Stepper Magnetic Cnc Encoder Linear Pictures Capacitive Linear Encoder Analog Output Encoder

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Precision Position Measurement: Combines magnetic and capacitive sensing technologies to provide accurate linear displacement feedback for CNC machines and industrial automation systems.
  • Analog Output Compatibility: Delivers continuous analog signals for seamless integration into control systems, enabling real-time monitoring and adjustment.

Key features

  • 1. Durable Material Construction

    • With a rugged rubber-insulated cable, you can ensure protection against moisture, chemicals, and mechanical stress in harsh industrial environments, outperforming standard PVC cables*

  • 2. User-Friendly Color-Coded Wiring

    • With color-coded wiring, you can streamline installation and reduce wiring errors by up to 25% compared to unmarked connectors*

  • 3. Precision Analog Output Performance

    • With capacitive sensing technology and 110V compatibility, you can achieve sub-millimeter measurement accuracy while maintaining stable operation in standard industrial setups*

  • 4. Industrial-Grade Durability & Reliability

    • Designed for continuous 24/7 operation, you can support uninterrupted manufacturing processes with a 40% longer lifespan than entry-level encoders in heavy-duty applications*

  • 5. Compliance with Safety Standards

    • With certifications meeting ISO 13849-1 PLc requirements, you can ensure safe integration into industrial automation systems while meeting global regulatory standards*

Product details

Stepper Magnetic Cnc Encoder Linear Pictures Capacitive Linear Encoder Analog Output Encoder

The Stepper Magnetic CNC Encoder Linear Pictures Capacitive Linear Encoder Analog Output Encoder is designed for precision measurement and control in industrial applications. Built with a durable rubber-insulated cable and a multi-wire connector, it ensures reliable performance in harsh environments. The analog output enables seamless integration with control systems, while color-coded wires simplify installation and maintenance.

Technical specifications

FeatureSpecificationBenefit
MaterialDurable rubber-insulated coatingWithstands moisture, chemicals, and mechanical stress
Voltage Rating110VSafe operation in standard industrial systems
Connector TypeMulti-wire rectangular connectorSupports simultaneous transmission of multiple signals
Wire IdentificationColor-coded conductorsReduces installation errors and improves usability
Temperature Range-20°C to 70°COperates reliably in diverse environmental conditions

Customization guide

Adjustable parameters include wire gauge, connector type, and shielding level to meet specific requirements such as higher current load, specialized device compatibility, or enhanced EMI protection.

Get inspired

With its analog output and precise measurement capabilities, this encoder is ideal for CNC machining, robotics, and industrial automation. The rugged design ensures longevity in factories, while the multi-wire connector simplifies complex system integration.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Resolution0.1 mm+15% (0.088 mm)+30% (0.07 mm)*
Accuracy±0.5% FS±0.3% FS±0.1% FS
Chemical ResistanceStandardEnhancedTriple-industry grade
Operating Temp.-20°C to 70°C-30°C to 80°C-40°C to 90°C

Supplier's note

  1. Technical Breakthroughs:

    • The triple-industry-grade chemical resistance (Pro Model) enables safe use in chemical plants or outdoor environments.
    • Color-coded wiring reduces installation errors by 40% compared to unmarked cables.
    • Analog output ensures real-time feedback with 0.1% accuracy, critical for precision machinery.

  2. Version Selection Guide:

    • Base Model: Ideal for standard workshops needing basic precision (e.g., small CNC machines).
    • Advanced Model: Suitable for mid-scale automation requiring improved accuracy and wider temperature tolerance (e.g., automotive assembly lines).
    • Pro Model: Best for extreme environments (e.g., oil refineries or aerospace manufacturing) where durability and ultra-precision are critical.

With the Pro Model’s chemical resistance and -40°C to 90°C range, you can ensure uninterrupted operation in harsh settings. Pair this with its ±0.1% accuracy to achieve millimeter-level precision in demanding applications.

Frequently asked questions

  • Which Stepper Magnetic CNC Encoder suits harsh industrial environments?

  • How to clean the multi-wire connector of the Capacitive Linear Encoder?

  • What materials are used in the Stepper Magnetic CNC Encoder cable?

  • Can the Stepper Magnetic CNC Encoder be customized for specific needs?

  • Is the Analog Output Encoder compatible with 110V systems?

  • What applications use the multi-wire connector in CNC encoders?

  • How do color-coded wires improve the Capacitive Linear Encoder’s usability?

  • Can this encoder withstand outdoor conditions?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Capacitive Linear EncodersClean environments (semiconductor, labs)Resolution: 1 micron (ISO 10360).
Base: 0.8 micron		High precision, non-contactSusceptible to contamination (requires clean environment)
Magnetic Linear EncodersIndustrial machinery (conveyors, robotics)Resolution: 5–25 micron (ISO 10360).
Base: 10 micron		Rugged, cost-effectiveLower resolution ▲ Advanced: 5 micron (better than industry avg)
Optical Linear EncodersCNC machining, precision instrumentsResolution: 0.1–1 micron (ISO 10360).
Advanced: 0.1 micron ▲ (Industry: 0.5)		Highest accuracyFragile, needs clean environment (IEC 60204)
Analog Output EncodersAnalog control systems (HVAC, pumps)Output: 24V (Industry).
Advanced: 110V ▲ (Base: 24V)		Smooth signal, easy integrationSusceptible to electrical noise (IEC 60204)
Digital Output EncodersPLCs, digital control systemsOutput: RS-485 (IEC 61158).
Advanced: 1 Gbps ▲ (Base: 100 Mbps)		Noise immunity, long-distance transmissionRequires digital interfaces (MIL-STD-810)
Industrial-Grade EncodersHarsh environments (factories, outdoors)IP67 (Industry).
Advanced: IP69K ▲ (Base: IP67)		Durable, withstands dust/waterHigher cost compared to standard encoders
