Steel Workhouse Structure Workshop Warehouse Building Dwg

Steel Workhouse Structure Workshop Warehouse Building Dwg

$25.00-$70.00/ Square Meter|200 Square Meter/Square Meters(Min. Order)
View product details

Steel Workhouse Structure Workshop Warehouse Building Dwg

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Structural Support: Robust steel framing (Q235/Q345 grades) provides high load-bearing capacity and spans large areas without internal columns, ideal for industrial and commercial spaces.
  • Multi-Functional Design: Combines steel beams/trusses with sandwich panels for thermal insulation, enabling adaptable use as warehouses, workshops, or hybrid spaces.

Key features

  • 1. Material Technology

    • With high-strength Q345 steel and insulated sandwich panels, ensure structural durability and energy efficiency compared to conventional materials*. The steel’s corrosion-resistant properties and thermal insulation capabilities make it ideal for harsh industrial environments.

  • 2. Performance Parameters

    • With a steel framework engineered for large-span designs, achieve uninterrupted floor space by eliminating internal columns, offering up to 25% more usable area than column-reliant structures*. The Q235/Q345 steel grades provide superior load-bearing capacity for heavy-duty applications.

  • 3. Scenario Solutions

    • Designed for warehouse and workshop versatility, adapt seamlessly to diverse industrial needs with modular expandability. The open-plan layout allows flexible customization for storage, manufacturing, or assembly operations.

  • 4. Certification Standards

    • Backed by CE certification and compliance with global standards (ASTM, GB, DIN), guarantee safety and reliability for commercial and industrial use. This ensures compatibility with international building regulations and quality benchmarks.

  • 5. Cost Efficiency

    • With light-gauge steel construction, reduce upfront costs by 15%* while maintaining structural integrity compared to heavier steel alternatives*. Faster installation and scalability options further optimize long-term economic benefits.

Product details

Steel Workhouse Structure Workshop Warehouse Building Dwg

The Steel Workhouse Structure Workshop Warehouse Building Dwg combines robust steel frameworks with modular design flexibility, offering durable and cost-effective solutions for industrial and commercial spaces. Certified to global standards (CE), it supports heavy loads and harsh environments while enabling rapid assembly and customization.

Technical specifications

FeatureSpecificationBenefit
MaterialQ235/Q345 steel + Sandwich panels (insulated)High strength-to-weight ratio, corrosion resistance, thermal insulation
CertificationCE compliantEnsures safety and quality for global industrial applications
StandardsAISI, BS, ASTM, DIN, JIS, GBAdaptable to international building codes and regulations
Load CapacityUp to 50 kN/m² (adjustable via beam design)Supports heavy machinery and storage in workshops/warehouses
Construction StyleLight gauge steel framework with open-plan layoutMaximizes space utilization and future expansions

Customization guide

Adjustable parameters include beam spacing (1.5m–3m), panel thickness (50mm–150mm), and roof slope (5°–15°) to meet specific load requirements, climate conditions, or energy efficiency goals.

Get inspired

With its industrial-modern aesthetic and modular steel framework, this structure is ideal for warehouses needing climate-controlled storage or workshops requiring open, adaptable spaces. Pair it with customizable sandwich panels for thermal efficiency or enhanced corrosion-resistant coatings for coastal regions.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Steel GradeQ235Q345Q345 + galvanized
Load Capacity50 kN/m²+15% (57.5 kN/m²)+30% (65 kN/m²)*
Insulation Thickness50mm100mm150mm
Assembly SpeedStandard (2–3 days/m²)20% faster30% faster

Supplier's note

  1. Three Technical Breakthroughs:

    • Q345 Steel Grade (Pro Model): Triple the corrosion resistance of standard steel, enabling safe handling of chemicals in industrial workshops.
    • Modular Sandwich Panels: 150mm insulation reduces energy consumption by 25% compared to traditional warehouses.
    • Light Gauge Steel Framework: 20% faster installation than traditional concrete structures, cutting downtime during expansions.

  2. Optimal Version Selection:

    • Base Model: Ideal for small workshops or temporary storage requiring basic load capacity (e.g., light machinery storage).
    • Advanced Model: Suitable for medium-scale warehouses with moderate climate needs (e.g., food storage requiring 100mm insulation).
    • Pro Model: Best for heavy industrial applications (e.g., automotive manufacturing) needing high load tolerance and extreme durability. Pair its galvanized coating with 150mm insulation for year-round climate control in harsh environments.

Frequently asked questions

  • Which steel workshop warehouse building model suits heavy machinery storage?

  • How to maintain the steel framing of a workshop warehouse to prevent corrosion?

  • Steel vs Concrete: Which is better for industrial workshop warehouses?

  • Can Canglong steel structures be customized for cold storage warehouses?

  • Is the steel workshop building certified for international projects?

  • What makes light gauge steel ideal for workshop warehouses?

  • Can the steel workshop design accommodate crane systems?

  • How does the sandwich panel material benefit workshop warehouses?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Material CompositionIndustrial warehouses, manufacturing plantsIndustry Standard: Q235 steel (235 MPa yield strength) + 50mm sandwich panel (R-4 insulation)
Our Base: Q345 steel (345 MPa) + 60mm panel (R-5)
Our Advanced: Q345 steel + 75mm panel (R-6.5)		▲ Base: 42% stronger steel for heavy equipment support
▲ Advanced: 63% better thermal insulation vs standard		Advanced tier adds 15% cost for thicker panels
Load CapacityWorkshop equipment storageIndustry: 2.0 kN/m² (ASTM A36)
Base: 2.5 kN/m² (▲1.5x)
Advanced: 3.0 kN/m² (▲2x)		▲ Base: Supports 5-ton forklifts
▲ Advanced: Handles 8-ton cranes		Requires reinforced foundations for Advanced tiers
Fire ResistanceFire-sensitive zones (e.g., chemical plants)Industry: 30-min fire rating (ASTM E119)
Base: 60-min rating (▲2x)
Advanced: 90-min rating (▲3x)		▲ Advanced: Meets NFPA 221 Class II-A standardsFire-rated panels increase weight by 20%
Thermal EfficiencyClimate-controlled warehousesIndustry: R-4 insulation
Base: R-5 (▲25%)
Advanced: R-6.5 (▲63%)		▲ Advanced: Reduces HVAC energy use by 30%
▲ Base: 15% lower cooling costs		Advanced panels reduce natural light penetration
Installation SpeedRapid-deployment facilitiesIndustry: 15 days/1,000m²
Base: 12 days (▲20%)
Advanced: 10 days (▲50%)		▲ Modular design cuts labor costs by $8,500/1,000m²Advanced pre-fab requires specialized cranes
Compliance CertificationsGlobal export projectsIndustry: CE
Base: CE + ISO 3801
Advanced: CE + ISO 3801 + ASTM A36		▲ Advanced: Pre-qualified for EU/US markets
▲ Base: Meets ISO insulation standards		Certification audits add 2-3 weeks to delivery
