PCB Pulse Transformer 230v 10v Power Transformer 220v to 12v Pq2620 Pq3230 High Frequency Transformer

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Frequency Voltage Transformation: Enables efficient conversion of input voltages (110V, 220V, 230V) to output voltages (5V, 12V, 24V, 48V, etc.) using a ferrite core and toroidal coil structure, ideal for PCB-based power supplies and pulse applications.
  • Flyback Topology Design: Supports high-frequency switching in electronic systems, making it suitable for applications requiring rapid voltage regulation and isolation, such as instrumentation and industrial control devices.

Key features

  • 1. Advanced Material Technology for High Efficiency

    • With a ferrite core and copper windings, achieve up to 20% lower energy loss compared to traditional iron-core transformers*. The ferrite core ensures minimal magnetic resistance at high frequencies, while copper windings reduce electrical resistance for optimal power transfer.

  • 2. Compact Toroidal Design for Space-Saving Solutions

    • The toroidal coil structure and vertical bobbin shape save 30% more space than conventional E-I laminated designs*, making it ideal for PCB-integrated systems where footprint is critical.

  • 3. Versatile Performance for Diverse Applications

    • Support input voltages from 110V to 230V and outputs up to 48V, compatible with power, instrument, and pulse applications. The flyback topology enables fast, stable voltage conversion in high-frequency circuits, outperforming standard transformers in dynamic environments*.

  • 4. Reliable for High-Performance Scenarios

    • Designed for continuous operation in commercial electronics and instrumentation, this transformer handles high-frequency demands (up to its rated capacity) with minimal heat generation, ensuring reliability under heavy loads.

  • 5. Comprehensive Global Compliance & Safety

    • Certified to CUL, UL, RoHS, and REACH standards, it meets strict safety and environmental regulations worldwide. This ensures compliance for industrial, commercial, and consumer-grade applications compared to uncertified alternatives*.

Product details

PCB Pulse Transformer 230v 10v Power Transformer 220v to 12v Pq2620 Pq3230 High Frequency Transformer

The PCB Pulse Transformer PQ2620/PQ3230 is a high-frequency, compact power transformer designed for versatile applications in electronics, instrumentation, and power systems. Built with a ferrite core and copper windings, it ensures high efficiency and low power loss. Certified to global standards (CUL, VDE, UL, etc.), it offers reliable performance in demanding environments.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialFerrite core, copper windings, plastic housing (yellow/black)High-temperature environments, PCB integration
Coil StructureToroidal, autotransformer configurationHigh-frequency power conversion (e.g., 220V→12V)
Frequency RangeOptimized for high-frequency applications (up to 1 MHz)Switch-mode power supplies, pulse circuits
Voltage RatingsInput: 110V/220V/230V; Output: 5V/12V/24V/48V/110V/220VCustomizable voltage transformation needs
CertificationsCUL, VDE, UL, RoHS, REACH, and regional EPR complianceGlobal industrial and consumer electronics

Customization guide

Adjustable parameters include input/output voltage ratios, frequency tolerance, and core material (e.g., ferrite vs. powdered iron) to meet specific requirements. For example:

  • Voltage customization: Tailor output voltages (e.g., 24V for industrial sensors or 12V for LED lighting).
  • Frequency optimization: Modify winding configurations for applications beyond 1 MHz.

Get inspired

These transformers are essential for powering electronic devices, stabilizing voltage in instrumentation, and enabling efficient energy conversion in high-frequency circuits. Their compact rectangle design and flyback topology make them ideal for space-constrained PCB layouts.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Input Voltage Range110V/220V+15% (up to 240V)+30% (up to 264V)*
Efficiency85%90%95%
Frequency Handling500 kHz800 kHz1 MHz
Core MaterialStandard ferriteHigh-permeability ferriteNanocrystalline ferrite

Supplier's note

  1. Key Technical Breakthroughs:

    • Ferrite Core Efficiency: Achieves 95% efficiency in the Pro model, reducing energy waste in power supplies.
    • Toroidal Design: Minimizes magnetic leakage, enabling stable operation in high-density PCB layouts.
    • Global Compliance: Triple-certification (UL, CQC, REACH) ensures seamless deployment across regions.

  2. Version Selection Guidance:

    • Base Model: Ideal for standard applications (e.g., home appliances) requiring 110V/220V input.
    • Advanced Model: Suitable for industrial systems needing broader voltage ranges (e.g., 240V solar inverters).
    • Pro Model: Best for high-frequency, high-power scenarios (e.g., medical equipment or server power supplies). With its 1 MHz frequency handling, it enables faster response times than traditional models.

The Pro Model’s expanded voltage range (+30% vs. base) supports emerging applications like EV charging systems. Pair this with its nanocrystalline core for superior thermal stability in harsh environments.

Frequently asked questions

  • Which PCB pulse transformer model suits 220V to 12V applications?

  • How do I maintain a PCB pulse transformer for longevity?

  • What’s the advantage of ferrite core vs. iron core in pulse transformers?

  • Can I customize voltage ratings for the PQ3230 transformer?

  • Is the PQ2620 transformer RoHS and UL certified?

  • What applications are best for toroidal coil transformers?

  • How does the vertical bobbin shape benefit PCB installation?

  • Are these transformers suitable for high-temperature environments?

Related searches
