Wifi Repeater Router PCB Circuit Board

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Signal Amplification & Routing: Designed to enhance Wi-Fi signal strength and expand network coverage, enabling seamless data transmission for repeater router applications.
  • High-Performance Layout: Utilizes FR-4 material and precise trace routing with vias to support complex digital/analog signal processing, ensuring reliability in high-frequency environments.

Key features

  • 1. Material Technology

    • With FR-4 material, ensure superior thermal and electrical stability compared to standard PCB materials*, enabling reliable operation in demanding environments.

  • 2. Interactive Design

    • With a customizable layout design, easily integrate diverse components for tailored functionality*, making it adaptable to specific project needs.

  • 3. Performance Parameters

    • With optimized trace routing, achieve faster data transmission speeds compared to conventional PCB designs*, enhancing network performance.

  • 4. Scenario Solutions

    • Designed for both home and commercial use, providing seamless network extension in diverse environments.

  • 5. Certification Standards

    • Constructed with FR-4 material, meeting industry standards for durability and safety*.

Product details

Wifi Repeater Router PCB Circuit Board

This high-performance WiFi Repeater Router PCB is engineered for reliable signal transmission and thermal management in complex electronic systems. Built with FR-4 material and a green solder mask, it combines durability with precision routing for seamless network expansion.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialFR-4 epoxy laminateEnsures thermal and electrical stability in routers/repeaters
Surface FinishImmersion gold (ENIG)Prevents oxidation, enabling reliable solder joints for SMT components
Trace RoutingHigh-density 6-8 layer designSupports complex signal paths in WiFi repeaters for reduced interference
ViasMicrovias + through-hole viasEfficient thermal dissipation and signal routing in high-frequency applications
Solder MaskGreen epoxy solder maskProtects copper traces while enhancing visibility during assembly

Customization guide

Adjustable trace widths (0.15mm–0.3mm) and via configurations (microvia density) to meet specific component placement needs for customized electronics designs.

Get inspired

This PCB’s precision layout and FR-4 material make it ideal for expanding WiFi coverage in smart homes or industrial IoT systems. Its microvia architecture ensures optimal thermal management, even under heavy data load.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Signal Bandwidth100MHz+15% (115MHz)+30% (130MHz)*
Thermal Dissipation5W/cm²Enhanced 7W/cm²Premium 10W/cm²
Layer Count4 layers6 layers8 layers
Material DurabilityFR-4 standardFR-4 + reinforced glassHigh-TG FR-4 (+20% temp resistance)

Supplier's note

  1. Technical Breakthroughs:

    • FR-4 Material: Triple the thermal stability of standard PCBs, ensuring reliability in high-temperature environments.
    • Microvia Architecture: Reduces signal loss by 20% compared to traditional via designs, critical for WiFi repeaters.
    • 8-Layer Routing: Enables simultaneous handling of 2.4GHz and 5GHz bands without cross-talk.

  2. Version Selection Guide:

    • Base Model: Ideal for basic home repeaters requiring stable 100MHz signal processing.
    • Advanced Model: Choose for commercial IoT setups needing 15% faster data throughput and 40% better thermal performance.
    • Pro Model: Designed for industrial-grade applications (e.g., smart factories) where extreme bandwidth (130MHz) and heat resistance (up to 170°C) are critical. With its 8-layer design, it minimizes latency in high-density networks.
