Equivalent or Original Power Relay CMA56H S DC12V C

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Power Circuit Control: Designed to manage high-current electrical systems using a 12V DC signal, enabling safe and efficient power regulation in demanding applications.
  • PCB Mount Compatibility: Features a flat, shell-type design with 5 pins for seamless integration into printed circuit boards (PCBs) in electronic devices and systems.

Key features

  • 1. Corrosion-Resistant Alloy Construction

    • With a corrosion-resistant alloy body and durable plastic enclosure, ensure long-lasting performance in harsh environments compared to all-plastic relays*.

  • 2. Versatile PCB Mount Design

    • With a PCB mount design and multiple wiring terminal types (screw, spring-loaded, soldering), simplify installation and adapt to diverse circuit configurations* compared to models with limited terminal options.

  • 3. High-Current Handling Capacity

    • With a 5-pin configuration optimized for power applications, handle high-current loads reliably for stable operation in demanding systems*.

  • 4. Space-Saving Flat Shell Design

    • With a flat shell design and PCB compatibility, seamlessly integrate into compact electronic devices and automotive systems requiring space-saving solutions* compared to bulkier alternatives.

  • 5. Safety-Compliant Materials

    • With flame-retardant plastic enclosures meeting industrial safety standards (e.g., UL94), ensure compliance in commercial and industrial environments*.

Product details

Equivalent or Original Power Relay CMA56H S DC12V C

The Equivalent or Original Power Relay CMA56H S DC12V C is a compact, PCB-mounted relay designed for high-current power control applications. Built with an alloy-and-plastic construction and a flat shell design, it offers durability, low-profile integration, and reliable performance in automotive, industrial, and electronic systems. With a 5-pin configuration and DC12V operation, it enables precise low-voltage control of high-power circuits.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialAlloy contacts, plastic enclosureHigh-current circuits and insulation
Connector TypePCB through-hole mountCompact PCB integration in control panels
Pins5-pin configurationMulti-channel control in industrial systems
ShapeLow-profile flat shellSpace-constrained devices like automotive ECUs
TypeSealed shell relayEnvironmental protection in harsh settings

Customization guide

Adjustable parameters include:

  • Contact Configuration: Customize pole/throw types (SPST/DPDT) for specific switching needs.
  • Terminal Type: Swap screw terminals for spring-loaded or soldered connections.
  • Material Composition: Reinforce alloy contacts for higher current ratings or add waterproofing for outdoor use.

Get inspired

With its robust alloy contacts and PCB mount design, this relay is ideal for applications requiring reliable power switching in tight spaces. For instance, in automotive systems, it can control engine management circuits, while in industrial setups, it manages motor control or safety systems.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Current Rating10A+50% (15A)+100% (20A)
Operating Temp Range-20°C to 70°C-30°C to 70°C-40°C to 85°C
Insulation Resistance100MΩ150MΩ200MΩ
WaterproofingN/AIP54 (dust/water)IP67 (submersion)

Supplier's note

  1. Technical Breakthroughs:

    • Alloy Contacts: Triple the corrosion resistance of standard copper contacts, extending lifespan in corrosive environments.
    • Low-Profile Design: 20% thinner than industry benchmarks, enabling compact PCB layouts.
    • IP67 Waterproofing (Pro): Enables use in outdoor/wet environments without additional housing.

  2. Version Selection Guide:

    • Base Model: Ideal for standard industrial controls (e.g., HVAC systems) where 10A suffices.
    • Advanced Model: Choose for automotive or food-processing environments needing IP54 protection and wider temp tolerance.
    • Pro Model: Best for extreme scenarios like marine equipment or oil rigs, leveraging 20A capacity and IP67 submersion resistance.

With the Pro’s IP67 rating, you can deploy relays in outdoor pumps without additional enclosures. The Advanced Model’s expanded temp range ensures reliability in cold-chain logistics systems.

Frequently asked questions

  • Which power relay model suits high-current applications for automotive systems?

  • How do I maintain a PCB-mounted relay like the CMA56H S DC12V C?

  • Alloy vs. Plastic in relay construction: Which material is better for durability?

  • Can the CMA56H S DC12V C relay be customized for specific wiring needs?

  • Is the CMA56H S DC12V C compliant with industrial safety standards?

  • Which relay is best for PCB-mounted projects requiring flat design?

  • Should I choose SPST or DPDT for my relay application?

  • Can this relay operate in extreme temperatures or wet environments?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
PCB Mount RelaysElectronics manufacturing, embedded systemsPlastic (Industry) ▲ Alloy+Plastic (Base) ▲▲ Reinforced Alloy (Advanced)
(IEC 60947-5-1 compliant, 20A capacity)		Easy PCB integration, lightweight, enhanced heat dissipation ▲▲Lower current capacity vs panel mounts, requires precise soldering
High Current HandlingIndustrial machinery, automotive systems10A (Industry) ▲ 15A (Base) ▲▲ 20A (Advanced)
(IEC 60947-5-1 compliant)		Handles heavy loads efficiently, reliable for power distributionLarger footprint, higher cost for advanced versions
Waterproof RelaysMarine electronics, outdoor equipmentNon-waterproof (Industry) ▲ IP65 (Base) ▲▲ IP67 (Advanced)
(MIL-STD-810G, submersible 1m/30min)		Operates in harsh environments, corrosion-resistant ▲▲Higher cost due to sealing mechanisms, complex installation
Customizable WiringSpecialized machinery, roboticsFixed wiring (Industry) ▲ Modular terminals (Base) ▲▲ Fully configurable (Advanced)
(Supports 5+ wiring types)		Adapts to unique system requirements, reduces downtime ▲▲Requires technical expertise, longer setup time
Low Voltage ControlSafety-critical systems, IoT devices24V (Industry) ▲ 12V (Base) ▲▲ 5V (Advanced)
(IEC 60950-1 compliant)		Energy-efficient, reduces voltage risks ▲▲, safer for sensitive circuitsLimited compatibility with legacy systems, requires voltage conversion
Compact Design RelaysPortable devices, space-constrained panels30x30mm (Industry) ▲ 25x25mm (Base) ▲▲ 20x20mm (Advanced)
(ISO 9001 certified)		Saves panel space, ideal for miniaturized systems ▲▲May compromise heat dissipation, delicate handling required
