Pcbasic Custom Oem Motherboard 12V Dc Frequency Converter Ceiling Fan Controller Pcb

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • 12V DC Frequency Conversion: Converts input voltage to regulate power for ceiling fan operations, enabling precise speed control and energy efficiency.
  • Customized PCB Design: Features gold-plated solder pads and an FR-4 material base for enhanced conductivity, durability, and thermal stability, ensuring reliable performance in diverse environments.

Key features

  • 1. Material Technology

    • With FR-4 composite material and gold-plated solder pads, ensure long-term durability and reliable electrical conductivity in demanding environments. ~30% more corrosion-resistant than standard PCBs*

  • 2. Interactive Design

    • With a modular layout design, customize control parameters to suit specific ceiling fan models and operational needs. Compatible with both OEM assembly and retrofit installations, offering flexibility for diverse applications.

  • 3. Performance Parameters

    • With a 12V DC frequency conversion capability, achieve precise speed control and energy efficiency, reducing power consumption by up to 25% compared to traditional AC controllers*

  • 4. Scenario Solutions

    • Designed for continuous operation in commercial settings (e.g., offices, hotels), while also enabling quick, hassle-free installation in home environments. The compact cut-out design integrates seamlessly into tight spaces like ceiling fan enclosures.

  • 5. Certification Standards

    • With CE certification, meet EU safety and performance standards, ensuring compliance for European markets and global regulatory requirements.

Product details

Pcbasic Custom Oem Motherboard 12V Dc Frequency Converter Ceiling Fan Controller Pcb

The Pcbasic Custom OEM Motherboard is a 12V DC frequency converter designed for ceiling fan control systems. Crafted from FR-4 material with gold-plated solder pads and a unique cut-out design, this PCB ensures reliable performance in demanding environments. CE-certified for safety and compliance, it combines precision engineering with customizable features to meet diverse application needs.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialFR-4 glass epoxyThermal stability in industrial settings
CertificationCE-compliantEU market-ready electronics
Solder PadsGold-platedHigh-reliability connections in humid environments
DesignCut-out sectionSpace-saving integration in compact devices
Voltage Compatibility12V DC input/outputFan speed control systems

Customization guide

Adjustable parameters include:

  • Pad Layout: Modify solder pad positions to accommodate different component placements.
  • Trace Routing: Optimize electrical paths for higher current loads.
  • Dimensions: Resize the board to fit specific enclosures or mounting constraints.

Get inspired

With its modular design and CE certification, this PCB is ideal for smart home automation, industrial fan systems, or retrofitting legacy equipment. The gold-plated pads ensure long-term durability, while the FR-4 base withstands thermal fluctuations in harsh environments.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Operating Temperature0°C to 70°C0°C to 85°C-20°C to 105°C*
Max Current Capacity5A8A12A
Customization OptionsLimitedModerateFull (layout/size)

Supplier's note

  1. Technical Breakthroughs:

    • FR-4 Material: Triple-layered thermal stability ensures operation in extreme environments.
    • Gold-Plated Pads: Reduces corrosion risk by 40% compared to standard tin finishes.
    • CE Certification: Streamlines compliance for EU and global markets.

  2. Version Selection Guidance:

    • Base Model: Ideal for residential ceiling fans requiring basic 12V DC control.
    • Advanced Model: Suitable for commercial HVAC systems needing higher current handling (e.g., industrial fans).
    • Pro Model: Designed for extreme environments (e.g., mining or outdoor equipment) with full customization for specialized enclosures.

With the Pro version’s expanded temperature range, users can deploy controllers in Arctic or tropical climates without performance loss. Pair its 12A capacity with heavy-duty motors to ensure uninterrupted operation.

Frequently asked questions

  • Which PCB model suits ceiling fan controllers in commercial spaces?

  • How does the gold-plated solder pad design enhance durability?

  • FR-4 vs. other materials: Why is FR-4 preferred for PCBs?

  • Can this PCB be customized for specific voltage requirements?

  • Is the PCB’s CE certification applicable for EU markets?

  • What applications are suitable for this 12V DC frequency converter PCB?

  • Does the PCB require specialized assembly tools?

  • How does the cut-out design benefit the PCB’s functionality?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Material CompositionIndustrial equipment, medical devicesFR-4 Epoxy (ISO 178 flexural strength: 240 MPa) vs Advanced FR-4 (320 MPa▲)Enhanced durability for heavy-duty applications▲
Certified thermal stability (-55°C to 140°C)		Higher cost for advanced material▲
Heavier weight compared to alternatives
Electrical PerformanceHigh-voltage systems, IoT devicesGold-Plated Pads (3μm thickness, IEC 61245) vs Advanced 5μm▲Reduced oxidation risk▲
Low contact resistance (≤10 mΩ)		Base version may require frequent cleaning in harsh environments▲
Safety CertificationResidential appliances (e.g., ceiling fans)CE Certified (EN 55032 EMC compliance) vs RoHS + REACH▲Compliance with EU safety standards▲
Reduced electromagnetic interference		Advanced certification adds cost and delays for small-scale projects▲
Thermal StabilityHigh-temperature environmentsTg 130°C (ASTM D696) vs Advanced Tg 170°C▲Withstands industrial oven applications▲
Prevents delamination under load▲		Limited flexibility for low-temperature use cases▲
Durability/LongevityMarine or chemical plantsCorrosion Resistance (1000+ salt-spray hours, ASTM B117) vs 2000+▲Extended lifespan in corrosive environments▲
Passivated surface for longevity		Base version may degrade in extreme pH conditions▲
Customization OptionsCustom electronics, prototypingStandard Layout (2-layer PCB) vs 4-layer Advanced▲Supports complex circuit designs▲
Flexible trace routing for miniaturization		Higher complexity increases manufacturing time and cost▲
