Shenzhen custom made single side printed circuit board pcb solar panel pcba assembly factory

Shenzhen custom made single side printed circuit board pcb solar panel pcba assembly factory

  • 1 - 999 Pieces
    $9.80
  • >= 1000 Pieces
    $1.20
View product details

Shenzhen custom made single side printed circuit board pcb solar panel pcba assembly factory

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Single-Sided PCB Assembly: Designed for mounting and interconnecting electronic components (resistors, capacitors, ICs) on a single layer, enabling compact and cost-effective circuit solutions.
  • High-Reliability Connectivity: Features HASL (Hot Air Solder Leveling) surface finishing and gold-plated contacts for superior solderability, conductivity, and corrosion resistance.

Key features

  • 1. Material Technology

    • With gold-plated contacts and HASL surface finishing, ensure superior conductivity, corrosion resistance, and reliable solderability. ~20% more durable than standard tin-plated PCBs*

  • 2. Interactive Design

    • With an optimized symmetrical layout and high-density component placement, maximize space efficiency for compact electronic systems. ~30% higher component density than standard designs*

  • 3. Performance Parameters

    • With a green solder mask, protect copper traces from oxidation and corrosion, ensuring consistent performance over time. Ideal for high-reliability applications requiring long-term stability.

  • 4. Scenario Solutions

    • Designed for solar panel applications, ensure reliable operation in outdoor environments with corrosion-resistant materials and robust construction. Perfect for harsh conditions where durability and continuous operation are critical.

  • 5. Certification Standards

    • With lead-free HASL surface finishing, comply with RoHS standards for environmental safety, offering a 100% lead-free alternative to traditional PCBs*

Product details

Shenzhen custom made single side printed circuit board pcb solar panel pcba assembly factory

Shenzhen custom-made single-sided PCBs combine precision engineering with customizable features, designed to meet diverse electronic assembly needs. With a green solder mask and HASL (Hot Air Solder Leveling) surface finishing, these PCBs ensure durability and reliability. Gold-plated contacts (optional in advanced models) enhance conductivity and corrosion resistance, ideal for high-reliability applications.

Technical specifications

FeatureSpecificationBenefit
Surface FinishingHASL (Hot Air Solder Leveling)Flat solderable surface for component placement
Solder Mask ColorGreenEnhanced visibility and copper trace protection
Contact PlatingGold-plated (optional on Advanced/Pro)Superior conductivity and corrosion resistance
MaterialFR-4 epoxy laminateFlame retardant and high thermal stability
Thickness1.6mm standardCompatible with most electronic assemblies

Customization guide

Adjustable parameters include:

  • Thickness: From 0.8mm to 3.2mm to fit compact or heavy-duty designs.
  • Component Density: Custom layout optimization for high-density assemblies.
  • Surface Finish: Swap HASL for ENIG (Electroless Nickel Immersion Gold) for advanced soldering requirements.

Get inspired

Design a robust solar panel controller PCB with gold-plated contacts for long-term outdoor use, or a lightweight single-sided board for consumer electronics with optimized HASL finishing for cost-effective production.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Surface FinishHASLHASL + Gold PlatingGold Plating
Thermal Resistance140°C160°C180°C*
Component Density500 components/m²1,200 components/m²2,500 components/m²
Corrosion Resistance48hr salt spray96hr salt spray200hr salt spray*

Supplier's note

  1. Technical Breakthroughs:

    • The Pro Model’s gold-plated contacts offer triple the corrosion resistance of HASL, enabling use in harsh industrial environments.
    • The Advanced Model’s hybrid HASL + gold plating reduces assembly defects by 20% compared to HASL-only designs.
    • FR-4 material ensures 20% higher thermal stability than standard epoxy laminates, supporting high-power applications.

  2. Optimal Version Selection:

    • Base Model: Ideal for low-cost consumer electronics (e.g., LED controllers) where basic durability suffices.
    • Advanced Model: Suited for industrial IoT devices requiring moderate component density and corrosion protection.
    • Pro Model: Best for aerospace or medical equipment needing extreme reliability (e.g., solar panel inverters in corrosive marine environments).

*Pro Model specifications exceed industry benchmarks by 30% in thermal and corrosion resistance.

Frequently asked questions

  • Which single side printed circuit board is best suited for solar panel assemblies?

  • How do I maintain the gold-plated contacts on PCB solar assemblies?

  • HASL vs ENIG surface finishes: Which is better for solar PCBs?

  • Can your Shenzhen PCB factory customize designs for solar panel applications?

  • Is your single-sided PCB compliant with solar industry standards?

  • Which model suits small-scale solar panel projects?

  • Single vs double-sided PCBs: Which is better for solar panels?

  • Does the PCB withstand extreme environmental conditions for solar use?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Surface FinishGeneral Electronics, Cost-Sensitive AppsIndustry Standard: HASL (Lead-based, IPC-6012)
Our Base: HASL (same)
Our Advanced: ENIG (3μm gold, ASTM B499)▲		Cost-effective for mass production (Base)
Enhanced corrosion resistance (Advanced)		Lead content may restrict RoHS compliance (Industry/Base)
Higher cost (Advanced)
Solder MaskOutdoor/Industrial EquipmentIndustry: Green (ISO 12097)
Our Base: Green (same)
Our Advanced: UV-resistant Green (ASTM D523)▲		Standard visibility (Base)
Extended lifespan in harsh environments (Advanced)		No chemical resistance (Base)
Complex coating process (Advanced)
ConductivityHigh-Power DevicesIndustry: 1 oz/ft² copper (IPC-4101)
Our Base: 1 oz▲
Our Advanced: 2 oz▲▲ (IPC-4101)		Meets basic current needs (Base)
Handles 50% higher current (Advanced)▲▲		Limited to low-power apps (Industry/Base)
Higher material costs (Advanced)
Chemical ResistanceChemical Processing EquipmentIndustry: Passes ASTM D543 for 10 chemicals
Our Base: 10 chemicals▲
Our Advanced: 50+ chemicals▲▲ (ASTM D543)		Basic chemical tolerance (Base)
Withstands 50+ chemical exposures (Advanced)		Fails in aggressive chemicals (Industry/Base)
Costly testing (Advanced)
Thermal DurabilityAutomotive/Industrial SystemsIndustry: 500 thermal cycles (IPC-6012)
Our Base: 500 cycles▲
Our Advanced: 1,000 cycles▲▲ (IPC-6012)		Standard for moderate environments (Base)
Survives extreme temp fluctuations (Advanced)▲▲		Fails in harsh thermal cycles (Industry/Base)
Longer production time (Advanced)
CustomizationPrototyping/Specialized DevicesIndustry: Standard layouts
Our Base: Custom layouts (+15% cost)▲
Our Advanced: Full customization (no surcharge)▲▲		Cost-effective for bulk orders (Base)
Rapid prototyping at scale (Advanced)▲▲		Limited design flexibility (Industry)
Higher lead time (Base/Advanced)
