monkey bike

1/6

Specification Engine:125cc, single cylinder, four-stroke, air-cooled Displacement: (50cc, 70cc, 90cc, 110cc and 125cc are all available. ) Drive System: fully automatic, semi-automatic(without handle clutch lever) or manual international gear are all available Transmission: Chain Start Method: Kick start and electric starter Front Suspension: Normal suspension Rear Suspension: Normal shock Front Brake: Drum brake Rear Brake: Drum brake Tire front and rear: 3.50-8 Vehicle Dimension: 140x58x111cm Handgrip Height: 88cm Distance Between Axles: 97cm Seat Height: 68cm Max. Speed: 40 KM/H Weight Capacity: 85kg Packing size: 143X38X73cm

1/6

SKYTEAM 50cc 4 stroke monkey bike(EEC E4 Approval) 50cc motorcycle st70 monkeybike eec foldable handle bar,skyteam CT70 Z50A replica mini dirt bike for kids,4 stroke mini trail 50 fun motorcycle Front disc brake, electric start, four gear manual, and strengthened rear shock absorber ST125-8 ENGINE ENGINE TYPE Air-Cooled, 4 stroke, single cylinder, 2 valve, SOHC DISPLACEMENT 124CC BORE*STROKE 52.4 x 57mm COMPRESSION RATIO 9.1 TO 1 MAXIMUM POWER 5.6kW/7500rpm MAXIMUM TORQUE 8.6Nm/5500rpm MAXIMUM SPEED 88km/h MAXIMUM SPEED ON COC 88km/h LUBRICATION SYSTEM Pressure and splash lubrication CARBURETOR/FUEL SUPPLY MIKUNI 22 83419 CLUTCH TYPE Wet, multiple disc IGNITION SYSTEM CDI STARTER SYSTEM Electric & Kick TRANSMISSION SYSTEM 4-gear, Pedal FINAL TRANSMISSION Chain FUAL TANK CAPACITY 4.5L OIL TANK CAPACITY 800ml CHASSIS CHASSIS Steel, Single-tube FRONT SUSPENSION SYSTEM Telescopic Forks FRONT TRAVEL 60mm REAR SUSPENSION SYSTEM Spring & Oil / Double Shock REAR TRAVEL 50mm FRONT BRAKE Disc155mm REAR BRAKE Drum FRONT TYRE 3.50-8-4PR REAR TYRE 3.50-8-4PR DIMENSIONS LENGTH 1375mm WIDTH 600mm HEIGHT 860mm SEAT HEIGHT 700mm WHEEL BASE 900mm MINIMUM GROUND CLEARANCE 170mm DRY WEIGHT 66Kg CONTAINER LOAD 84/174/174 PACKING DIMENSION 1150 x 410 x 752mm

1/6

WELCOME TO HAOBO our factory high quality dirt bike_monkey EEC 50cc TYPE OF ENGINE: 124.8cc,4-troke,OHC,1 cylinder BORE AND STROKE(mm): 39*41.4/52.4*49.5/52.4*57.9 COMPRESSION RATIO: 8.8:1/9.1:1/9.0:1 COOLING: air IGNITION: CDI TRANSMISSION: 4 speed, manual clutch FINAL DRIVE: chain STARTING SYSTEM: electric&kick SUSPENSION/FRONT: spring&oil. SUSPENSION/REAR: spring&oil or double shock BRAKE/FRONT: discΦ155mm/6" BRAKE/REAR: drum TIRE/FRONT: 3.5-8 TIRE/REAR: 3.5-8 L*W*H: 1430*560*900mm/60"*22"*35" SEAT HEIGHT: 650mm/25.6". FUEL CAPACITY: 4.5L/2.3 Gallons DRY WEIGHT: 75KGS/154.3LBS OPTIONAL: semi-automatic MAX SPEED: 42km/h,57km/h,90km/h

1/6

SKYTEAM 125cc 4 stroke GorillaMonkey bike monkey motorcycle (EEC EUROIV EURO4 APPROVED) SKYTEAM 125cc 4 stroke GorillaMonkey bike monkey motorcycle Dirt bike 110cc 125cc Monkey Bike Gorilla Mini Monkey Bike Mini Monkey Dax Mini Moto msx kids monkey motorcycle bike pocket bike Front disc brake, electric start, four gear manual, and strengthened rear shock absorber ST125-8A ENGINE ENGINE TYPE Air-Cooled, 4 stroke, single cylinder, 2 valve, SOHC DISPLACEMENT 124CC BORE*STROKE 52.4 x 57mm COMPRESSION RATIO 9.1 TO 1 MAXIMUM POWER 5.6kW/7500rpm MAXIMUM TORQUE 8.6Nm/5500rpm MAXIMUM SPEED 88km/h MAXIMUM SPEED ON COC 88km/h LUBRICATION SYSTEM Pressure and splash lubrication CARBURETOR/FUEL SUPPLY MIKUNI 22 83419 CLUTCH TYPE Wet, multiple disc IGNITION SYSTEM CDI STARTER SYSTEM Electric & Kick TRANSMISSION SYSTEM 4-gear, Pedal FINAL TRANSMISSION Chain FUAL TANK CAPACITY 4.5L OIL TANK CAPACITY 800ml CHASSIS CHASSIS Steel, Single-tube FRONT SUSPENSION SYSTEM Telescopic Forks FRONT TRAVEL 60mm REAR SUSPENSION SYSTEM Spring & Oil / Double Shock REAR TRAVEL 50mm FRONT BRAKE Disc155mm REAR BRAKE Drum FRONT TYRE 3.50-8-4PR REAR TYRE 3.50-8-4PR DIMENSIONS LENGTH 1375mm WIDTH 600mm HEIGHT 860mm SEAT HEIGHT 700mm WHEEL BASE 900mm MINIMUM GROUND CLEARANCE 170mm DRY WEIGHT 66Kg CONTAINER LOAD 84/174/174 PACKING DIMENSION 1150 x 410 x 752mm

1/6

3. Q: What’s the delivery time9 A: It usually takes about one week for sample order. For big order,the exact delivery time will be different for different orders or at different time. 6. Q:What's your warranty terms9 A: We offer different warranty time for different products.

1/4

Q1. What is your terms of packing9 A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters. Q5. Can you produce according to the samples9 A: Yes, we can produce by your samples or technical drawings.
