  • SCFR-1230 3.7V Micro DC Motor 14785 RPM 0.441 MN.m with Brush Commutation for Electric Toothbrush & Camera
  • SCFR-1230 3.7V Micro DC Motor 14785 RPM 0.441 MN.m with Brush Commutation for Electric Toothbrush & Camera
  • SCFR-1230 3.7V Micro DC Motor 14785 RPM 0.441 MN.m with Brush Commutation for Electric Toothbrush & Camera
  • SCFR-1230 3.7V Micro DC Motor 14785 RPM 0.441 MN.m with Brush Commutation for Electric Toothbrush & Camera
  • SCFR-1230 3.7V Micro DC Motor 14785 RPM 0.441 MN.m with Brush Commutation for Electric Toothbrush & Camera
  • SCFR-1230 3.7V Micro DC Motor 14785 RPM 0.441 MN.m with Brush Commutation for Electric Toothbrush & Camera
SCFR-1230 3.7V Micro DC Motor 14785 RPM 0.441 MN.m with Brush Commutation for Electric Toothbrush & Camera
Ready to Ship
In stock Fast dispatch

SCFR-1230 3.7V Micro DC Motor 14785 RPM 0.441 MN.m with Brush Commutation for Electric Toothbrush & Camera

  • 2 - 99 Pieces
    $1
  • 100 - 4999 Pieces
    $0.95
  • 5000 - 9999 Pieces
    $0.90
  • >= 10000 Pieces
    $0.80

Customization:

Motor Customization（Min.Order: 10 pieces）
Packaging（Min.Order: 10 pieces）
Logo（Min.Order: 10 pieces）
View product details

SCFR-1230 3.7V Micro DC Motor 14785 RPM 0.441 MN.m with Brush Commutation for Electric Toothbrush & Camera

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Performance Operation: The SCFR-1230 3.7V Micro DC Motor delivers 14,785 RPM and 0.441 MN·m torque, optimized for precision-driven applications like electric toothbrushes and camera components.
  • Brush Commutation Reliability: Equipped with brush commutation for consistent performance in compact designs, ensuring smooth operation in space-constrained environments.

Key features

  • 1. Material Technology

    • With a durable metal casing, you can ensure reliable performance in compact applications compared to plastic-bodied motors*.

  • 2. Interactive Design

    • With easy-to-connect terminals and a mounting shaft, you can seamlessly integrate into projects like electric toothbrushes or cameras, simplifying assembly compared to models with complex wiring*.

  • 3. Performance Parameters

    • With 14,785 RPM and 0.441 MN.m torque, you can achieve high-speed performance in compact devices, offering ~20% faster operation than similar-sized brushed motors*.

  • 4. Scenario Solutions

    • Designed for compact applications like electric toothbrushes and cameras, you can ensure reliable operation in space-constrained environments, optimizing space compared to bulkier alternatives*.

  • 5. Certification Standards

    • With IE2 efficiency certification, you can meet energy efficiency standards for consumer electronics, surpassing non-certified models in energy performance*.

Product details

SCFR-1230 3.7V Micro DC Motor 14785 RPM 0.441 MN.m with Brush Commutation for Electric Toothbrush & Camera

The SCFR-1230 3.7V Micro DC Motor combines compact design with robust performance, engineered for precision applications like electric toothbrushes and camera components. With a brushed commutation system and IE2 efficiency, it delivers reliable power in confined spaces while minimizing energy waste.

Technical specifications

FeatureSpecificationApplication Scenario
Voltage3.7V DCLow-voltage portable devices (e.g., handheld tools)
RPM14,785High-speed applications requiring rapid response
Torque0.441 MN·mLight-load tasks with precise control
Commutation TypeBrushedCost-effective solutions needing simplicity
Efficiency ClassIE2Energy-efficient operation in consumer electronics
MaterialAluminum/Steel CasingDurable construction for harsh environments

Customization guide

Adjustable parameters:

  • Material coatings (e.g., anti-corrosion, anti-slip) to meet environmental or aesthetic needs.
  • Shaft length/terminal configuration for tailored mechanical/electrical integration.
  • Voltage tolerance range to adapt to fluctuating power sources.

Get inspired

Compact yet powerful, the SCFR-1230 excels in space-constrained applications. Its high RPM and low torque make it ideal for electric toothbrushes (vibrational cleaning) or camera autofocus systems (rapid positional adjustments). With brushed commutation, it balances affordability and reliability for mass-produced consumer goods.

Choose your model

ParameterBase Model (SCFR-1230)Advanced ModelPro Model
RPM14,785+15% (16,997)+30% (19,221)*
Torque0.441 MN·m+20% (0.529 MN·m)+40% (0.617 MN·m)
Efficiency ClassIE2IE3IE4
CertificationIPX2IPX5IP67**

Supplier's note

  1. Technical Breakthroughs:

    • 14,785 RPM: Enables ultra-fast response in precision devices like autofocus motors.
    • Brushed Commutation Reliability: Ensures consistent performance in compact, cost-sensitive designs.
    • IE2 Efficiency: Meets international energy standards, reducing heat buildup in confined spaces.

  2. Optimal Version Selection:

    • Base Model: Ideal for standard applications (e.g., basic electric toothbrushes) where cost and simplicity are priorities.
    • Advanced Model: Targets mid-tier devices requiring IPX5 water resistance (e.g., outdoor cameras) and 20% higher torque for heavier loads.
    • Pro Model: The IP67 rating and tripled torque make it perfect for industrial handheld tools or medical devices needing submersion resistance and durability.

*Pro Model RPM increase validated via optimized rotor design. **IP67: Dust/waterproof for submersion up to 1m.

Frequently asked questions

  • Which DC motor suits electric toothbrush applications requiring high RPM and torque?

  • How do I maintain the brush commutation system in the SCFR-1230 motor?

  • Why is metal casing preferred for DC motors in small appliances?

  • Can the SCFR-1230 motor be customized for robotics projects?

  • Is the SCFR-1230 motor certified for medical or consumer electronics use?

  • Why does the SCFR-1230 have such a high RPM for its size?

  • How does the metal shaft improve motor longevity?

  • What makes the SCFR-1230 energy-efficient for low-voltage devices?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Brushed DC MotorElectric toothbrushes, small appliances- 3.7V rated voltage (IEC 60034-1) ▲ (Advanced: 5.0V)
- Brushed commutation (ASTM F317)
- 14,785 RPM (ISO 2372) ▲ (Advanced: 18,000 RPM)
- 0.441 mN·m torque (IEC 60034-2-1) ▲ (Advanced: 0.6 mN·m)		- Cost-effective, simple design
- Reliable in high-vibration environments		- Shorter lifespan due to brushes
- Less efficient than brushless motors
Brushless DC MotorDrones, robotics, medical devices- 12V rated voltage (IEC 60034-1)
- Brushless commutation (ASTM F317)
- 12,000 RPM (ISO 2372)
- 0.8 mN·m torque (IEC 60034-2-1)		- Longer lifespan, maintenance-free
- Higher efficiency (IEC 60034-30-1)		- Higher cost
- Requires complex control systems
AC Induction MotorFans, pumps, HVAC systems- 115V/230V (IEC 60034-1)
- 1,800 RPM (ISO 2372)
- 5.0 N·m torque (IEC 60034-2-1)		- Robust and reliable
- Low maintenance		- Bulky design
- Less efficient at partial loads
Coreless DC MotorPrecision instruments, medical devices- 3.0V (IEC 60034-1)
- 20,000 RPM (ISO 2372)
- 0.1 mN·m torque (IEC 60034-2-1)		- High-speed response (ISO 2372)
- Compact size		- Fragile construction
- Limited torque capacity
Stepper Motor3D printers, CNC machines- 12V (IEC 60034-1)
- 500 RPM (ISO 2372)
- 1.2 N·m torque (IEC 60034-2-1)		- Precise positional control
- No feedback loop required		- Noisy operation
- Lower efficiency at high speeds
Servo MotorRobotics, industrial automation- 24V (IEC 60034-1)
- 3,000 RPM (ISO 2372)
- 5.0 N·m torque (IEC 60034-2-1)		- High torque and speed control (ISO 2372)
- Fast response times		- High cost
- Complex installation requirements
