Small Size ST7567 Controller Monochrome 12864 Dots Matrix LCD Module Cog Module

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Resolution Monochrome Display: Equipped with a 128x64 pixel matrix and ST7567 controller, enabling crisp text and graphic rendering for industrial interfaces, IoT devices, or embedded systems.
  • FSTN Transflective Technology: Combines LED backlight (labeled "LED2") with sunlight-readable transflective mode, ensuring visibility in diverse lighting conditions.

Key features

  • 1. Material Technology

    • With a FSTN (Fused Silica Transmissive) substrate and transflective display mode, you can achieve clear visibility in direct sunlight and low-light environments, outperforming standard LCDs in readability*. The Chip On Glass (COG) design ensures durability and compact integration, reducing space requirements compared to traditional modules.

  • 2. Interactive Design

    • With the ST7567 controller and 40-pin interface, you can seamlessly integrate the module into microcontroller-based systems for easy customization of display content and control. Its flexible ribbon cable simplifies connectivity in tight spaces.

  • 3. Performance Parameters

    • With a 128x64 pixel resolution and 3.0V low-power operation (30mA), you can deliver sharp monochrome visuals while consuming ~20% less power than comparable modules*. The wide operating temperature range (-10°C to 70°C) ensures reliability in extreme environments.

  • 4. Scenario Solutions

    • With transflective technology and industrial-grade durability, you can deploy this module in demanding applications like automotive dashboards, industrial control panels, or handheld devices. Its compact size enables use in space-constrained systems.

  • 5. Certification Standards

    • With EPR certifications from Germany and France, you can meet strict environmental regulations for sustainable packaging and disposal, ensuring compliance with EU standards for eco-friendly manufacturing and recycling.

Product details

Small Size ST7567 Controller Monochrome 12864 Dots Matrix LCD Module Cog Module

The HZY Small Size ST7567 Controller Monochrome 128x64 FSTN LCD Module is a compact, high-resolution display engineered for space-constrained applications. With a transflective design, LED backlight, and wide operating temperature range (-10°C to 70°C), it delivers clear visibility in diverse environments. Certified for EU compliance (EPR Germany/France), it integrates seamlessly into IoT, automotive, and industrial systems via its 40-pin interface.

Technical specifications

FeatureSpecificationApplication Scenario
Display Size128x64 pixels (1.8" diagonal)Compact devices requiring high detail
Display TypeFSTN (positive transflective)Outdoor/industrial settings for sunlight readability
BacklightLED (2.0V)Energy-efficient illumination
Power Requirements3.0V @ 30mABattery-operated systems
Operating Temp-10°C to 70°CHarsh industrial or automotive use
Interface40-pin flexible ribbon cableDirect connection to microcontrollers
CertificationsEPR_Germany_Packing, EPR_France_PackingEU-compliant manufacturing

Customization guide

Adjustable parameters include:

  • Backlight brightness (via PWM control) to reduce power consumption in low-light scenarios.
  • Interface pinout customization for non-standard PCB layouts.
  • Temperature tolerance upgrades for extreme industrial applications.

Get inspired

With its transflective FSTN technology and LED backlight, this module is ideal for dashboards, smart sensors, or handheld devices. Its EU certifications simplify deployment in regulated markets, while the ST7567 controller ensures easy integration with Arduino/Raspberry Pi systems.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Resolution128x64128x64 (enhanced PWM)128x64 (16-bit color)*
Brightness100 cd/m²150 cd/m²200 cd/m²
Operating Temp Range-10°C to 70°C-20°C to 80°C-30°C to 85°C
CertificationsEPR_GermanyEPR_Germany/FranceEPR + RoHS

Supplier's note

  1. Technical Breakthroughs:

    • Transflective FSTN: Achieves 30% better sunlight readability vs. standard TN panels.
    • Low Power Consumption: 30mA at 3.0V, 20% lower than traditional LCDs.
    • Extreme Temp Tolerance: Pro Model’s -30°C to 85°C range exceeds industry benchmarks by 20%.

  2. Version Selection Guide:

    • Base Model: Optimal for basic IoT sensors or indoor devices (e.g., thermostats).
    • Advanced Model: Suitable for automotive or outdoor equipment needing EU dual-certification.
    • Pro Model: Ideal for industrial robotics or military gear requiring ultra-reliable performance in extreme conditions.

*Pro Model’s 16-bit color capability enables grayscale gradients for advanced diagnostics.

Frequently asked questions

  • Which LCD module is best suited for compact devices requiring a monochrome display?

  • How do I maintain the LED backlight of this LCD module?

  • What are the advantages of FSTN over TFT in this LCD module?

  • Can this LCD module be customized for Arduino compatibility?

  • Is this LCD module EPR-certified for EU markets?

  • Does the 3.0V power requirement affect performance if using a 3.3V supply?

  • Why choose LED backlight over other types for this LCD module?

  • Is this LCD module suitable for automotive applications?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Display ResolutionCompact devices (e.g., IoT sensors)Industry: 96x64 (common)
Our Base: 128x64 (ST7567 controller)▲
Our Advanced: 128x64 + SPI interface▲▲		Higher resolution for detailed dataRequires more control pins
Backlight TechnologyOutdoor/low-light useIndustry: CCFL (older)
Our Base: LED (LED2)▲
Our Advanced: LED with PWM dimming▲▲		Energy-efficient, thinner profileLess brightness than CCFL in some cases
Power RequirementsBattery-operated devicesIndustry: 5V/50mA
Our Base: 3.0V/30mA▲ (ideal for 3.3V MCUs)
Our Advanced: 3.0V/25mA▲▲		Lower power consumptionMay need voltage regulator
Display TypeHarsh environments (sunlight)Industry: TFT (color) or monochrome LCD
Our Base: FSTN transflective▲
Our Advanced: FSTN + anti-glare coating▲▲		Readable in sunlight without backlightMonochrome limits color applications
Operating TemperatureIndustrial/automotiveIndustry: -20°C to 60°C
Our Base: -10°C to 70°C▲
Our Advanced: -20°C to 80°C▲▲		Wider operational rangeMay require cooling in extreme temps
CertificationsEU market complianceIndustry: CE/RoHS
Our Base: EPR Germany/France▲
Our Advanced: EPR + RoHS▲▲		Compliance with EU packing lawsLimited to regions with EPR requirements
