PCB Resin Lamp Exposure Curing Screen Printing Plate Making LED Ultraviolet Vacuum Suction Plate Machine

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • UV Curing System: Equipped with high-intensity LED ultraviolet lamps for rapid curing of UV-curable resins, inks, and coatings on PCBs, screen printing plates, and other substrates.
  • Vacuum Suction Technology: Ensures uniform adhesion and precision during curing by stabilizing materials (e.g., plastics, metals, glass) via a built-in vacuum system.

Key features

  • 1. Advanced UV LED Technology (Material Technology)

    • With high-intensity LED ultraviolet lamps, achieve rapid curing of UV-curable inks and resins for precise screen printing plate making. The energy-efficient design reduces operational costs while maintaining consistent performance.

  • 2. Intuitive Control Panel (Interactive Design)

    • With a digital display and programmable presets, customize curing parameters (e.g., time, intensity) for different materials like PCB resin or metal substrates. Simplify workflows with automated operation for consistent results.

  • 3. High-Speed Production (Performance Parameters)

    • With a vacuum suction system and optimized UV exposure, cure plates ~30% faster than conventional models*. Achieve uniform curing on large or irregular substrates for commercial-scale production.

  • 4. Versatile Industrial Applications (Scenario Solutions)

    • Designed for pre-press workflows, this machine adapts to PCB resin processing, screen printing plate making, and industrial coating tasks. The robust metal frame ensures durability in high-volume manufacturing environments.

  • 5. Safety-Compliant Design (Certification Standards)

    • Engineered with safety interlocks and emergency stop features, meeting industrial safety standards (certifications subject to manufacturer confirmation). Prioritizes operator safety while maintaining precision.

  • Notes:

    • The product’s vacuum system and LED UV tech emphasize efficiency and scalability.

Product details

PCB Resin Lamp Exposure Curing Screen Printing Plate Making LED Ultraviolet Vacuum Suction Plate Machine

The PCB Resin Lamp Exposure Curing Screen Printing Plate Making LED Ultraviolet Vacuum Suction Plate Machine is a high-precision pre-press solution designed for rapid, automated production of screen printing plates. With UV LED technology and vacuum-assisted curing, it ensures uniform resin curing and precise plate adhesion, ideal for PCB manufacturing, signage, and industrial printing applications.

Technical specifications

FeatureSpecificationBenefit
UV LED Lamps365-405nm wavelength, 1200W powerEnergy-efficient curing with minimal heat output
Automatic GradeFully automatic operationReduces manual intervention and errors
Vacuum Suction SystemAdjustable pressure (0.5-0.8MPa)Ensures even resin distribution on plates
Material CompatibilitySupports resin-coated polyester platesVersatile for PCB, ceramic, and metal substrates
Safety FeaturesEmergency stop, interlock guardsISO 13849-1 compliant safety protocols

Customization guide

Adjustable parameters include exposure time (5-60 seconds) and vacuum pressure to accommodate plate thickness variations (0.1-5mm) or specialized resin formulations. Custom wavelength settings (±5nm) allow optimization for different UV-curable resins.

Get inspired

Achieve flawless screen printing plates for high-density PCBs or durable outdoor signage. With precise temperature control and vacuum suction, this machine ensures consistent results even on complex designs.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Curing Speed12 plates/hour+20% (14.4 plates/hour)+35% (16.2 plates/hour)*
UV Intensity800mW/cm²1000mW/cm²1200mW/cm²
Automation LevelSemi-automaticFully automaticFully automatic + IoT
Max Plate Thickness3mm4mm5mm

Supplier's note

  1. Technical Breakthroughs:

    • Adjustable UV Wavelength: Optimizes curing for diverse resins (e.g., epoxy vs. acrylic).
    • Dual-Zone Temperature Control: Reduces warping in thick plates by ±2°C precision.
    • IoT Integration (Pro Model): Remote monitoring for real-time process adjustments.

  2. Model Selection Guide:

    • Base Model: Ideal for small workshops needing cost-effective semi-automation.
    • Advanced Model: Suitable for medium-scale PCB manufacturers requiring faster throughput and full automation.
    • Pro Model: Best for high-volume production lines (e.g., automotive electronics) needing IoT connectivity and 5mm plate capacity. With its 1200mW/cm² intensity, it ensures durable adhesion on metal substrates, reducing rework by 40%.

*Comparative benchmarks: 20% faster than traditional mercury-vapor UV systems.

Frequently asked questions

  • Which UV curing machine model is best for PCB resin lamp exposure and screen printing plate making?

  • How do I maintain the UV lamps in a LED ultraviolet vacuum suction plate machine?

  • What materials can the UV vacuum suction plate machine handle for screen printing?

  • Can this UV curing machine be customized for specific PCB or plate-making needs?

  • Is the LED UV technology in this machine FDA-approved for industrial use?

  • Why is a vacuum suction system important for UV curing in plate making?

  • How does this machine compare to traditional UV curing methods for plate making?

  • What automation features does the conventional plate processor include?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Curing SpeedHigh-volume PCB manufacturingIndustry Standard: 10–15 sec (ISO 2812)
Our Base: 5 sec (IEC 61131)▲
Our Advanced: 3 sec (ASTM D3359)▲▲		▲▲ 3x faster than Industry Standard; reduces production bottlenecksAdvanced model requires higher energy input (+20%)
Material CompatibilityDiverse substrates (plastic, metal, glass)Industry Standard: 5 materials (ASTM D543)
Our Base: 10 materials▲
Our Advanced: 15 materials▲▲		▲▲ Supports exotic materials like carbon fiber; minimizes reworkAdvanced may need costly substrate pre-treatment
Automation LevelMass production linesIndustry Standard: Semi-automatic
Our Base: Fully automated (ISO 9283)▲
Our Advanced: AI-adjusted curing▲▲		▲▲ Reduces labor costs by 40%; integrates with Industry 4.0 systemsAdvanced requires specialized operator training
Energy EfficiencyEco-conscious facilitiesIndustry Standard: 500 W/m²
Our Base: 350 W/m² (IEC 60068)▲
Our Advanced: 280 W/m²▲▲		▲▲ 44% energy savings; lowers operational costsAdvanced has complex cooling systems (higher upfront cost)
Safety FeaturesIndustrial workshops with safety mandatesIndustry Standard: Basic emergency stop
Our Base: UV-shield + interlocks▲
Our Advanced: Auto-shutoff + fume extraction▲▲		▲▲ Meets OSHA/ISO 13849 safety standards; prevents operator exposureAdvanced adds maintenance complexity
Maintenance EaseSmall-scale workshopsIndustry Standard: 8hr lamp replacement
Our Base: 2hr modular design▲
Our Advanced: Self-diagnostic sensors▲▲		▲▲ Reduces downtime by 75%; predictive maintenance alertsAdvanced sensors require calibration every 6 months
