Prefabricated Railway Station Galvanized Steel Structures Curved Roof Design Structural Steel Pipe Truss Shed for Sale

Prefabricated Railway Station Galvanized Steel Structures Curved Roof Design Structural Steel Pipe Truss Shed for Sale

$30.00-$180.00/ Square Meter|100 Square Meter/Square Meters(Min. Order)

Customization:

Graphic customization（Min.Order: 200 pieces）
View product details

Prefabricated Railway Station Galvanized Steel Structures Curved Roof Design Structural Steel Pipe Truss Shed for Sale

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Structural Support & Weather Resistance: Designed as a prefabricated galvanized steel structure with a curved roof, providing robust load-bearing capacity and weatherproofing for railway stations, warehouses, and industrial spaces.
  • Corrosion Protection: Galvanized steel coating ensures long-term durability against environmental exposure, while Q355-grade steel guarantees high strength and reliability.

Key features

  • 1. Galvanized Steel with Q355 Grade for Enhanced Durability

    • With a galvanized steel body and Q355-grade structural steel, you can ensure long-term corrosion resistance and superior load-bearing capacity compared to standard steel grades*. The dual-layer sandwich panels further provide thermal insulation, optimizing energy efficiency in diverse climates.

  • 2. Pre-Fabricated Modular Design for Rapid Deployment

    • With a pre-fabricated, welded light steel frame and curved roof truss system, you can achieve quick on-site assembly and reduce construction time by up to 30%* compared to traditional builds, ideal for railway stations and commercial projects requiring fast deployment.

  • 3. High-Strength Welded Frames for Heavy-Duty Applications

    • With JIS/DIN-compliant welded joints and Q355 steel pipes, you can support loads exceeding 500 kg/m²*, surpassing industry standards for structural integrity in high-traffic environments like transportation hubs and industrial warehouses.

  • 4. Curved Roof Design for Versatile Scenario Solutions

    • With an aerodynamic curved roof and open-truss structure, you can optimize natural light penetration, enhance drainage efficiency, and accommodate large, uninterrupted spaces—perfect for railway stations, exhibition halls, or storage facilities.

  • 5. Multi-Standard Compliance for Global Reliability

    • With certification to JIS, DIN, ASTM, and other international standards, you can ensure safety, adaptability, and compliance across global projects, backed by rigorous quality control during decoiling, welding, and bending processes.

Product details

Prefabricated Railway Station Galvanized Steel Structures Curved Roof Design Structural Steel Pipe Truss Shed for Sale

The Prefabricated Railway Station Galvanized Steel Structures offer a modern, industrial design with curved roof trusses engineered for durability and adaptability. Constructed from Q355 and light steel, these structures meet global standards (JIS/DIN/GB/BS/AISI/ASTM) and feature galvanized coatings for corrosion resistance. Ideal for railway stations, warehouses, and exhibition halls, they combine strength with sleek aesthetics, optimized for heavy loads and harsh environments.

Technical specifications

FeatureSpecificationBenefit
Material CompositionQ355 steel + light steel20% stronger than Q235, lightweight
Galvanization CoatingHot-dip galvanized (85-100μm)50+ years corrosion resistance
Curved Roof DesignPre-engineered steel truss systemOptimal rainwater drainage, modern style
Sandwich Panel Cladding50-150mm polyurethane core (R-5 to R-10)40% better thermal insulation vs. single-layer steel
Certification StandardsJIS/DIN/GB/BS/AISI/ASTM compliantGlobal project compatibility

Customization guide

Adjustable Parameters:

  • Roof Span: 20m–50m (customizable for specific site requirements).
  • Material Thickness: Steel sheets from 2mm to 6mm (optimized for load needs).
  • Insulation Thickness: 50mm–150mm sandwich panels (tailored to climate zones).
  • Processing Services: Supports decoiling, punching, welding, and bending for bespoke designs.

Get inspired

Elevate your infrastructure projects with our Prefabricated Railway Station Steel Structures. Designed for durability and efficiency, these structures combine modern aesthetics with robust engineering. Whether for high-traffic railway stations or industrial warehouses, our curved roof designs and galvanized steel ensure longevity in demanding environments.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Load Capacity (kN/m²)0.5+15% (0.58)+30% (0.65)*
Corrosion Resistance20 years+25% (25 years)+50% (30 years)*
Insulation R-ValueR-5R-7R-10
Customization OptionsStandard sizesAdjustable spanFull customization

Supplier's note

  1. Technical Breakthroughs:

    • Q355 Steel Grade: 20% higher tensile strength than Q235, enabling lighter yet stronger structures.
    • Hot-Dip Galvanization: Extends lifespan by 30% in coastal environments vs. painted steel.
    • Sandwich Panels: 40% better thermal insulation than single-layer steel, reducing energy costs.

  2. Version Selection Guidance:

    • Pro Model: Ideal for railway stations in heavy snowfall regions. Its R-10 insulation and 0.65kN/m² load capacity ensure structural integrity and energy efficiency.
    • Advanced Model: Suitable for moderate climates with balanced performance and cost-effectiveness.
    • Base Model: Best for low-load applications like temporary shelters or indoor warehouses.

Comparative Advantage: The Pro Model’s load capacity exceeds industry benchmarks by 30%, enabling safe handling of extreme weather loads when paired with its corrosion-resistant coating. This combination creates a 50-year lifecycle solution for critical infrastructure.

Frequently asked questions

  • Which prefabricated steel structure model is best suited for railway station roofing applications?

  • How do I maintain the galvanized steel frames of a prefabricated shed?

  • What are the advantages of Q355 steel over other grades for structural roofing?

  • Can the steel sheet truss shed be customized for specific load requirements?

  • Are the curved roof steel structures compliant with international safety standards?

  • What makes the sandwich panel material optimal for railway station roofing?

  • How does the curved roof design enhance structural performance?

  • Is the steel structure eco-friendly and recyclable?
