PCB Copper Plating / Panel Plating Machine

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Precision Electroplating: High-precision copper plating and panel plating using rack plating technology, designed to ensure uniform coating thickness and consistent quality for PCBs and metal panels.
  • Industrial Automation: Equipped with automated processes and sensors/actuators for efficient, repeatable material handling and surface treatment in high-volume production.

Key features

  • 1. Precision Electroplating Technology

    • With advanced electroplating technology, achieve uniform copper plating on PCBs and panels for enhanced conductivity and durability. The rack plating design ensures consistent coating thickness, reducing defects compared to manual processes*.

  • 2. Automated Multi-Tasking Capabilities

    • With programmable presets for voltage (380V) and plating parameters, streamline workflows for diverse PCB projects. The automated arm and sensor-equipped components enable seamless transitions between tasks, saving ~30% in setup time versus traditional machines*.

  • 3. High-Volume Industrial Performance

    • With a robust industrial-grade build, handle continuous commercial-scale plating operations without downtime. Designed for heavy-duty use, it outperforms entry-level models in throughput and reliability under prolonged operation*.

  • 4. Safety-Compliant Design

    • With reinforced safety features, including enclosed components and voltage regulation, minimize risks in industrial settings. The ergonomic structure aligns with OSHA standards for operator safety, ensuring compliance in regulated environments.

  • 5. Versatile Rack Plating Adaptability

    • With modular rack plating compatibility, process PCBs of varying sizes and thicknesses in a single setup. This flexibility reduces production costs compared to dedicated single-use equipment*.

Product details

PCB Copper Plating / Panel Plating Machine

The PCB Copper Plating/Panel Plating Machine is a precision-engineered solution for industrial electroplating applications. Designed for copper plating via rack plating, it operates at 380V and comes with a 1-year warranty. Its robust construction and automated features ensure consistent coating quality for printed circuit boards (PCBs) and large panels in electronics manufacturing.

Technical specifications

FeatureSpecificationApplication Scenario
Voltage380VEnsures stable power for industrial use
Coating MethodElectroplatingAchieves uniform copper plating on PCBs
Plating StyleRack PlatingBatch processing of large PCB panels
Material HandlingUp to 500kg/batchHigh-volume production lines
Warranty1 YearCovers initial maintenance and repairs

Scenario Solution Paragraph:
The machine’s rack plating style and high material capacity make it ideal for mass-producing PCB panels in electronics assembly lines. Its 380V power ensures reliable operation in industrial settings, while precision sensors (visible in the machine’s design) enable consistent coating thickness for quality assurance.

Customization guide

Adjustable parameters include:

  • Arm Length: Extendable up to 3 meters to accommodate varying panel sizes.
  • Sensor Spacing: Customizable for precise material positioning during plating.
  • Material Compatibility: Configurable to handle different substrate types (e.g., FR4, aluminum).

Get inspired

Optimize your production workflow with this industrial-grade plating machine. Its precision sensors and automated arm ensure repeatable results, while the robust design withstands heavy-duty use. Whether you’re manufacturing small PCB batches or large panels, this machine adapts to your needs.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Plating Speed10 units/hour+15% (11.5/hour)+30% (13/hour)
Precision±0.1mm±0.05mm±0.02mm
Material Capacity500kg/batch750kg/batch1000kg/batch
Energy EfficiencyStandard10% Improved20% Improved*

Supplier's note

  1. Technical Breakthroughs:

    • Precision Sensors: Achieve micron-level accuracy, reducing defects in high-precision electronics.
    • Energy Efficiency: The Pro model’s 20% improvement cuts operational costs compared to industry benchmarks.
    • Customizable Arm: Adapts to diverse panel sizes, eliminating the need for multiple machines.

  2. Version Selection Guide:

    • Base Model: Ideal for small-to-medium workshops requiring basic plating needs.
    • Advanced Model: Suitable for mid-volume production lines needing faster throughput and tighter tolerances.
    • Pro Model: Best for large-scale manufacturers requiring ultra-precision (e.g., aerospace components) and high-capacity processing.

*Pro Model’s energy efficiency exceeds industry standards by 20%, reducing carbon footprint.

Frequently asked questions

  • Which PCB copper plating machine model is best for small electronics workshops?

  • How do I clean the electroplating chamber to maintain efficiency?

  • Copper vs. Nickel plating: Which is better for PCB corrosion resistance?

  • Can the panel plating machine be customized for specific PCB dimensions?

  • Is the machine’s electroplating process RoHS compliant?

  • Does the 380V voltage affect plating quality in industrial settings?

  • Why choose rack plating over barrel plating for PCBs?

  • What safety features does the machine have for industrial use?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Plating MethodSurface finishing for PCBsElectroplating (ASTM B487 compliant) ▲ Advanced: Real-time thickness control (ISO 3057)Uniform coating, high adhesion ▲ Advanced: Precision adjustments during runtimeRequires conductive substrates; advanced model needs skilled operators
Voltage CompatibilityGlobal manufacturing facilities380V (standard industrial voltage) ▲ Advanced: Auto-adjust 220–415V (IEC 60038)Direct compatibility with European/Asian grids ▲ Advanced: Universal voltage useBase model limited to 380V regions; advanced model may cost more
Plating ThicknessPrecision PCB manufacturing1–50 µm (ASTM B487) ▲ Advanced: 1–100 µm (PLC customizable)Meets most PCB specs ▲ Advanced: Handles ultra-thick coatings for heavy-duty useThicker plating increases processing time; advanced model needs PLC programming
Plating StyleBatch processing of large panelsRack plating (ISO 14560) ▲ Advanced: Hybrid rack-tank system (ASTM B557)Minimizes part damage ▲ Advanced: Combines efficiency of tank with rack controlLower throughput than barrel plating; advanced setup requires space
Warranty PeriodLong-term production facilities1 year warranty ▲ Advanced: 2 yearsStandard coverage for critical operations ▲ Advanced: Extended protectionBase model may incur repair costs faster; advanced model has higher upfront cost
Safety FeaturesHigh-risk manufacturing environmentsEmergency stop (IEC 60204) ▲ Advanced: Leak detection + auto-shutdown (ISO 13849)Meets basic safety norms ▲ Advanced: Proactive hazard preventionAdvanced features add complexity; base model lacks real-time monitoring
