mv Hv transformers High Voltage Transformer 1600kVA 11kV 24kV 35KV 40.5kV Oil Immersed Electrical Transformer

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High Voltage Transformation: Designed to efficiently step down voltages from 35kV/24kV to 480V/11kV, enabling reliable power distribution for industrial and commercial applications.
  • Versatile Cooling Systems: Equipped with ONAF (Oil Natural Air Forced) and ONAN (Oil Natural Air Natural) cooling methods to ensure optimal performance under varying load conditions.
  • Global Frequency Compatibility: Supports both 50Hz and 60Hz frequencies, ensuring seamless operation across international power grids.

Key features

  • 1. Corrosion-Resistant Material Technology

    • With a robust oil-immersed design and corrosion-resistant materials, ensure reliable operation in harsh industrial environments. The sealed structure minimizes contamination risks, offering superior durability compared to open-type transformers*.

  • 2. Adaptable Frequency Compatibility

    • Supporting both 50Hz and 60Hz frequencies, this transformer enables seamless deployment across global power grids without reconfiguration, unlike region-specific models*.

  • 3. High-Capacity Voltage Handling

    • With a rated primary voltage of 24.0kV and support for voltages up to 40.5kV, deliver consistent power output for large-scale industrial applications, outperforming standard 20kV-class transformers*.

  • 4. Dual Cooling Method Flexibility

    • Equipped with ONAF (oil-natural/air-forced) and ONAN (oil-natural/air-natural) cooling, balance energy efficiency and continuous operation in commercial settings, reducing downtime compared to single-mode systems*.

  • 5. Comprehensive Safety Compliance

    • Constructed to meet international electrical safety standards (e.g., IEC/IEEE), ensuring reliable performance in critical power infrastructure while prioritizing operator safety*.

Product details

mv Hv transformers High Voltage Transformer 1600kVA 11kV 24kV 35KV 40.5kV Oil Immersed Electrical Transformer

The BD A Series High Voltage Transformer (1600kVA, 11kV–40.5kV) is a robust oil-immersed power transformer designed for medium to high-voltage applications. Its three-coil configuration and dual cooling modes (ONAF/ONAN) ensure reliable performance in industrial, utility, and commercial power distribution systems.

Technical specifications

FeatureSpecificationBenefit
Rated Capacity1600kVASupports large-scale power distribution
Voltage RatingsInput: 35kV/24kV/11kV; Output: 480V/11kVFlexible voltage adaptation for diverse grids
Cooling MethodONAF (forced air), ONAN (natural air)Ensures thermal stability under load spikes
Frequency50Hz/60Hz dual compatibilityGlobal deployment readiness
TypePower TransformerOptimized for steady-state power transfer

Customization guide

Adjustable parameters include input/output voltage configurations (e.g., 35kV to 480V) and cooling system settings (ONAF/ONAN) to meet specific power density or thermal management needs.

Get inspired

The BD A Series is ideal for industrial plants, data centers, and substations requiring reliable high-voltage conversion. Its oil-immersed design and robust insulation (up to 40.5kV) ensure safety in harsh environments.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Voltage Handling35kV40.5kV40.5kV + 20% surge capacity*
EfficiencyIEC 60076 Standard+8% efficiency+15% efficiency*
Thermal PerformanceONAN onlyONAF/ONAN hybridONAF +智能温控系统**

Supplier's note

  1. Technical Breakthroughs:

    • Voltage Flexibility: Supports 11kV to 40.5kV input, enabling compatibility with tiered grid infrastructure.
    • Dual Cooling: ONAF/ONAN hybrid mode reduces downtime in fluctuating load scenarios.
    • Frequency Adaptability: 50Hz/60Hz operation eliminates the need for grid-specific redesigns.

  2. Model Selection Guidance:

    • Base Model: Ideal for standard substations with stable 35kV grids.
    • Advanced Model: Recommended for industrial sites with frequent load variations (e.g., factories).
    • Pro Model: Best for high-stress environments (e.g., mining, offshore platforms) needing 20% higher surge tolerance and AI-driven thermal control.

*Compared to IEC 60076-8 benchmarks.
**智能温控系统 = Smart Temperature Control System (AI-powered cooling optimization).

Frequently asked questions

  • Which high voltage transformer model is best for industrial power supply up to 1600kVA?

  • How do I maintain an oil-immersed transformer with ONAF/ONAN cooling systems?

  • What’s the difference between ONAF and ONAN cooling in 35kV transformers?

  • Is this 11kV-480V transformer compatible with 60Hz electrical systems?

  • Can the 24kV primary voltage be adjusted for custom power distribution?

  • Does the 40.5kV transformer meet IEEE or IEC safety standards?

  • How does the three-coil design enhance efficiency in power transformers?

  • What customization options are available for 35kV input voltage configurations?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Core & Coil DesignIndustrial power distributionTriple-coil configuration (IEC 60076-7) ▲
Industry: Dual-coil (24kV)
Our Base: Triple-coil (24kV)
Our Advanced: Amorphous core ▲ (40.5kV)		Enhanced power transfer efficiency ▲
Reduced energy loss in Advanced		Higher material costs for Advanced
Cooling EfficiencyData centers, substationsCooling: ONAF & ONAN (IEEE C57.91)
Industry: ONAN only
Our Base: ONAF/ONAN (24kV)
Our Advanced: Enhanced ONAF ▲ (40.5kV)		Flexible cooling modes for varied environments ▲
Advanced: 20% lower temp rise		Higher maintenance for ONAF systems in Advanced
Voltage HandlingHigh-voltage grids (35kV–40.5kV)Rated Primary Voltage: 24kV ▲
Industry: ≤35kV
Our Base: 24kV
Our Advanced: 40.5kV ▲ (IEC 60076-1)		Base: Meets 24kV grid needs
Advanced: Supports 40.5kV (▲ exceeds IEC 60726)		Advanced requires specialized installation expertise
Frequency CompatibilityGlobal power grids (50/60Hz)Dual-frequency (50/60Hz) ▲
Industry: 50Hz only
Our Base/Advanced: Both frequencies (IEC 60076-7)		Seamless deployment in US/Asia markets ▲
No need for retrofitting		Slightly heavier core design compared to single-frequency units
Thermal PerformanceHigh-load industrial plantsThermal Endurance: 155°C (ASTM D2294)
Industry: 120°C
Our Base: 155°C
Our Advanced: 180°C ▲ (ASTM D2294)		Base: 30% better heat dissipation than industry ▲
Advanced: 50% cooler under load		Advanced uses premium insulation (costs +20%)
Noise LevelUrban substations, hospitalsNoise: 62 dBA (IEC 60076-3) ▲
Industry: 75 dBA
Our Base: 68 dBA (quieter than refrigerator hum)
Advanced: 62 dBA ▲ (whisper-quiet)		Advanced: Meets hospital noise regulations ▲
Base: Ideal for commercial zones		Advanced requires sound-dampening materials (adds 10% weight)
