Reducer Spiral Bevel Helical Speed Reduction Variator Cycloidal Servo High Precision Planetary Winch Drive Nmrv Worm Gearbox

Reducer Spiral Bevel Helical Speed Reduction Variator Cycloidal Servo High Precision Planetary Winch Drive Nmrv Worm Gearbox

$20.00-$86.00/ Piece|1 Piece/Pieces(Min. Order)

Customization:

Customized logo（Min.Order: 100 pieces）
Customized packaging（Min.Order: 100 pieces）
View product details

Reducer Spiral Bevel Helical Speed Reduction Variator Cycloidal Servo High Precision Planetary Winch Drive Nmrv Worm Gearbox

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Precision Speed Reduction & Torque Enhancement: Combines worm, helical, planetary, and cycloidal gearing arrangements to deliver precise speed reduction (up to 1500 RPM input) and torque amplification, ideal for applications requiring controlled mechanical output.
  • Versatile Gearing Configurations: Supports bevel, miter, worm, cycloidal, helical, and planetary designs, enabling adaptation to diverse operational demands such as industrial machinery, robotics, and servo-driven systems.

Key features

  • 1. Corrosion-Resistant Material Construction

    • With corrosion-resistant steel and cast iron construction, ensure durability in harsh industrial environments. The protective blue coating enhances longevity and visibility, outperforming non-coated alternatives*.

  • 2. Modular Flange Mounting Design

    • With modular flange mounting design, easily integrate into diverse mechanical systems with minimal adjustments compared to fixed mounting solutions*. The dual-flange configuration enables versatile orientation for space-constrained setups.

  • 3. High-Speed Multi-Gearing Performance

    • With 1500rpm input speed and multi-gearing arrangement (bevel, helical, planetary), achieve ~20% faster torque transmission and adaptability to complex motion demands than standard worm-only gearboxes*.

  • 4. Heavy-Duty Industrial Reliability

    • Designed for heavy-duty industrial applications, reliably handle continuous operation in manufacturing and automation systems compared to consumer-grade alternatives*. The robust design supports high-torque scenarios without compromising precision.

  • 5. ISO-Compliant Safety Standards

    • Complies with ISO industrial gear standards, ensuring safety and performance in regulated environments*. This certification guarantees compatibility with global quality and safety requirements.

Product details

Reducer Spiral Bevel Helical Speed Reduction Variator Cycloidal Servo High Precision Planetary Winch Drive Nmrv Worm Gearbox

The Reducer Spiral Bevel Helical Speed Reduction Variator Cycloidal Servo High Precision Planetary Winch Drive Nmrv Worm Gearbox combines robust iron/cast iron construction with advanced gearing arrangements (bevel, miter, worm, cycloidal, helical, planetary) to deliver precise torque control and high durability. With an input speed of 1500rpm, it suits industrial machinery, conveyor systems, and robotics requiring reliable power transmission. Modular flange mounting and customizable gear ratios enable versatile integration into diverse applications.

Technical specifications

FeatureSpecificationApplication Scenario
Gearing ArrangementBevel, Miter, Worm, Cycloidal, Helical, PlanetaryHeavy-duty machinery, precision robotics, winch drives
Input Speed1500rpmHigh-speed motor interfaces (e.g., servo motors)
MaterialIron/Cast IronHarsh environments with high mechanical stress
TypeWorm GearboxApplications requiring compact design and smooth torque delivery

Customization guide

Adjustable gear ratios and flange configurations to meet torque requirements or spatial constraints in specialized machinery.

Get inspired

With its cycloidal design and versatile gearing options, this gearbox optimizes power distribution in automated manufacturing lines. The cast iron casing ensures longevity in corrosive or high-vibration settings, while flange adaptability simplifies installation in tight spaces.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Torque Capacity1000 Nm+15% (1150 Nm)+30% (1300 Nm)*
Efficiency75%85%92%
MTBF (Hours)10,000+20% (12,000)+40% (14,000)

Supplier's note

  1. Technical Breakthroughs:

    • Cycloidal Gearing: Reduces backlash and improves efficiency by 20% compared to traditional worm gears.
    • Cast Iron Construction: Enhances durability in high-impact environments, outperforming aluminum by 30% in load-bearing tests.
    • Modular Flange Design: Enables 45% faster installation in multi-axis robotic systems.

  2. Optimal Version Selection:

    • Base Model: Ideal for standard conveyor systems or light industrial automation (e.g., packaging lines).
    • Advanced Model: Suitable for heavy-duty applications like mining equipment, where +15% torque boosts reliability.
    • Pro Model: Designed for extreme environments (e.g., offshore machinery) with triple the corrosion resistance of industry benchmarks. Its 92% efficiency ensures minimal energy loss in high-speed robotics.

With cast iron construction, you can ensure durability in corrosive environments. The Pro Model’s 1300 Nm torque capacity enables safe handling of heavy payloads in construction equipment. Pair its high efficiency with cycloidal gearing for seamless operation in precision CNC machining systems.

Frequently asked questions

  • Which NMVRV worm gearbox model is best suited for high torque industrial applications?

  • How do I clean and maintain the flange-mounted worm gearboxes to prevent corrosion?

  • Cast iron vs steel: Which material is better for heavy-duty gearboxes in harsh environments?

  • Can these modular gearboxes be customized for specific torque and speed requirements?

  • Are the materials in these gearboxes ISO-certified for industrial machinery use?

  • How does the planetary gear reducer handle high input speeds like 1500rpm?

  • What’s the advantage of the integrated motor design in compact machinery?

  • Which gearbox is best for precision control in winch drive systems?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Worm GearboxLow-speed, high-torque applicationsCast iron (400 MPa ASTM A48), 1500rpm input, worm gear arrangement (ISO 947)▲ Compact design (12% smaller than helical)Lower efficiency (75-85%) ▲ vs cycloidal (tooltip: "Quieter than 43 dBA (refrigerator hum)")
Helical GearboxHigh-speed machinery (pumps, turbines)Helical gears (ISO 6336), 2000rpm input, lubricated bearings▲ 95% efficiency (reduces energy loss by 20%)Requires frequent maintenance due to axial thrust ▲ vs worm (tooltip: "Smooth operation at 2000rpm")
Planetary GearboxRobotics, aerospace (space-constrained)Planetary configuration (ISO 6336), 3000rpm input, aluminum casing▲ 98% efficiency ▲ 3x higher torque density vs helicalComplex design increases cost (tooltip: "Compact enough for drone propulsion")
Cycloidal GearboxHigh-reduction applications (mixers)Cycloidal discs (ISO 1328), 1000:1 reduction ratio, steel housing▲ Single-stage 1000:1 reduction ▲ High durability (tooltip: "Handles 10,000+ cycles per ISO 1328")Max input speed limited to 1200rpm ▲ vs worm (tooltip: "Quieter than 50 dBA")
Bevel/Miter GearboxRight-angle drives (ship steering)Bevel/ miter gears (ISO 947), 90° alignment, heat-treated steel▲ Direct 90° torque transfer ▲ High shock resistance (tooltip: "Withstands 500 Nm impact")Higher wear rate (tooltip: "Lubrication required every 50 hours")
Worm Planetary HybridHeavy machinery (elevators, cranes)Hybrid worm/planetary design (ISO 6336/947), 1800rpm input, dual lubrication▲ Combines worm’s compactness + planetary’s torque ▲ 90% efficiencyComplex assembly increases downtime risk (tooltip: "Handles 10,000 Nm torque")
