Programmable Transformer Making Equipment Foil Winder Cast Resin Transformer Foil Winding Machine

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Precision Foil Winding: Designed to automate the winding of foil for cast resin transformers, supporting oil tank configurations in round, rectangular, and oval shapes.
  • Programmable CNC Control: Equipped with a PLC-based system for customizable winding parameters, ensuring consistent output and adaptability to diverse transformer designs.
  • TIG Welding Integration: Utilizes TIG welding technology for seamless, high-quality joints in transformer core fabrication, enhancing durability and electrical performance.

Key features

  • 1. Material Technology

    • With a CNC-machined corrosion-resistant metal body and TIG welding technology, you can achieve durable, precision-engineered components ideal for industrial use. ~30% stronger joints than spot-welded models*

  • 2. Interactive Design

    • With a PLC-driven touchscreen interface, you can program multiple winding patterns and automate processes effortlessly. Supports 50+ presets for quick setup*

  • 3. Performance Parameters

    • With support for round, rectangle, and oval oil tank shapes, you can adapt to diverse production requirements. Processes materials 20% faster than non-CNC models*

  • 4. Scenario Solutions

    • With a modular design and continuous operation capability, you can seamlessly integrate into high-volume commercial production environments. Reduces downtime by 40% compared to semi-automated systems*

  • 5. Certification Standards

    • Complies with ISO 9001 quality management standards, ensuring reliable performance. Certifications may vary by model; confirm with manufacturer*

Product details

Programmable Transformer Making Equipment Foil Winder Cast Resin Transformer Foil Winding Machine

The Programmable Transformer Making Equipment Foil Winder is a high-precision industrial machine designed for automated foil winding in cast resin transformer manufacturing. Equipped with CNC technology and PLC-based controls, it ensures accuracy and efficiency in processing materials like metal foils for power distribution systems, electronics, and industrial machinery.

Technical specifications

FeatureSpecificationBenefit
CNC Control SystemPLC-based with digital interfaceEnables precise material handling and repeatability
Welding MethodHigh-precision TIG weldingEnsures durable, consistent joints in transformer cores
Material HandlingMulti-roller conveyor systemSupports continuous, high-volume production of coils
Oil Coil ShapesRound, Rectangle, OvalCustomizable to meet diverse transformer design requirements
Safety FeaturesOrange-accented structural componentsEnhances visibility and operator safety during operation

Customization guide

Adjustable parameters include coil shape selection (round/rectangle/oval) and modular design configurations, allowing customization to meet specific production scales and material requirements.

Get inspired

With its PLC-driven automation and TIG welding precision, this machine is ideal for manufacturers seeking to streamline transformer production. Whether you need compact coils for electronics or robust cores for power systems, this equipment delivers unmatched reliability.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Processing Speed50 units/hr+15% (58 units/hr)+30% (65 units/hr)*
Accuracy±0.5mm±0.3mm±0.1mm
Automation LevelSemi-AutomaticAutomated with monitoringFully automated with AI integration
Welding Speed12m/min14m/min18m/min (+50% faster)

Supplier's note

  1. Technical Breakthroughs:

    • PLC-based CNC Control: Achieves ±0.1mm accuracy in the Pro model, surpassing industry standards by 50%.
    • TIG Welding Integration: Ensures corrosion-resistant joints, critical for harsh industrial environments.
    • Modular Design: Enables quick reconfiguration for round/rectangle/oval coils, reducing downtime by 20%.

  2. Version Selection Guide:

    • Base Model: Ideal for small-to-medium workshops requiring basic automation and cost-effective production (e.g., low-volume transformer cores).
    • Advanced Model: Suitable for mid-scale manufacturers needing enhanced precision and real-time monitoring (e.g., electronics components).
    • Pro Model: Best for high-volume industrial applications requiring 65 units/hr output and AI-driven optimization (e.g., power grid infrastructure).

*Pro Model’s speed exceeds industry benchmarks by 30%, reducing cycle times for large-scale production.

Frequently asked questions

  • Which programmable foil winding machine suits high-volume transformer production?

  • How do I maintain the conveyor belts and rollers on the cast resin transformer winder?

  • Can the foil winder handle both metal and plastic materials for transformer cores?

  • Does the CNC foil winding machine support custom transformer dimensions?

  • Is the machine’s TIG welding process ISO-certified for transformer safety standards?

  • What automation features improve efficiency in the foil winding process?

  • Are safety features integrated into the transformer foil winder’s design?

  • How does the CNC system enhance precision in cast resin transformer winding?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Winding PrecisionHigh-volume transformer production- Industry Standard: Manual winding (±0.5mm tolerance)
- Our Base: CNC (±0.2mm) ▲▲
- Our Advanced: PLC-based CNC (±0.1mm) ▲▲▲
(ISO 9001 certified)		▲▲▲ Precision: Advanced CNC reduces errors by 80% vs manual systemsHigher cost for advanced systems; requires skilled operators for PLC programming
Welding MethodCore assembly in transformers- Industry Standard: MIG welding (ASTM A312)
- Our Base: TIG welding (ASTM A312) ▲
- Our Advanced: TIG + automation ▲▲▲		▲▲▲ Strength: TIG welds 30% stronger than MIG for thin metal jointsSlower cycle time; advanced systems need calibration for precision
Oil Tank ConfigurationCustom transformer design flexibility- Industry Standard: Round tanks only
- Our Base: Round + Rectangle ▲
- Our Advanced: Round, Rectangle, Oval ▲▲▲
(ASTM A53 compliance)		▲▲▲ Versatility: Supports oval tanks for compact installationsComplex setups for non-standard shapes; requires design adjustments
Control SystemAutomated production lines- Industry Standard: Manual controls
- Our Base: Basic PLC ▲
- Our Advanced: Touchscreen PLC ▲▲▲
(ISO 13849 safety-rated)		▲▲▲ Programmability: Advanced PLC stores 50+ presets for repeat jobsHigher maintenance costs; requires training for touchscreen features
Material HandlingHigh-speed foil winding- Industry Standard: Manual loading
- Our Base: Semi-automated conveyors ▲
- Our Advanced: Fully automated conveyors ▲▲▲
(ISO 5211 standard)		▲▲▲ Efficiency: Reduces labor by 60% in foil feeding processesRequires larger floor space; conveyors need frequent alignment checks
Safety FeaturesIndustrial manufacturing environments- Industry Standard: Basic guards
- Our Base: Color-coded safety zones (orange accents) ▲
- Our Advanced: Safety sensors + color coding ▲▲▲		▲▲▲ Safety: Sensors reduce accident risk by 40% during operationHigher upfront cost; sensors require regular calibration
