the pin configuration of OBD2 connectors for specialized automotive systems?

  • Is the OBD2 connector compliant with J1962 standards for automotive diagnostics?

  • Why choose solder termination for PCB-mounted OBD connectors?

  • What makes this OBD connector durable for harsh automotive environments?

  • How does the 16-pin design ensure compatibility with OBDII standards?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Industry Standard OBD2 ConnectorBasic automotive diagnosticsABS housing (ISO 9001), 16-pin (IEC 60603), tin-plated brass contacts (ASTM B209)Cost-effective, widely compatible with standard toolsLimited durability in harsh environments, no EMI shielding, no temperature rating
Our Base Tier OBD2 ConnectorStandard automotive diagnosticsCopper contacts with tin plating (ASTM B209), 16-pin (ISO 3801), solder termination (IEC 60695) ▲
Modular design (▲)		Higher conductivity than brass, supports 16 pins, easy PCB mountingNo advanced environmental sealing, basic temperature range (-20°C to 85°C)
Our Advanced Tier OBD2 ConnectorHeavy-duty industrial/automotive systemsGold-plated copper contacts (MIL-STD-883), 16-pin with locking mechanism (▲▲)
Flame-retardant housing (UL 94 V-0) ▲▲
Operates -40°C to 125°C (▲▲)		Enhanced durability, EMI shielding (▲), wide temperature tolerance, secure lockingHigher cost, bulkier design compared to base tier
High-Temperature OBD2 ConnectorEngine control units, high-heat systemsGlass-reinforced nylon housing (UL 94 V-0), 14-pin, nickel-plated contacts (ASTM B489)Operates up to 150°C, resistant to thermal shockLimited pin count (14 vs 16), less flexible for customization
Modular OBD2 AdapterCustom systems, robotics8-24 pin customizable (▲), snap-fit design, nylon housingFlexible pin configuration, easy assemblyLower durability in vibration-heavy environments, no EMI shielding
Industrial High-Reliability OBD2Industrial machinery, roboticsMetal alloy housing (ASTM F1564), 16-pin with IP67 sealing (▲▲), gold-plated contacts (MIL-STD-883)IP67 dust/water resistance, vibration-resistant, EMI shielding (▲▲)Bulky design, higher cost, limited temperature range (-25°C to 85°C)
