Oem Printed Circuit Board Electrical Pulse Physiotherapy Apparatus Other PCB&PCBA TENS Equipment Gerber File Bom List Services

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Electrical Pulse Therapy Support: Designed for TENS (Transcutaneous Electrical Nerve Stimulation) devices to deliver precise, adjustable electrical pulses for pain relief and muscle stimulation.
  • OEM Customization: Provides Gerber files and Bill of Materials (BOM) lists for tailored PCB/PCBA solutions, enabling seamless integration into medical devices.
  • Compliance-Ready Design: Built with certifications (CE, RoHS, EPR) to ensure safety and regulatory compliance for medical-grade applications.

Key features

  • 1. Material Technology

    • With a durable FR4 substrate and advanced surface finishes (HASL/Immersion Tin/ENIG), ensure reliable conductivity and corrosion resistance in medical environments.

  • 2. Interactive Design

    • With a modular design featuring RCA connectors and adjustable potentiometers, customize parameters like pulse intensity for tailored physiotherapy solutions.

  • 3. Performance Parameters

    • With a robust power supply system (AC/DC compatibility and high-capacity capacitors), deliver stable energy for precise TENS pulse generation.

  • 4. Scenario Solutions

    • With certified compliance for home appliance applications, safely integrate into TENS devices for household use while supporting scalable commercial adaptations.

  • 5. Certification Standards

    • With multi-regional certifications (CE, RoHS, EPR-France/Germany), ensure compliance with EU environmental and safety regulations for global deployment.

Product details

Oem Printed Circuit Board Electrical Pulse Physiotherapy Apparatus Other PCB&PCBA TENS Equipment Gerber File Bom List Services

The Oem Printed Circuit Board (PCB) for TENS equipment is a high-performance electrical pulse physiotherapy apparatus designed for home healthcare applications. Built with robust FR4 material and advanced surface finishing options, this PCB supports customizable configurations to meet diverse medical and compliance requirements.

Technical specifications

FeatureSpecificationBenefit
CertificationsCE, RoHS, EPR (France/Germany WEEE & Packing)Ensures compliance with EU environmental and safety standards.
Surface FinishingHASL, Immersion Tin, ENIGEnhances solderability, corrosion resistance, and longevity.
ConnectivityRCA audio input/output (as per design)Supports integration with standard audio interfaces for signal transmission.
ModularityAdjustable potentiometers and modular designEnables customization of pulse frequency, amplitude, and output parameters.

Customization guide

Adjustable potentiometers allow users to fine-tune electrical pulse parameters (e.g., frequency, amplitude) to meet specific therapeutic needs. Surface finishing options (ENIG for high-reliability environments, HASL for cost-sensitive applications) can be selected based on durability and compliance requirements.

Get inspired

Transform your TENS device into a precision therapeutic tool with this versatile PCB. Whether you need a compact home solution or a professional-grade unit, its modular design and certified components ensure safe, effective, and customizable performance.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Surface FinishingHASLImmersion Tin (+10%)ENIG (+25% corrosion resistance)*
CertificationsCE, RoHS+EPR GermanyFull EPR (France/Germany)
Power Output50V max75V max100V max
Adjustable ParametersFrequency onlyFrequency + AmplitudeFull parameter control

Supplier's note

  1. Technical Breakthroughs:

    • ENIG Surface Finishing: The Pro model’s Electroless Nickel Immersion Gold coating reduces oxidation by 30% compared to HASL, ensuring longevity in humid environments.
    • Full EPR Compliance: The Pro model meets all French and German waste/electronics regulations, enabling seamless EU market entry.
    • Modular Design: Adjustable potentiometers allow real-time parameter tuning, a 40% improvement over fixed-design competitors.

  2. Optimal Version Selection:

    • Home Users: Base Model suffices for basic TENS applications (e.g., muscle relaxation) with standard CE/RoHS compliance.
    • Clinics/Professionals: Advanced Model offers expanded voltage and EPR Germany certification for regulated healthcare settings.
    • High-End Therapeutic Use: Pro Model’s ENIG and full EPR compliance, paired with full parameter control, cater to demanding medical environments requiring peak durability and regulatory adherence.

*Comparative data based on industry benchmarks for corrosion resistance in ENIG vs. HASL.

Frequently asked questions

  • Which PCB suits TENS equipment for home use?

  • How to clean the components on a Hi-Fi amplifier PCB?

  • HASL vs ENIG for audio PCBs: Which is better for durability?

  • Can this PCB be customized for specific audio needs?

  • Is the PCB RoHS and CE certified for EU markets?

  • Does the PCB support both AC and DC power inputs?

  • How to adjust the gain on the amplifier module?

  • Why is FR4 material used in this audio PCB?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Surface FinishTENS Equipment, Home Appliances▲ HASL (Lead-free) ▲▲ ENIG (Solder Mask Defined)
(Industry: HASL; Our Base: HASL + RoHS; Our Advanced: ENIG)		Cost-effective (Base), corrosion resistance (Advanced), RoHS complianceHigher cost for ENIG, potential environmental concerns without RoHS compliance (Industry)
Compliance CertificationsEU Market Compliance▲ CE ▲▲ Multiple EPR (France/Germany) + RoHS
(Industry: CE; Our Base: CE + RoHS; Our Advanced: Full EPR + RoHS)		Wider market access (Advanced), EU regulatory alignment, reduced legal risksHigher certification costs for Advanced tier, limited compliance in non-EU regions (Base)
Signal IntegrityAudio Amplification, Medical Devices▲ FR4 Material ▲▲ Enhanced Grounding
(Industry: Basic FR4; Our Base: FR4 + Grounding; Our Advanced: Optimized Layout)		Reduced noise (Advanced), stable signal transmission, modular design flexibilityHigher complexity in manufacturing (Advanced), susceptibility to interference (Industry)
Thermal PerformanceHigh-Power Applications▲ Basic Thermal Design ▲▲ Advanced Thermal Solutions
(Industry: Passive Cooling; Our Base: Heat Sinks; Our Advanced: Active Cooling)		Prevents overheating (Advanced), prolonged component lifespanIncreased power consumption (Advanced), bulkier design (Base)
Customization OptionsDIY Audio Systems, Specialty Electronics▲ Limited Modularity ▲▲ Full Customization
(Industry: Fixed Layout; Our Base: Modular Slots; Our Advanced: User-Defined Components)		Tailored performance (Advanced), scalability for projects, future-proof designHigher assembly complexity (Advanced), costlier customization (Base)
Power HandlingTENS Devices, High-Current Systems▲ Standard Components ▲▲ High-Performance Components
(Industry: 1A Max; Our Base: 3A; Our Advanced: 5A +)		Supports demanding loads (Advanced), stable power delivery, reduced voltage dropsRequires robust power supplies (Advanced), bulkier form factor (Base)
