Winding Coil Machine Automatic Oil Type Transformer Coil Winding Machine

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Automatic Winding Process: Designed for precision winding of transformer coils using CNC technology, enabling consistent and accurate production of electrical components.
  • Material Handling: Capable of processing various materials (e.g., wire, cable, tape) with adjustable rollers and spindles to accommodate different thicknesses and diameters.

Key features

  • 1. Corrosion-Resistant Metal Body & Precision CNC Machining

    • With a corrosion-resistant metal body and precision CNC-machined components, ensure durable, long-lasting operation in industrial environments while maintaining consistent coil accuracy.

  • 2. Intuitive Digital Control Panel with Multi-Program Presets

    • With an intuitive digital control panel and multi-program presets, customize winding patterns effortlessly to suit different transformer coil requirements, streamlining production workflows.

  • 3. High-Speed Automatic Winding for Enhanced Efficiency

    • With a high-speed motor and automatic operation, achieve rapid coil winding—up to 30% faster than manual models*—to boost output in commercial or industrial settings.

  • 4. Adaptable Spindle Design for Versatile Material Handling

    • With adjustable spindles and rollers, handle diverse wire/cable thicknesses and diameters, ensuring compatibility with various transformer manufacturing needs.

  • 5. ISO Safety-Certified Design for Reliable Operation

    • With ISO safety certifications and emergency stop features (e.g., the yellow lever), ensure compliance with industrial standards and operator safety during continuous use.

Product details

Winding Coil Machine Automatic Oil Type Transformer Coil Winding Machine

The Winding Coil Machine Automatic Oil Type Transformer Coil Winding Machine is a robust, CNC-controlled industrial solution designed for precision winding of transformer coils. Equipped with automated features and customizable parameters, it ensures consistent performance across diverse material handling requirements.

Technical specifications

FeatureSpecificationApplication Scenario
Control TypeCNC (Computer Numerical Control)Precision winding in transformer manufacturing
Automation LevelFully AutomaticHigh-volume production lines
Material HandlingSupports materials up to 50mm diameterWinding thick transformer coils
Safety FeaturesEmergency stop lever, overload protectionIndustrial environments requiring operator safety

Customization guide

Adjustable parameters include winding tension, speed, and material diameter tolerance to meet specific production needs. The CNC system allows programming for custom coil patterns and thickness requirements.

Get inspired

With CNC precision, you can achieve uniform coil winding for high-performance transformers. Its fully automatic operation reduces downtime, while adjustable tension settings ensure material integrity even for delicate wires.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Maximum Material Diameter50mm60mm (+20%)70mm (+40%)
Processing Speed10m/min12m/min (+20%)15m/min (+50%)
Automation FeaturesBasic presetsAI-assisted adjustmentsFull AI optimization

Supplier's note

  1. Technical Breakthroughs:

    • CNC Precision: Enables sub-millimeter accuracy for complex coil geometries.
    • AI-Driven Automation: The Pro Model’s AI optimization reduces errors by 30% compared to traditional methods.
    • Safety Redesign: Emergency stop and overload protection exceed ISO 13849-1 safety standards.

  2. Version Selection Guide:

    • Base Model: Ideal for small-to-medium workshops requiring reliable, cost-effective winding for standard transformers.
    • Advanced Model: Suitable for mid-scale manufacturers needing adaptive settings for mixed material types (e.g., copper vs. aluminum).
    • Pro Model: Designed for large industrial facilities demanding high throughput and AI-driven quality control. Its 70mm capacity handles heavy-duty coils, while 15m/min speed cuts production cycles by 20% versus competitors.

Frequently asked questions

  • Which winding coil machine model suits small workshops for oil-type transformer production?

  • How to clean and maintain the rollers of an automatic oil-type transformer coil winding machine?

  • Copper vs Aluminum coils: Which material works best with this CNC automatic winding machine?

  • Can this automatic coil winding machine be customized for non-standard transformer coil dimensions?

  • Is the automatic oil-type winding machine CE-certified and FDA-approved for material safety?

  • What’s the maximum thickness of materials this transformer coil winding machine can handle?

  • How many coils can the automatic winding machine produce per hour for medium-sized transformers?

  • Does the machine require dedicated installation space, or can it integrate into existing production lines?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Automation LevelHigh-volume production, precision manufacturingIndustry Standard: Manual operationOur Base: Semi-automated (ISO 13849-1) ▲
Our Advanced: Fully automated with CNC/PLC (ISO 13849-1) ▲▲		Reduces human error, increases throughput
PrecisionTransformer coil winding with tight tolerancesIndustry Standard: ±0.1mm manualOur Base: ±0.05mm via servo motors (ISO 230-2) ▲
Our Advanced: ±0.01mm via CNC (ISO 230-2) ▲▲		Higher precision improves transformer efficiency
Material HandlingHandling large spools of copper wireIndustry Standard: Up to 200kg (ISO 9283)Our Base: 300kg ▲
Our Advanced: 500kg ▲▲		Handles heavier materials without deformation
SpeedMass production of transformer coilsIndustry Standard: 60 RPM (IEC 60204)Our Base: 90 RPM ▲
Our Advanced: 120 RPM ▲▲		Faster production cycles
Safety FeaturesFactory environments with multiple operatorsIndustry Standard: Basic emergency stopOur Base: Dual safety sensors (EN ISO 13850) ▲
Our Advanced: Full safety enclosure ▲▲		Compliance with OSHA standards
CustomizationCustom transformer designsIndustry Standard: Fixed spindle sizesOur Base: Adjustable spindles (custom specs) ▲
Our Advanced: Fully programmable parameters ▲▲		Flexibility for diverse projects
