PCBA Electronic Engineering Service PCB Design GERBER Software for Development Metal Detector Module

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • PCB Design & Manufacturing: Provides professional PCBA services for developing metal detector modules using GERBER software, integrating components like resistors, capacitors, ICs, and relays for precise signal processing and power management.
  • Custom Component Integration: Supports the assembly of SMDs, through-hole components, and specialized parts (e.g., relays, transistors) to meet specific functional requirements.

Key features

  • 1. Material Technology

    • With a FR-4 epoxy substrate, ensure superior thermal and electrical stability compared to standard PCB materials. This corrosion-resistant material withstands harsh industrial environments, offering up to 20% better durability* [*Disclaimer: Based on internal testing; actual results may vary].

  • 2. Interactive Design

    • Powered by GERBER software integration, streamline PCB design with multi-program presets for rapid prototyping of metal detectors or home appliances. Customize layouts effortlessly using modular templates, reducing development time by 30%* [*Disclaimer: Results depend on project complexity].

  • 3. Performance Parameters

    • Equipped with high-current relays and robust power management ICs, handle demanding applications like automotive systems or industrial controls. Achieve seamless operation at voltages up to 24V, outperforming generic PCB solutions in power efficiency* [*Disclaimer: Performance varies by component configuration].

  • 4. Scenario Solutions

    • Adapt to diverse environments with a modular design. Whether for home electronics or commercial systems, the PCB’s grid-like component arrangement ensures reliability in both low-volume prototyping and high-throughput industrial use cases.

  • 5. Certification Standards

    • Comply with safety and quality standards through grounded connectors and thermal-resistant materials. Meets safety requirements for consumer electronics (e.g., UL certification-ready), ensuring safe deployment across applications* [*Disclaimer: Certification status subject to manufacturer’s specifications].

Product details

PCBA Electronic Engineering Service PCB Design GERBER Software for Development Metal Detector Module

Our PCBA Electronic Engineering Service offers a customizable PCB design solution for metal detector modules, engineered for reliability in electronic devices, home appliances, and consumer electronics. Built with FR-4 material and a modular layout, this PCB supports high-performance components like ICs, relays, and power management systems, ensuring robust functionality across industrial, automotive, and consumer applications.

Technical specifications

FeatureSpecificationBenefit
MaterialFR-4 epoxy laminateHigh thermal stability and flame resistance
Component Density500+ SMD/through-hole componentsScalable for complex circuit designs
Design FlexibilityGrid-based layout with 0.5mm trace widthPrecision for miniaturized electronics
Safety FeaturesIntegrated grounding and overcurrent protectionReduces fault risks in power-sensitive systems
CertificationsRoHS, UL RecognizedCompliance for global consumer markets

Customization guide

Adjust component types (e.g., resistor values, capacitor ratings) or layout density to meet specific power requirements or space constraints. For high-voltage applications, upgrade to reinforced FR-4 or add thermal vias for enhanced cooling.

Get inspired

From industrial sensors to smart home devices, this PCB’s modular design adapts to diverse needs. Its relay integration enables control of high-current systems, while its compact form factor suits wearable electronics.
