ORIEMAC Horizontal Directional Drilling Tracker Locator 50m Horizontal Directional Drill XZ500

ORIEMAC Horizontal Directional Drilling Tracker Locator 50m Horizontal Directional Drill XZ500

  • 1 - 2 Units
    $50,500
  • >= 3 Units
    $50,000

Customization:

Customized logo（Min.Order: 1 pieces）
Customized packaging（Min.Order: 1 pieces）
Graphic customization（Min.Order: 1 pieces）
View product details

ORIEMAC Horizontal Directional Drilling Tracker Locator 50m Horizontal Directional Drill XZ500

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Precision Drilling & Tracking: Equipped with a Horizontal Directional Drilling Tracker Locator, enabling accurate guidance for underground pipe/cable installation with a maximum drilling depth of 50m and diameter capacity of 500mm.
  • Robust Rotary Drilling: Powered by a diesel engine and featuring crawler mobility, ensuring stable operation on uneven terrain while delivering high torque for efficient drilling in hard soil or rock.

Key features

  • 1. Material Technology

    • With a corrosion-resistant steel and aluminum alloy frame, ensure long-lasting durability in harsh construction environments. The robust design withstands heavy-duty use, maintaining structural integrity even in abrasive conditions.

  • 2. Interactive Design

    • With a user-friendly control panel featuring multi-program presets, adjust drilling parameters quickly for precise depth and diameter control (up to 50m and 500mm). Streamline operations with intuitive touchscreen interface access.

  • 3. Performance Parameters

    • With a 50m drilling depth and 500mm diameter capacity, tackle large-scale projects ~20% faster than traditional models*. The diesel-powered engine delivers consistent power, paired with 380V voltage for reliable performance in demanding scenarios.

  • 4. Scenario Solutions

    • With crawler mobility and trenching capabilities, operate efficiently on uneven terrain for commercial infrastructure projects. The tracked system ensures stability during excavation and material transport, ideal for rugged construction sites.

  • 5. Certification Standards

    • With compliance to industry safety and durability standards, ensure reliable operation in high-risk environments. Certification details are subject to manufacturer confirmation for specific project requirements.

Product details

ORIEMAC Horizontal Directional Drilling Tracker Locator 50m Horizontal Directional Drill XZ500

The ORIEMAC XZ500 Horizontal Directional Drilling Tracker Locator is a robust drilling rig designed for precise trenchless installation of pipelines, cables, and utilities. Equipped with a diesel engine and crawler mobility, it offers 50m drilling depth and 500mm diameter capacity, making it ideal for construction, mining, and infrastructure projects.

Technical specifications

FeatureSpecificationBenefit
Drilling Depth50mEnables deep utility installation in challenging terrains.
Drilling Diameter500mmAccommodates large-diameter pipelines and cables.
Engine TypeDiesel-PoweredEnsures robust performance in remote, off-grid locations.
Mobility SystemCrawler TracksProvides superior stability and traction on uneven terrain.
Hydraulic SystemHigh-Pressure DesignEnhances precision and control during drilling operations.
Safety FeaturesGuarded ComponentsReduces operational risks and ensures operator safety.
Warranty1 Year ComprehensiveGuarantees reliability and post-purchase support.

Customization guide

Adjustable arm lengths and conveyor configurations can be tailored to meet specific terrain or material handling needs. The hydraulic system’s pressure settings are customizable for varying drilling depths and soil conditions.

Get inspired

With its crawler mobility and 50m drilling capability, the XZ500 excels in trenchless construction projects, minimizing surface disruption. Ideal for installing waterlines, telecommunications cables, or gas pipelines in urban or rugged environments.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Drilling Depth50m+15% (57.5m)+30% (65m)*
Drilling Diameter500mm+20% (600mm)+40% (700mm)
Engine Power100HP120HP150HP
Traction Force5,000kg+20% (6,000kg)+40% (7,000kg)
Hydraulic Pressure200bar220bar240bar

Supplier's note

  1. Three Technical Breakthroughs:

    • Diesel Efficiency: The advanced combustion system reduces fuel consumption by 18% compared to traditional diesel engines.
    • Crawler Mobility: The tracked design provides 20% better ground pressure distribution than wheeled models, ensuring stability on soft terrain.
    • Precision Tracking: The hydraulic system’s real-time feedback mechanism improves drilling accuracy by 25% in uneven substrates.

  2. Optimal Version Selection:

    • Base Model: Ideal for small-scale contractors handling standard pipelines (≤500mm) in stable terrain.
    • Advanced Model: Suitable for medium-sized projects requiring deeper drilling (up to 57.5m) or larger diameters (600mm).
    • Pro Model: Best for large infrastructure firms needing extreme depth (65m) and heavy-duty applications (e.g., oil/gas pipelines).

With the Pro model’s 240bar hydraulic pressure, you can penetrate hard rock formations 30% faster than industry benchmarks. Pair this with its 150HP engine to achieve uninterrupted operation in remote mining sites.

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Horizontal Directional Drill (HDD)Underground utility installation, pipeline laying- Drilling Depth: 50m (▲12.5% vs Industry Standard 45m)
- Diameter: 500mm (ISO 13673 compliant)
- Diesel Engine: 100HP (ISO 8178 certified)
- Crawler Mobility: 50kPa ground pressure (enhances stability)		- High precision for sensitive underground projects
- Versatile for pipelines/cables
- Stable on uneven terrain		- Higher upfront cost
- Requires skilled operators for alignment
Rotary Drilling RigMineral exploration, oil drilling- Drilling Depth: 150m (▲200% vs HDD)
- Diameter: 1000mm (ASTM F1948)
- Power: 200HP (ISO 8528)		- Deeper drilling capability
- Handles large-scale projects
- Adaptable to hard rock formations		- Bulky and less mobile
- Higher fuel consumption
- Longer setup time
Trenching MachineTrench digging for pipelines/cables- Trench Depth: 3m (▲50% vs Industry Avg 2m)
- Conveyor Capacity: 5m³/min (ISO 5009)
- Track Width: 1.2m (ISO 6357)		- Rapid trenching for utilities
- Integrated material removal via conveyor
- Compact design for tight spaces		- Limited to trenching tasks
- Higher maintenance due to moving parts
- Noise pollution (▲85 dBA)
ExcavatorEarthmoving, demolition- Bucket Capacity: 1.5m³ (ISO 670)
- Digging Depth: 8m (▲33% vs Industry 6m)
- Swing Speed: 12 RPM (ISO 6165)		- Versatile for multi-tasking (digging, lifting)
- High torque for tough terrain
- Adjustable attachments		- High fuel consumption
- Bulky footprint limits mobility in narrow areas
- Requires skilled operator
Crawler LoaderSite preparation, material loading- Load Capacity: 3T (ISO 3457)
- Ground Pressure: 50kPa (enhances traction)
- Turning Radius: 2.5m (ISO 5010)		- Stable on soft/uneven terrain
- Durable for heavy-duty tasks
- Compact for confined spaces		- Limited to loading/digging tasks
- Lower speed compared to wheeled loaders
- Higher purchase cost
Portable Drill RigSmall-scale drilling, remote areas- Drilling Depth: 20m (▲-60% vs HDD)
- Compact Design: 2m³ (ISO 7095)
- Weight: 1.5T (ISO 3095)		- Easy transport via truck
- Lower cost and maintenance
- Quick setup (15 mins)		- Limited to shallow drilling
- Reduced power for hard materials
- Less precise for complex projects
