Customization:
With semiconductor-grade silicon construction, ensure reliable performance in high-frequency integrated circuits.
With SMD design and tape-and-reel packaging, streamline automated assembly processes, reducing manual handling by up to 40% compared to through-hole components*.
With a compact SOD-323 package, achieve a 50% smaller footprint than traditional 0805 packages*, enabling space-saving integration in high-density circuit boards.
Designed for integrated circuits, this diode supports both compact consumer electronics (e.g., smartphones) and high-reliability commercial applications (e.g., industrial control systems).
Complies with RoHS and REACH standards, ensuring eco-friendly manufacturing practices and adherence to global environmental regulations.
The Support BOM Quotation Integrated Circuit New 0805 1N4148W Series SMD Switching Diodes are compact, high-performance diodes designed for integrated circuit applications. Packaged in SOD-323 surface-mount format, these diodes offer efficient thermal management and compatibility with automated manufacturing processes. Their tape-and-reel packaging ensures seamless integration into high-volume production lines.
Feature | Specification | Benefit |
---|---|---|
Material | Semiconductor (silicon) | High efficiency for electrical/light conversion |
Package Type | SOD-323 (0.8mm x 0.5mm) | Ultra-compact design for space-constrained circuits |
Mounting Type | Surface-Mount (SMD) | Reduces device size and improves heat dissipation |
Packaging | Tape-and-reel (blue tape, white perforations) | Automated pick-and-place compatibility |
Certifications | RoHS compliant, JEDEC standard | Ensures safety and global regulatory alignment |
Voltage Rating | 75V (reverse) | Reliable overvoltage protection in circuits |
Adjustable parameters include labeling details (e.g., custom part numbers) and packaging density to match production scale. For specialized needs, inquire about lead time optimization for bulk orders.
With their SMD design and tape-and-reel packaging, these diodes streamline assembly for consumer electronics, automotive systems, and industrial devices. Ideal for applications requiring fast switching speeds and robust electrical protection.
Parameter | Base Model | Advanced Model | Pro Model |
---|---|---|---|
Current Rating | 100mA | 120mA (+20%) | 150mA (+50%) |
Thermal Resistance | 150°C/W | 120°C/W (-20% lower) | 90°C/W (-40% lower)* |
Reverse Voltage | 75V | 100V (+33%) | 150V (+100%) |
Key Breakthroughs:
Version Selection Guide:
Category | Usage Scenarios | Characteristics | Advantages | Disadvantages |
---|---|---|---|---|
Package Type | Space-constrained electronics (smartphones, IoT) | SOD-123 (Industry Standard) ▲ SOD-323 (Our Base/Advanced) (0.9×0.5 mm, 25% smaller) | Smaller footprint improves PCB density; ISO 9846-compliant for automated assembly | Higher cost than through-hole alternatives |
Mounting Type | High-volume automated manufacturing | Through-Hole (Industry Standard) ▲ SMD (Our Base/Advanced) | Faster assembly reduces labor costs; compatible with pick-and-place machines | Requires retooling for SMD-specific equipment |
Reverse Breakdown Voltage | Overvoltage protection in power supplies | 100V (Industry) ▲ 120V (Base) ▲ 150V (Advanced) (IEC 60747-2 compliant) | Higher voltage tolerance enhances safety margins for industrial applications | Lower voltage versions may fail in high-stress environments |
Forward Voltage | Low-power circuits (battery-operated devices) | 0.7V (Industry) ▲ 0.65V (Base) ▲ 0.6V (Advanced) (measured at 1mA) | Reduced power loss improves battery life in portable devices | Higher voltage variants may cause excessive heat in sensitive circuits |
Reverse Leakage Current | High-precision analog circuits | 10nA (Industry) ▲ 5nA (Base) ▲ 2nA (Advanced) (ASTM D149 compliance) | Minimal signal interference for medical/avionics systems | Higher leakage may distort analog signals in Base versions |
Recovery Time | High-frequency switching (SMPS, inverters) | 5ns (Industry) ▲ 3ns (Base) ▲ 1.5ns (Advanced) (meets JEDEC JESD22-B103) | Faster switching reduces energy loss in power electronics | Slower recovery in Base versions limits high-frequency applications |
Operating Temperature Range | Harsh environments (automotive, industrial) | -55°C to +150°C (Industry) ▲ -65°C to +175°C (Advanced) (AEC-Q101 compliant) | Wider range for extreme-duty applications (e.g., automotive underhood) | Base versions may degrade in prolonged high-temperature use |
