Transformer Core Plate

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Transformer Core Support: Designed to form the magnetic core of transformers, ensuring efficient energy transfer and minimal energy loss through its EI lamination pattern and non-oriented silicon steel composition.
  • Durability & Protection: Coated finish and cold-rolled steel construction enhance corrosion resistance and mechanical strength, suitable for high-stress electrical applications.

Key features

  • 1. Advanced Material Technology

    • With a coated, cold-rolled non-oriented silicon steel core, you can ensure superior magnetic efficiency and corrosion resistance in harsh industrial environments*. The coated finish protects against rust and wear, outperforming standard steel plates without compromising electrical performance.

  • 2. Optimized Performance Parameters

    • With ASTM/DIN/BS-compliant silicon steel, you can achieve up to 15% higher magnetic permeability compared to generic steel grades*, enabling efficient energy transfer in transformers and reducing operational losses.

  • 3. Versatile Manufacturing Flexibility

    • With integrated processing services (decoiling, bending, punching), you can customize the plate to fit diverse transformer designs*, streamlining assembly and reducing production downtime.

  • 4. Multi-Standard Certification Assurance

    • With compliance to ASTM, DIN, JIS, and other global standards, you can guarantee reliability and safety for use in international projects*, meeting strict quality and safety requirements.

  • 5. Industrial Scenario Adaptability

    • With a robust, coated metallic structure, you can deploy the plate in high-stress environments like power plants or manufacturing facilities*, offering durability comparable to premium-grade materials at a competitive cost*.

Product details

Transformer Core Plate

The Transformer Core Plate is a precision-engineered component designed for transformer core construction. Crafted from high-grade non-oriented silicon steel, this plate ensures optimal magnetic performance and energy efficiency. With a coated finish and compliance to global standards (ASTM, DIN, etc.), it delivers durability and adaptability for diverse electrical applications.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialNon-oriented silicon steel (ASTM, DIN, BS, AISI, JIS, GB compliant)Core construction in power transformers and electrical machinery
FinishCoated for corrosion resistance and surface protectionHarsh industrial environments
ProcessingCold-rolled, with decoiling, welding, bending, punching, and cutting servicesCustom fabrication for transformer designs
Thickness Tolerance±0.02mm (meets precision lamination requirements)High-efficiency transformer core assemblies
PatternEI lamination configurationModular core assembly in electrical equipment

Customization guide

Adjustable parameters include plate dimensions, hole patterns, and edge finishing to meet specific transformer design requirements. For instance, custom bending angles or punching layouts can optimize core alignment and heat dissipation.

Get inspired

With its non-oriented silicon steel composition and precision cold-rolling, this plate ensures minimal energy loss in transformers. The coated finish and ASTM/DIN compliance make it ideal for global industrial and commercial projects.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Material GradeStandard silicon steelHigh-silicon steel (+15% permeability)Premium ultra-low-loss steel (+30% efficiency)*
Thickness Tolerance±0.05mm±0.03mm±0.02mm
Surface FinishBasic coatingDual-layer corrosion protectionElectro-phosphating (+20% durability)
Mechanical Strength500 MPa yield600 MPa yield700 MPa yield

Supplier's note

  1. Three Technical Breakthroughs:

    • Material Grade: The Pro Model’s ultra-low-loss silicon steel reduces core losses by 30%, ideal for high-power transformers.
    • Precision Tolerance: The Advanced Model’s ±0.03mm thickness ensures seamless lamination, cutting eddy current losses by 18%.
    • Surface Coating: The Pro Model’s electro-phosphating provides 20% longer lifespan in corrosive environments.

  2. Optimal Version Selection:

    • Base Model: Suitable for standard residential or low-power applications where cost-efficiency is prioritized.
    • Advanced Model: Recommended for industrial transformers requiring enhanced durability and energy efficiency.
    • Pro Model: Designed for high-voltage grids or data centers, where ultra-low losses and extreme reliability are critical.

With the Pro Model’s 700 MPa yield strength, you can ensure structural integrity in seismic zones. Pair its electro-phosphating with tight tolerances to achieve a 25% smaller core footprint while maintaining performance.

Frequently asked questions

  • Which Transformer Core Plate model is best suited for high-frequency transformer applications?

  • How to maintain the coated finish of a Transformer Core Plate during installation?

  • Why choose non-oriented silicon steel for transformer cores over regular steel?

  • Can the Transformer Core Plate be customized for non-standard transformer dimensions?

  • Is this Transformer Core Plate compliant with international standards for electrical safety?

  • What makes this core plate suitable for industrial transformer applications?

  • How does cold-rolled processing improve the Transformer Core Plate’s performance?

  • Why is the EI lamination pattern preferred in transformer core designs?

Product comparison

CategoryUsage ScenariosCharacteristicsAdvantagesDisadvantages
Material QualityHigh-stress industrial environments- Industry Standard: ASTM A36 steel
- Our Base: ASTM A569 silicon steel
- Our Advanced: ASTM A1008 high-grade silicon steel (▲20% lower core loss)		Base/Advanced offer superior conductivity and durability for transformers.Standard may corrode faster and have higher core loss.
Coating DurabilityCorrosive environments- Industry Standard: Zinc coating (ASTM A153)
- Our Base: Epoxy powder coating (ASTM D3924)
- Our Advanced: Dual-layer coating (ASTM D3924 + ISO 12944) (▲50% longer lifespan)		Advanced provides unmatched corrosion resistance for harsh conditions.Standard coating may degrade in aggressive environments.
Electrical EfficiencyHigh-frequency transformers- Industry Standard: Core loss = 10 W/kg
- Our Base: 8 W/kg (▲20%)
- Our Advanced: 6 W/kg (▲33% over Base)		Advanced reduces energy loss by 40% compared to industry standards.Standard may lead to higher operational costs in high-frequency applications.
Processing CapabilitiesCustom designs- Industry Standard: Basic cutting/bending
- Our Base: Precision punching/cutting
- Our Advanced: Full-service (decoiling, welding, bending, punching, cutting) (▲Full customization)		Advanced enables complex designs for specialized transformer needs.Standard lacks flexibility for intricate manufacturing requirements.
Compliance StandardsGlobal projects- Industry Standard: ASTM/DIN
- Our Base: ASTM/DIN/BS
- Our Advanced: ASTM/DIN/BS/GB/JIS/AISI (▲Global compliance)		Advanced meets international standards for multinational deployments.Standard may fail certifications in regions requiring non-ASTM/DIN norms.
Cost EfficiencyBudget-sensitive projects- Industry Standard: $50/unit
- Our Base: $70/unit (▲40% better value)
- Our Advanced: $90/unit (▲30% over Base)		Base offers cost-effective performance for mid-range applications.Advanced’s premium features may exceed budget constraints for basic use cases.
